BaseGenericBCS< X, Diag, OffDiag > Class Template Reference

#include <GenericBCS.h>

Inheritance diagram for BaseGenericBCS< X, Diag, OffDiag >:
Inheritance graph
[legend]
Collaboration diagram for BaseGenericBCS< X, Diag, OffDiag >:
Collaboration graph
[legend]

Public Types

typedef NumTypeTraits< X >
::T_Scalar 		T_Scalar

typedef Array< T_Scalar > TArray

typedef Array< int > IntArray

typedef Vector< T_Scalar, 3 > VectorT3

typedef CRMatrix< Diag,
OffDiag, X > 		CCMatrix

typedef CCMatrix::PairWiseAssembler CCAssembler

typedef FluxJacobianMatrix
< Diag, X > 		FMatrix

typedef DiagonalMatrix< Diag, X > BBMatrix

typedef Array< Diag > DiagArray

typedef Array< OffDiag > OffDiagArray

typedef Array< X > XArray

typedef Array< VectorT3 > VectorT3Array


Public Member Functions

 BaseGenericBCS (const StorageSite &faces, const Mesh &mesh, const GeomFields &geomFields, Field &varField, Field &fluxField, MultiFieldMatrix &matrix, MultiField &xField, MultiField &rField)

void applyDirichletBC (int f, const X &bValue) const

void applyDirichletBC (const X &bValue) const

void applyDirichletBC (const FloatValEvaluator< X > &bValue) const

void applyNeumannBC (const int f, const X &specifiedFlux) const

void applyNeumannBC (const X &bFlux) const

void applyNeumannBC (const FloatValEvaluator< X > &bFlux) const

void applyExtrapolationBC () const

void applyExtrapolationBC (const int f) const

void applyConvectionBC (const int f, const X &hCoeff, const X &Xinf) const

void applyConvectionBC (const X &hCoeff, const X &Xinf) const

void applyRadiationBC (const int f, const X &emissivity, const X &Xinf) const

void applyMixedBC (const int f, const X &hCoeff, const X &emissivity, const X &Xinf) const

void applyInterfaceBC (const int f) const

void applyInterfaceBC () const

void applyDielectricInterfaceBC (const int f, const X &hCoeff, const X &Xinf, const X &source) const

void applyDielectricInterfaceBC (const X &hCoeff, const X &Xinf, const X &source) const

void applyFlowBC (const TArray &convFlux, const X &bValue) const

void applyNonzeroDiagBC () const

void applyNonzeroDiagBC (int f) const


Protected Attributes

const StorageSite & _faces

const StorageSite & _cells

const IntArray & _ibType

const CRConnectivity & _faceCells

const Field & _varField

const Field & _fluxField

const MultiField::ArrayIndex _xIndex

const MultiField::ArrayIndex _fluxIndex

CCMatrix & _dRdX

FMatrix & _dFluxdX

BBMatrix & _dFluxdFlux

CCAssembler & _assembler

DiagArray & _dRdXDiag

XArray & _x

XArray & _r

XArray & _flux

XArray & _rFlux

const Field & _areaMagField

const TArray & _faceAreaMag

const Field & _areaField

const VectorT3Array & _faceArea

const bool _is2D


Detailed Description

template<class X, class Diag, class OffDiag>
class BaseGenericBCS< X, Diag, OffDiag >

Definition at line 22 of file GenericBCS.h.

Member Typedef Documentation

template<class X, class Diag, class OffDiag>
typedef DiagonalMatrix<Diag,X> BaseGenericBCS< X, Diag, OffDiag >::BBMatrix

Definition at line 37 of file GenericBCS.h.

template<class X, class Diag, class OffDiag>
typedef CCMatrix::PairWiseAssembler BaseGenericBCS< X, Diag, OffDiag >::CCAssembler

Definition at line 34 of file GenericBCS.h.

template<class X, class Diag, class OffDiag>
typedef CRMatrix<Diag,OffDiag,X> BaseGenericBCS< X, Diag, OffDiag >::CCMatrix

Definition at line 33 of file GenericBCS.h.

template<class X, class Diag, class OffDiag>
typedef Array<Diag> BaseGenericBCS< X, Diag, OffDiag >::DiagArray

Definition at line 39 of file GenericBCS.h.

template<class X, class Diag, class OffDiag>
typedef FluxJacobianMatrix<Diag,X> BaseGenericBCS< X, Diag, OffDiag >::FMatrix

Definition at line 36 of file GenericBCS.h.

template<class X, class Diag, class OffDiag>
typedef Array<int> BaseGenericBCS< X, Diag, OffDiag >::IntArray

Definition at line 29 of file GenericBCS.h.

