MatrixOperation.h File Reference

This graph shows which files directly or indirectly include this file:

Go to the source code of this file.

Classes
class	SquareMatrix< T, N >

Functions
template<class T >
T	determinant (SquareMatrix< T, 2 > &a)
template<class T >
T	determinant (SquareMatrix< T, 3 > &a)
template<class T , int N>
T	determinant (SquareMatrix< T, N > &a, int size)
template<class T >
SquareMatrix< T, 2 >	inverse (SquareMatrix< T, 2 > &a)
template<class T >
SquareMatrix< T, 3 >	inverse (SquareMatrix< T, 3 > &a)
template<class T , int N>
SquareMatrix< T, N >	inverse (SquareMatrix< T, N > &b, int size)
template<class T , int N>
SquareMatrix< T, N >	inverseGauss (SquareMatrix< T, N > &a, int size)

Function Documentation

template<class T >

T determinant

(

SquareMatrix< T, 2 > &

a

)

Definition at line 67 of file MatrixOperation.h.

Referenced by MeshMetricsCalculator< T >::computeIBInterpolationMatrices(), MeshMetricsCalculator< T >::computeIBInterpolationMatricesCells(), MeshMetricsCalculator< T >::computeSolidInterpolationMatrices(), determinant(), and inverse().

                                   {
  T d = a(0,0)*a(1,1)-a(0,1)*a(1,0);
  return d;
}

template<class T >

T determinant

(

SquareMatrix< T, 3 > &

a

)

Definition at line 73 of file MatrixOperation.h.

                                   {
  T d = a(0,0)*(a(1,1)*a(2,2)-a(1,2)*a(2,1))
    -a(0,1)*(a(1,0)*a(2,2) - a(1,2)*a(2,0))
    +a(0,2)*(a(1,0)*a(2,1) - a(1,1)*a(2,0));
  return d;
}

template<class T , int N>

T determinant	(	SquareMatrix< T, N > &	a,
		int	size
	)

Definition at line 81 of file MatrixOperation.h.

References determinant().

                                             {

  T d(0.0);
  T s(1.0);
    int m, n;
    SquareMatrix<T,N> b(NumTypeTraits<T>::getZero());

    if (size == 1){
      d = a(0,0);
      return d;
    }
    else{
      for(int k=0; k<size; k++){
        m = 0;
        n = 0;
        for(int i=0; i<size; i++){
          for(int j=0; j<size; j++){
            b(i,j)=0.0;
            if(i!=0&&j!=k){
              b(m,n)=a(i,j);
              if(n<(size-2))
                n++;
              else{
                n=0;
                m++;
              }
            }
          }
        }
        d = d + s*(a(0,k)*determinant(b, size-1));
        s=-1*s;
      }
    }
    return d;
}

template<class T >

SquareMatrix<T,2> inverse

(

SquareMatrix< T, 2 > &

a

)

Definition at line 118 of file MatrixOperation.h.

References determinant().

Referenced by MeshMetricsCalculator< T >::computeIBInterpolationMatrices(), MeshMetricsCalculator< T >::computeIBInterpolationMatricesCells(), MeshMetricsCalculator< T >::computeSolidInterpolationMatrices(), and COMETDiscretizer< T >::updateeShifted().

                                               {

  SquareMatrix<T,2> inv;
  T d = determinant(a);
  inv(0,0) = a(1,1) / d;
  inv(0,1) = -a(0,1) / d;
  inv(1,0) = -a(1,0) / d;
  inv(1,1) = a(0,0) / d;

  return inv;
}

template<class T >

SquareMatrix<T,3> inverse

(

SquareMatrix< T, 3 > &

a

)

Definition at line 132 of file MatrixOperation.h.

References determinant().

{
  SquareMatrix<T,3> inv;
  T d = determinant(a);

  inv(0,0) =  (a(1,1)*a(2,2) - a(1,2)*a(2,1)) / d;
  inv(0,1) =  (a(0,2)*a(2,1) - a(0,1)*a(2,2)) / d;
  inv(0,2) =  (a(0,1)*a(1,2) - a(0,2)*a(1,1)) / d;
  inv(1,0) =  (a(1,2)*a(2,0) - a(1,0)*a(2,2)) / d;
  inv(1,1) =  (a(0,0)*a(2,2) - a(0,2)*a(2,0)) / d;
  inv(1,2) =  (a(0,2)*a(1,0) - a(0,0)*a(1,2)) / d;
  inv(2,0) =  (a(1,0)*a(2,1) - a(1,1)*a(2,0)) / d;
  inv(2,1) =  (a(0,1)*a(2,0) - a(0,0)*a(2,1)) / d;
  inv(2,2) =  (a(0,0)*a(1,1) - a(0,1)*a(1,0)) / d;

  return inv;
}

template<class T , int N>

SquareMatrix<T,N> inverse	(	SquareMatrix< T, N > &	b,
		int	size
	)

Definition at line 151 of file MatrixOperation.h.