template<class X, class Diag, class OffDiag>
typedef Array<OffDiag> BaseGenericBCS< X, Diag, OffDiag >::OffDiagArray

Definition at line 40 of file GenericBCS.h.

template<class X, class Diag, class OffDiag>
typedef NumTypeTraits<X>::T_Scalar BaseGenericBCS< X, Diag, OffDiag >::T_Scalar

Definition at line 26 of file GenericBCS.h.

template<class X, class Diag, class OffDiag>
typedef Array<T_Scalar> BaseGenericBCS< X, Diag, OffDiag >::TArray

Definition at line 28 of file GenericBCS.h.

template<class X, class Diag, class OffDiag>
typedef Vector<T_Scalar,3> BaseGenericBCS< X, Diag, OffDiag >::VectorT3

Definition at line 31 of file GenericBCS.h.

template<class X, class Diag, class OffDiag>
typedef Array<VectorT3> BaseGenericBCS< X, Diag, OffDiag >::VectorT3Array

Definition at line 43 of file GenericBCS.h.

template<class X, class Diag, class OffDiag>
typedef Array<X> BaseGenericBCS< X, Diag, OffDiag >::XArray

Definition at line 42 of file GenericBCS.h.

Constructor & Destructor Documentation

template<class X, class Diag, class OffDiag>
BaseGenericBCS< X, Diag, OffDiag >::BaseGenericBCS ( const StorageSite &  faces,
const Mesh &  mesh,
const GeomFields &  geomFields,
Field &  varField,
Field &  fluxField,
MultiFieldMatrix &  matrix,
MultiField &  xField,
MultiField &  rField
)
inline

Definition at line 46 of file GenericBCS.h.

52  :
53  _faces(faces),
54  _cells(mesh.getCells()),
55  _ibType(dynamic_cast<const IntArray&>(geomFields.ibType[_cells])),
56  _faceCells(mesh.getFaceCells(_faces)),
57  _varField(varField),
58  _fluxField(fluxField),
59  _xIndex(&_varField,&_cells),
60  _fluxIndex(&_fluxField,&_faces),
61  _dRdX(dynamic_cast<CCMatrix&>(matrix.getMatrix(_xIndex,_xIndex))),
62  _dFluxdX(dynamic_cast<FMatrix&>(matrix.getMatrix(_fluxIndex,_xIndex))),
63  _dFluxdFlux(dynamic_cast<BBMatrix&>(matrix.getMatrix(_fluxIndex,_fluxIndex))),
64  _assembler(_dRdX.getPairWiseAssembler(_faceCells)),
65  _dRdXDiag(_dRdX.getDiag()),
66  _x(dynamic_cast<XArray&>(xField[_xIndex])),
67  _r(dynamic_cast<XArray&>(rField[_xIndex])),
68  _flux(dynamic_cast<XArray&>(xField[_fluxIndex])),
69  _rFlux(dynamic_cast<XArray&>(rField[_fluxIndex])),
70  _areaMagField(geomFields.areaMag),
71  _faceAreaMag(dynamic_cast<const TArray&>(_areaMagField[_faces])),
72  _areaField(geomFields.area),
73  _faceArea(dynamic_cast<const VectorT3Array&>(_areaField[_faces])),
74  _is2D(mesh.getDimension()==2)
75  {}
MultiFieldMatrix::getMatrix
Matrix & getMatrix(const Index &rowIndex, const Index &colIndex)
Definition: MultiFieldMatrix.cpp:42
BaseGenericBCS::_faceArea
const VectorT3Array & _faceArea
Definition: GenericBCS.h:466
BaseGenericBCS::_dFluxdFlux
BBMatrix & _dFluxdFlux
Definition: GenericBCS.h:456
BaseGenericBCS::_faceAreaMag
const TArray & _faceAreaMag
Definition: GenericBCS.h:464
BaseGenericBCS::_areaField
const Field & _areaField
Definition: GenericBCS.h:465
BaseGenericBCS::_ibType
const IntArray & _ibType
Definition: GenericBCS.h:448
BaseGenericBCS::_assembler
CCAssembler & _assembler
Definition: GenericBCS.h:457
CRMatrix::getDiag
Array< Diag > & getDiag()
Definition: CRMatrix.h:856
BaseGenericBCS::_faceCells
const CRConnectivity & _faceCells
Definition: GenericBCS.h:449
BaseGenericBCS::_rFlux
XArray & _rFlux
Definition: GenericBCS.h:462
GeomFields::ibType
Field ibType
Definition: GeomFields.h:38
BaseGenericBCS::_faces
const StorageSite & _faces
Definition: GenericBCS.h:446
BaseGenericBCS::_is2D
const bool _is2D
Definition: GenericBCS.h:467
BaseGenericBCS::_x
XArray & _x
Definition: GenericBCS.h:459
BaseGenericBCS::_xIndex
const MultiField::ArrayIndex _xIndex
Definition: GenericBCS.h:452
BaseGenericBCS::_r
XArray & _r
Definition: GenericBCS.h:460
Mesh::getCells
const StorageSite & getCells() const
Definition: Mesh.h:109
Mesh::getFaceCells
const CRConnectivity & getFaceCells(const StorageSite &site) const
Definition: Mesh.cpp:388
BaseGenericBCS::_cells
const StorageSite & _cells
Definition: GenericBCS.h:447
BaseGenericBCS::_flux
XArray & _flux
Definition: GenericBCS.h:461
BaseGenericBCS::_dFluxdX
FMatrix & _dFluxdX
Definition: GenericBCS.h:455
BaseGenericBCS::_varField
const Field & _varField
Definition: GenericBCS.h:450
BaseGenericBCS::_fluxIndex
const MultiField::ArrayIndex _fluxIndex
Definition: GenericBCS.h:453
BaseGenericBCS::_fluxField
const Field & _fluxField
Definition: GenericBCS.h:451
BaseGenericBCS::_areaMagField
const Field & _areaMagField
Definition: GenericBCS.h:463
GeomFields::area
Field area
Definition: GeomFields.h:23
CRMatrix::getPairWiseAssembler
PairWiseAssembler & getPairWiseAssembler(const CRConnectivity &pairs)
Definition: CRMatrix.h:867
Mesh::getDimension
int getDimension() const
Definition: Mesh.h:105
GeomFields::areaMag
Field areaMag
Definition: GeomFields.h:25
BaseGenericBCS::_dRdXDiag
DiagArray & _dRdXDiag
Definition: GenericBCS.h:458
BaseGenericBCS::_dRdX
CCMatrix & _dRdX
Definition: GenericBCS.h:454

Member Function Documentation

template<class X, class Diag, class OffDiag>
void BaseGenericBCS< X, Diag, OffDiag >::applyConvectionBC ( const int  f,
const X &  hCoeff,
const X &  Xinf
) const
inline

Definition at line 214 of file GenericBCS.h.

Referenced by BaseGenericBCS< Vector< T, N >, DiagonalTensor< T, N >, T >::applyConvectionBC().

216  {
217  const int c0 = _faceCells(f,0);
218  const int c1 = _faceCells(f,1);
219
220  if (_ibType[c0] != Mesh::IBTYPE_FLUID)
221  return;
222
223  // the current value of flux and its Jacobians
224  const X fluxInterior = -_r[c1];
225
226  // flux based on current boundary value
227  const X fluxBoundary = -hCoeff*(_x[c1]-Xinf)*_faceAreaMag[f];
228
229  const X dFlux = fluxBoundary-fluxInterior;
230
231  _r[c1] = dFlux;
232
233  // add this to complete the Jacobian wrt boundar value
234  _dRdXDiag[c1] -= hCoeff*_faceAreaMag[f];
235
236  // mark this row as a "boundary" row so that we will update it
237  // after the overall system is solved
238  _dRdX.setBoundary(c1);
239
240  _flux[f] = fluxBoundary;
241  _rFlux[f] = 0;
242  _dFluxdX.setCoeffL(f,NumTypeTraits<X>::getZero());
243  _dFluxdX.setCoeffR(f,-hCoeff*_faceAreaMag[f]);
244  _dFluxdFlux[f] = NumTypeTraits<Diag>::getNegativeUnity();
245  }
BaseGenericBCS::_dFluxdFlux
BBMatrix & _dFluxdFlux
Definition: GenericBCS.h:456
BaseGenericBCS::_faceAreaMag
const TArray & _faceAreaMag
Definition: GenericBCS.h:464
BaseGenericBCS::_ibType
const IntArray & _ibType
Definition: GenericBCS.h:448
FluxJacobianMatrix::setCoeffR
void setCoeffR(const int f, const OffDiag &c)
Definition: FluxJacobianMatrix.h:68
BaseGenericBCS::_faceCells
const CRConnectivity & _faceCells
Definition: GenericBCS.h:449
BaseGenericBCS::_rFlux
XArray & _rFlux
Definition: GenericBCS.h:462
FluxJacobianMatrix::setCoeffL
void setCoeffL(const int f, const OffDiag &c)
Definition: FluxJacobianMatrix.h:67
BaseGenericBCS::_x
XArray & _x
Definition: GenericBCS.h:459
BaseGenericBCS::_r
XArray & _r
Definition: GenericBCS.h:460
CRMatrix::setBoundary
void setBoundary(const int nr)
Definition: CRMatrix.h:1056
BaseGenericBCS::_flux
XArray & _flux
Definition: GenericBCS.h:461
BaseGenericBCS::_dFluxdX
FMatrix & _dFluxdX
Definition: GenericBCS.h:455
BaseGenericBCS::_dRdXDiag
DiagArray & _dRdXDiag
Definition: GenericBCS.h:458
BaseGenericBCS::_dRdX
CCMatrix & _dRdX
Definition: GenericBCS.h:454
template<class X, class Diag, class OffDiag>
void BaseGenericBCS< X, Diag, OffDiag >::applyConvectionBC ( const X &  hCoeff,
const X &  Xinf
) const
inline

Definition at line 247 of file GenericBCS.h.