References determinant().

{
   const T d = determinant(b, size);

   SquareMatrix<T,N> a(NumTypeTraits<T>::getZero());
   SquareMatrix<T,N> tmp(NumTypeTraits<T>::getZero());
   SquareMatrix<T,N> fac(NumTypeTraits<T>::getZero());
   SquareMatrix<T,N> trans(NumTypeTraits<T>::getZero());

   int p, q, m, n, i, j;

   for(q=0; q<size; q++){
     for(p=0; p<size; p++){
       m=0;
       n=0;
       for(i=0; i<size; i++){
         for(j=0; j<size; j++){
           tmp(i,j)=0;
           if(i!=q&&j!=p) {
             tmp(m,n)=b(i,j);
             if(n<(size-2))
               n++;
             else {
               n=0;
               m++;
             }
           }
         }
       }
       fac(q,p)=pow(-1.0,q+p)*determinant(tmp,size-1);
     }
   }

   for(i=0; i<size; i++) {
     for(j=0; j<size; j++){
       trans(i,j)=fac(j,i);
     }
   }

   for(i=0; i<size; i++) {
     for(j=0; j<size; j++){
       a(i,j)=trans(i,j)/d;
     }
   }
   return a;
}

template<class T , int N>

SquareMatrix<T,N> inverseGauss	(	SquareMatrix< T, N > &	a,
		int	size
	)

Definition at line 201 of file MatrixOperation.h.

References fabs().

Referenced by KineticModel< T >::NewtonsMethodBGK(), COMETModel< T >::NewtonsMethodBGK(), KineticModel< T >::NewtonsMethodESBGK(), and COMETModel< T >::NewtonsMethodESBGK().

{

  int indx[10];
  T c[10];
  SquareMatrix<T,N> b(NumTypeTraits<T>::getZero());
  SquareMatrix<T,N> x(NumTypeTraits<T>::getZero());

  b = 1.0; //identity matrix
  /*
    for (int i = 0; i < size; i++)
    cout <<i<<" a-matrix "<<a(i,0)<< " "<< a(i,1)<< "   " <<a(i,2)<< " "<< a(i,3)<< "   " <<a(i,4)<<endl;
  */

 /* Initialize the index */
  for (int i = 0; i < size; i++){indx[i] = i;}

  /* Find the rescaling factors, one from each row */
  for (int i = 0; i < size; i++)
  {
    T c1 = 0;
    for (int j = 0; j < size; j++)
      {
        if (fabs(a(i,j)) > c1)
          c1 = fabs(a(i,j));
      }
    c[i] = c1;
  }


  /* Search the pivoting (largest) element from each column */
  for (int j = 0; j < size-1; j++)
  {
    T pi1 = 0.0;
    int pk=j;
    int  itmp;
    T pi;
    for (int i = j; i < size; i++)
    {
      pi = fabs(a(indx[i],j))/c[indx[i]];
      if (pi > pi1)
      {
        pi1 = pi;
        pk = i;
      }
    }
    /* Interchange the rows via indx[] to record pivoting order */
    itmp = indx[j];
    indx[j] = indx[pk];
    indx[pk] = itmp;
    for (int i = j+1; i < size; i++)
    {
      T pj;
      pj = a(indx[i],j)/a(indx[j],j);
      /* Record pivoting ratios below the diagonal */
      a(indx[i],j) = pj;
      /* Modify other elements accordingly */
      for (int k = j+1; k < size; k++)
      {
        a(indx[i],k) = a(indx[i],k)-pj*a(indx[j],k);
      }
    }
  }

  /*
  cout <<"indx  "<< "  re-scaling" <<endl;
  for (int i = 0; i < size; i++)cout<< indx[i]<<" -  "<<c[i] <<endl;
  for (int i = 0; i < size; i++)
    cout <<i<<" an-matrix "<<a(i,0)<< " "<< a(i,1)<< "   " <<a(i,2)<< " "<< a(i,3)<< "   " <<a(i,4)<<endl;
  */

  for (int i = 0; i < size-1; i++)
  {
    for (int j = i+1; j < size; j++)
    {
      for (int k = 0; k < size; k++)
      {
        b(indx[j],k) = b(indx[j],k)-a(indx[j],i)*b(indx[i],k);
      }
    }
  }
  //backsubstitution
  for (int col = 0; col < size; col++)
  {
    x(size-1,col) = b(indx[size-1],col)/a(indx[size-1],size-1);
    for (int j = size-2; j >= 0; j = j-1)
    {
      x(j,col) = b(indx[j],col);
      for (int k = j+1; k < size; k++)
      {
        x(j,col) = x(j,col)-a(indx[j],k)*x(k,col);
      }
      x(j,col) = x(j,col)/a(indx[j],j);
    }
  }
  return x;
}