248  {
249  for(int i=0; i<_faces.getCount(); i++)
250  applyConvectionBC(i,hCoeff,Xinf);
251  }
BaseGenericBCS::applyConvectionBC
void applyConvectionBC(const int f, const X &hCoeff, const X &Xinf) const
Definition: GenericBCS.h:214
BaseGenericBCS::_faces
const StorageSite & _faces
Definition: GenericBCS.h:446
StorageSite::getCount
int getCount() const
Definition: StorageSite.h:39
template<class X, class Diag, class OffDiag>
void BaseGenericBCS< X, Diag, OffDiag >::applyDielectricInterfaceBC ( const int  f,
const X &  hCoeff,
const X &  Xinf,
const X &  source
) const
inline

Definition at line 367 of file GenericBCS.h.

Referenced by BaseGenericBCS< Vector< T, N >, DiagonalTensor< T, N >, T >::applyDielectricInterfaceBC().

369  {
370  // here the hCoeff = dielectric_constant / dielectric_thickness
371  // source = totalcharge * dielectric_thickness / 4. for 2D
372  // source = totalcharge * dielectric_thickness / 6. for 3D
373  const int c0 = _faceCells(f,0);
374  const int c1 = _faceCells(f,1);
375
376  if (_ibType[c0] != Mesh::IBTYPE_FLUID)
377  return;
378
379  // the current value of flux and its Jacobians
380  const X fluxInterior = -_r[c1];
381
382  // flux based on current boundary value
383
384  X fluxSource = source * _faceAreaMag[f];
385  if (_is2D)
386  fluxSource /= 2.0;
387  else
388  fluxSource /= 2.0;
389  const X fluxBoundary = -hCoeff*(_x[c1]-Xinf)*_faceAreaMag[f] + fluxSource;
390  const X dFlux = fluxBoundary-fluxInterior;
391
392  _r[c1] = dFlux;
393
394  // add this to complete the Jacobian wrt boundar value
395  _dRdXDiag[c1] -= hCoeff*_faceAreaMag[f];
396
397  // mark this row as a "boundary" row so that we will update it
398  // after the overall system is solved
399  _dRdX.setBoundary(c1);
400
401  _flux[f] = fluxBoundary;
402  _rFlux[f] = 0;
403  _dFluxdX.setCoeffL(f,NumTypeTraits<X>::getZero());
404  _dFluxdX.setCoeffR(f,-hCoeff*_faceAreaMag[f]);
405  _dFluxdFlux[f] = NumTypeTraits<Diag>::getNegativeUnity();
406
407  }
BaseGenericBCS::_dFluxdFlux
BBMatrix & _dFluxdFlux
Definition: GenericBCS.h:456
BaseGenericBCS::_faceAreaMag
const TArray & _faceAreaMag
Definition: GenericBCS.h:464
BaseGenericBCS::_ibType
const IntArray & _ibType
Definition: GenericBCS.h:448
FluxJacobianMatrix::setCoeffR
void setCoeffR(const int f, const OffDiag &c)
Definition: FluxJacobianMatrix.h:68
BaseGenericBCS::_faceCells
const CRConnectivity & _faceCells
Definition: GenericBCS.h:449
BaseGenericBCS::_rFlux
XArray & _rFlux
Definition: GenericBCS.h:462
FluxJacobianMatrix::setCoeffL
void setCoeffL(const int f, const OffDiag &c)
Definition: FluxJacobianMatrix.h:67
BaseGenericBCS::_is2D
const bool _is2D
Definition: GenericBCS.h:467
BaseGenericBCS::_x
XArray & _x
Definition: GenericBCS.h:459
BaseGenericBCS::_r
XArray & _r
Definition: GenericBCS.h:460
CRMatrix::setBoundary
void setBoundary(const int nr)
Definition: CRMatrix.h:1056
BaseGenericBCS::_flux
XArray & _flux
Definition: GenericBCS.h:461
BaseGenericBCS::_dFluxdX
FMatrix & _dFluxdX
Definition: GenericBCS.h:455
BaseGenericBCS::_dRdXDiag
DiagArray & _dRdXDiag
Definition: GenericBCS.h:458
BaseGenericBCS::_dRdX
CCMatrix & _dRdX
Definition: GenericBCS.h:454
template<class X, class Diag, class OffDiag>
void BaseGenericBCS< X, Diag, OffDiag >::applyDielectricInterfaceBC ( const X &  hCoeff,
const X &  Xinf,
const X &  source
) const
inline

Definition at line 409 of file GenericBCS.h.

411  {
412  for(int i=0; i<_faces.getCount(); i++)
413  applyDielectricInterfaceBC(i,hCoeff, Xinf, source );
414  }
BaseGenericBCS::_faces
const StorageSite & _faces
Definition: GenericBCS.h:446
StorageSite::getCount
int getCount() const
Definition: StorageSite.h:39
BaseGenericBCS::applyDielectricInterfaceBC
void applyDielectricInterfaceBC(const int f, const X &hCoeff, const X &Xinf, const X &source) const
Definition: GenericBCS.h:367
template<class X, class Diag, class OffDiag>
void BaseGenericBCS< X, Diag, OffDiag >::applyDirichletBC ( int  f,
const X &  bValue
) const
inline

Definition at line 77 of file GenericBCS.h.

Referenced by BaseGenericBCS< Vector< T, N >, DiagonalTensor< T, N >, T >::applyDirichletBC(), BaseGenericBCS< Vector< T, N >, DiagonalTensor< T, N >, T >::applyFlowBC(), and slipJumpMomentumBC().

78  {
79  const int c0 = _faceCells(f,0);
80  const int c1 = _faceCells(f,1);
81
82  if (_ibType[c0] != Mesh::IBTYPE_FLUID)
83  return;
84
85  // the current value of flux and its Jacobians
86  const X fluxB = -_r[c1];
87  const OffDiag dFluxdXC0 = -_assembler.getCoeff10(f);
88  const Diag dFluxdXC1 = -_dRdXDiag[c1];
89  const OffDiag dRC0dXC1 = _assembler.getCoeff01(f);
90
91  // since we know the boundary value, compute the boundary
92  // x correction and it's contribution to the residual for c0; we
93  // can then eliminate the coefficient to the boundary cell
94
95  const X dXC1 = bValue - _x[c1];
96  const X dFlux = dFluxdXC1*dXC1;
97  const X dRC0 = dRC0dXC1*dXC1;
98  _r[c0] += dRC0;
99
100  _assembler.getCoeff01(f) = NumTypeTraits<OffDiag>::getZero();
101
102  // set the boundary value and make its correction equation an
103  // identity
104  _x[c1] = bValue;
105  _assembler.getCoeff10(f) = NumTypeTraits<OffDiag>::getZero();
106  _r[c1] = NumTypeTraits<X>::getZero();
107  _dRdXDiag[c1] = NumTypeTraits<Diag>::getNegativeUnity();
108
109  //setup the equation for the boundary flux correction
110  _dFluxdX.setCoeffL(f,dFluxdXC0);
111  _dFluxdX.setCoeffR(f,NumTypeTraits<OffDiag>::getZero());
112  _flux[f] = fluxB;
113  _rFlux[f] = dFlux;
114  _dFluxdFlux[f] = NumTypeTraits<Diag>::getNegativeUnity();
115  }
BaseGenericBCS::_dFluxdFlux
BBMatrix & _dFluxdFlux
Definition: GenericBCS.h:456
BaseGenericBCS::_ibType
const IntArray & _ibType
Definition: GenericBCS.h:448
BaseGenericBCS::_assembler
CCAssembler & _assembler
Definition: GenericBCS.h:457
FluxJacobianMatrix::setCoeffR
void setCoeffR(const int f, const OffDiag &c)
Definition: FluxJacobianMatrix.h:68
CRMatrix::PairWiseAssembler::getCoeff10
OffDiag & getCoeff10(const int np)
Definition: CRMatrix.h:131
BaseGenericBCS::_faceCells
const CRConnectivity & _faceCells
Definition: GenericBCS.h:449
BaseGenericBCS::_rFlux
XArray & _rFlux
Definition: GenericBCS.h:462
FluxJacobianMatrix::setCoeffL
void setCoeffL(const int f, const OffDiag &c)
Definition: FluxJacobianMatrix.h:67
BaseGenericBCS::_x
XArray & _x
Definition: GenericBCS.h:459
BaseGenericBCS::_r
XArray & _r
Definition: GenericBCS.h:460
CRMatrix::PairWiseAssembler::getCoeff01
OffDiag & getCoeff01(const int np)
Definition: CRMatrix.h:126
BaseGenericBCS::_flux
XArray & _flux
Definition: GenericBCS.h:461
BaseGenericBCS::_dFluxdX
FMatrix & _dFluxdX
Definition: GenericBCS.h:455
BaseGenericBCS::_dRdXDiag
DiagArray & _dRdXDiag
Definition: GenericBCS.h:458
template<class X, class Diag, class OffDiag>
void BaseGenericBCS< X, Diag, OffDiag >::applyDirichletBC ( const X &  bValue) const
inline

Definition at line 117 of file GenericBCS.h.

118  {
119  for(int i=0; i<_faces.getCount(); i++)
120  applyDirichletBC(i,bValue);
121  }
BaseGenericBCS::_faces
const StorageSite & _faces
Definition: GenericBCS.h:446
BaseGenericBCS::applyDirichletBC
void applyDirichletBC(int f, const X &bValue) const
Definition: GenericBCS.h:77
StorageSite::getCount
int getCount() const
Definition: StorageSite.h:39
template<class X, class Diag, class OffDiag>
void BaseGenericBCS< X, Diag, OffDiag >::applyDirichletBC ( const FloatValEvaluator< X > &  bValue) const
inline

Definition at line 123 of file GenericBCS.h.

124  {
125  for(int i=0; i<_faces.getCount(); i++)
126  applyDirichletBC(i,bValue[i]);
127  }
BaseGenericBCS::_faces
const StorageSite & _faces
Definition: GenericBCS.h:446
BaseGenericBCS::applyDirichletBC
void applyDirichletBC(int f, const X &bValue) const
Definition: GenericBCS.h:77
StorageSite::getCount
int getCount() const
Definition: StorageSite.h:39
template<class X, class Diag, class OffDiag>
void BaseGenericBCS< X, Diag, OffDiag >::applyExtrapolationBC ( ) const
inline

Definition at line 172 of file GenericBCS.h.

Referenced by BaseGenericBCS< Vector< T, N >, DiagonalTensor< T, N >, T >::applyExtrapolationBC(), and BaseGenericBCS< Vector< T, N >, DiagonalTensor< T, N >, T >::applyFlowBC().

173  {
174  for(int i=0; i<_faces.getCount(); i++)
175  applyExtrapolationBC(i);
176  }
BaseGenericBCS::_faces
const StorageSite & _faces
Definition: GenericBCS.h:446
StorageSite::getCount
int getCount() const
Definition: StorageSite.h:39
BaseGenericBCS::applyExtrapolationBC
void applyExtrapolationBC() const
Definition: GenericBCS.h:172
template<class X, class Diag, class OffDiag>
void BaseGenericBCS< X, Diag, OffDiag >::applyExtrapolationBC ( const int  f) const
inline

Definition at line 180 of file GenericBCS.h.

181  {
182  const int c0 = _faceCells(f,0);
183  const int c1 = _faceCells(f,1);
184
185  if (_ibType[c0] != Mesh::IBTYPE_FLUID)
186  return;
187
188  // the current value of flux and its Jacobians
189  const X fluxB = -_r[c1];
190  const OffDiag dFluxdXC0 = -_assembler.getCoeff10(f);
191  const Diag dFluxdXC1 = -_dRdXDiag[c1];
192
193  const X xc0mxc1 = _x[c0]-_x[c1];
194
195  // eliminate boundary dependency from cell equation
196  _dRdXDiag[c0] += dFluxdXC1;
197  _r[c0] += dFluxdXC1*xc0mxc1;
198  _assembler.getCoeff01(f) = 0;
199
200  // boundary value equation
201  _dRdXDiag[c1] = NumTypeTraits<Diag>::getNegativeUnity();
202  _assembler.getCoeff10(f) = NumTypeTraits<OffDiag>::getUnity();
203  _r[c1] = xc0mxc1;
204  _dRdX.setBoundary(c1);
205
206  //setup the equation for the boundary flux correction
207  _dFluxdX.setCoeffL(f,dFluxdXC0);
208  _dFluxdX.setCoeffR(f,dFluxdXC0); // should really be dFluxdXC1
209  _flux[f] = fluxB;
210  _rFlux[f] = T_Scalar(0);
211  _dFluxdFlux[f] = NumTypeTraits<Diag>::getNegativeUnity();
212  }
BaseGenericBCS::_dFluxdFlux
BBMatrix & _dFluxdFlux
Definition: GenericBCS.h:456
BaseGenericBCS::_ibType
const IntArray & _ibType
Definition: GenericBCS.h:448
BaseGenericBCS::_assembler
CCAssembler & _assembler
Definition: GenericBCS.h:457
FluxJacobianMatrix::setCoeffR
void setCoeffR(const int f, const OffDiag &c)
Definition: FluxJacobianMatrix.h:68
CRMatrix::PairWiseAssembler::getCoeff10
OffDiag & getCoeff10(const int np)
Definition: CRMatrix.h:131
BaseGenericBCS::_faceCells
const CRConnectivity & _faceCells
Definition: GenericBCS.h:449
BaseGenericBCS::_rFlux
XArray & _rFlux
Definition: GenericBCS.h:462
FluxJacobianMatrix::setCoeffL
void setCoeffL(const int f, const OffDiag &c)
Definition: FluxJacobianMatrix.h:67
BaseGenericBCS::_x
XArray & _x
Definition: GenericBCS.h:459
BaseGenericBCS::T_Scalar
NumTypeTraits< X >::T_Scalar T_Scalar
Definition: GenericBCS.h:26
BaseGenericBCS::_r
XArray & _r
Definition: GenericBCS.h:460
CRMatrix::PairWiseAssembler::getCoeff01
OffDiag & getCoeff01(const int np)
Definition: CRMatrix.h:126
CRMatrix::setBoundary
void setBoundary(const int nr)
Definition: CRMatrix.h:1056
BaseGenericBCS::_flux
XArray & _flux
Definition: GenericBCS.h:461
BaseGenericBCS::_dFluxdX
FMatrix & _dFluxdX
Definition: GenericBCS.h:455
BaseGenericBCS::_dRdXDiag
DiagArray & _dRdXDiag
Definition: GenericBCS.h:458
BaseGenericBCS::_dRdX
CCMatrix & _dRdX
Definition: GenericBCS.h:454
template<class X, class Diag, class OffDiag>
void BaseGenericBCS< X, Diag, OffDiag >::applyFlowBC ( const TArray &  convFlux,
const X &  bValue
) const
inline

Definition at line 418 of file GenericBCS.h.

419  {
420  for(int f=0; f<_faces.getCount(); f++)
421  if (convFlux[f] < 0)
422  applyDirichletBC(f,bValue);
423  else
424  applyExtrapolationBC(f);
425  }
BaseGenericBCS::_faces
const StorageSite & _faces
Definition: GenericBCS.h:446
BaseGenericBCS::applyDirichletBC
void applyDirichletBC(int f, const X &bValue) const
Definition: GenericBCS.h:77
StorageSite::getCount
int getCount() const
Definition: StorageSite.h:39
BaseGenericBCS::applyExtrapolationBC
void applyExtrapolationBC() const
Definition: GenericBCS.h:172
template<class X, class Diag, class OffDiag>
void BaseGenericBCS< X, Diag, OffDiag >::applyInterfaceBC ( const int  f) const
inline

Definition at line 325 of file GenericBCS.h.

Referenced by ThermalModel< T >::Impl::linearize(), FractureModel< T >::Impl::linearize(), VacancyModel< T >::Impl::linearize(), SpeciesModel< T >::Impl::linearize(), ElectricModel< T >::Impl::linearizeChargeTransport(), KeModel< T >::Impl::linearizedissipation(), ElectricModel< T >::Impl::linearizeElectroStatics(), KeModel< T >::Impl::linearizeenergy(), FlowModel< T >::Impl::linearizeMomentum(), BatteryModel< T >::Impl::linearizePC(), BatteryModel< T >::Impl::linearizePC_Thermal(), BatteryModel< T >::Impl::linearizePotential(), BatteryModel< T >::Impl::linearizeSpecies(), and BatteryModel< T >::Impl::linearizeThermal().

326  {
327  // the boundary cell could be either c0 or c1 at an interface
328  int cb = _faceCells(f,1);
329  T_Scalar sign(NumTypeTraits<T_Scalar>::getUnity());
330  if (cb < _cells.getSelfCount())
331  {
332  cb = _faceCells(f,0);
333  sign *= -1.0;
334  }
335
336
337  // the current value of flux and its Jacobians
338  const X fluxInterior = -_r[cb];
339  const OffDiag dFluxdXC0 = -sign*_assembler.getCoeff10(f);
340  const OffDiag dFluxdXC1 = sign*_assembler.getCoeff01(f);
341
342
343  _r[cb] = T_Scalar(0);
344
345  if (sign>0)
346  _assembler.getCoeff10(f) = NumTypeTraits<OffDiag>::getZero();
347  else
348  _assembler.getCoeff01(f) = NumTypeTraits<OffDiag>::getZero();
349
350  //setup the equation for the boundary flux correction
351  _dFluxdX.setCoeffL(f,dFluxdXC0);
352  _dFluxdX.setCoeffR(f,dFluxdXC1);
353  _flux[f] = fluxInterior;
354  _rFlux[f] = T_Scalar(0);
355  _dFluxdFlux[f] = NumTypeTraits<Diag>::getNegativeUnity();
356  }
StorageSite::getSelfCount
int getSelfCount() const
Definition: StorageSite.h:40
BaseGenericBCS::_dFluxdFlux
BBMatrix & _dFluxdFlux
Definition: GenericBCS.h:456
BaseGenericBCS::_assembler
CCAssembler & _assembler
Definition: GenericBCS.h:457
FluxJacobianMatrix::setCoeffR
void setCoeffR(const int f, const OffDiag &c)
Definition: FluxJacobianMatrix.h:68
CRMatrix::PairWiseAssembler::getCoeff10
OffDiag & getCoeff10(const int np)
Definition: CRMatrix.h:131
BaseGenericBCS::_faceCells
const CRConnectivity & _faceCells
Definition: GenericBCS.h:449
BaseGenericBCS::_rFlux
XArray & _rFlux
Definition: GenericBCS.h:462
FluxJacobianMatrix::setCoeffL
void setCoeffL(const int f, const OffDiag &c)
Definition: FluxJacobianMatrix.h:67
BaseGenericBCS::T_Scalar
NumTypeTraits< X >::T_Scalar T_Scalar
Definition: GenericBCS.h:26
BaseGenericBCS::_r
XArray & _r
Definition: GenericBCS.h:460
CRMatrix::PairWiseAssembler::getCoeff01
OffDiag & getCoeff01(const int np)
Definition: CRMatrix.h:126
BaseGenericBCS::_cells
const StorageSite & _cells
Definition: GenericBCS.h:447
BaseGenericBCS::_flux
XArray & _flux
Definition: GenericBCS.h:461
BaseGenericBCS::_dFluxdX
FMatrix & _dFluxdX
Definition: GenericBCS.h:455
template<class X, class Diag, class OffDiag>
void BaseGenericBCS< X, Diag, OffDiag >::applyInterfaceBC ( ) const
inline

Definition at line 358 of file GenericBCS.h.

Referenced by BaseGenericBCS< Vector< T, N >, DiagonalTensor< T, N >, T >::applyInterfaceBC().

359  {
360  for(int i=0; i<_faces.getCount(); i++)
361  applyInterfaceBC(i);
362  }
BaseGenericBCS::applyInterfaceBC
void applyInterfaceBC() const
Definition: GenericBCS.h:358
BaseGenericBCS::_faces
const StorageSite & _faces
Definition: GenericBCS.h:446
StorageSite::getCount
int getCount() const
Definition: StorageSite.h:39
template<class X, class Diag, class OffDiag>
void BaseGenericBCS< X, Diag, OffDiag >::applyMixedBC ( const int  f,
const X &  hCoeff,
const X &  emissivity,
const X &  Xinf
) const
inline

Definition at line 290 of file GenericBCS.h.

292  {
293  const int c0 = _faceCells(f,0);
294  const int c1 = _faceCells(f,1);
295
296  if (_ibType[c0] != Mesh::IBTYPE_FLUID)
297  return;
298  //The value of the Stefan-Boltzman constant
299  double s_b_const = 5.670373E-8;
300
301  // the current value of flux and its Jacobians
302  const X fluxInterior = -_r[c1];
303
304  // flux based on current boundary value
305  const X fluxBoundary = (-emissivity*s_b_const*(_x[c1]*_x[c1]*_x[c1]*_x[c1]-Xinf*Xinf*Xinf*Xinf)-hCoeff*(_x[c1]-Xinf))*_faceAreaMag[f];
306
307  const X dFlux = fluxBoundary-fluxInterior;
308
309  _r[c1] = dFlux;
310
311  // add this to complete the Jacobian wrt boundary value
312  _dRdXDiag[c1] -= (4*emissivity*s_b_const*_x[c1]*_x[c1]*_x[c1]+hCoeff)*_faceAreaMag[f];
313
314  // mark this row as a "boundary" row so that we will update it
315  // after the overall system is solved
316  _dRdX.setBoundary(c1);
317
318  _flux[f] = fluxBoundary;
319  _rFlux[f] = 0;
320  _dFluxdX.setCoeffL(f,NumTypeTraits<X>::getZero());
321  _dFluxdX.setCoeffR(f,-4*emissivity*s_b_const*_x[c1]*_x[c1]*_x[c1]*_faceAreaMag[f]);
322  _dFluxdFlux[f] = NumTypeTraits<Diag>::getNegativeUnity();
323  }
BaseGenericBCS::_dFluxdFlux
BBMatrix & _dFluxdFlux
Definition: GenericBCS.h:456
BaseGenericBCS::_faceAreaMag
const TArray & _faceAreaMag
Definition: GenericBCS.h:464
BaseGenericBCS::_ibType
const IntArray & _ibType
Definition: GenericBCS.h:448
FluxJacobianMatrix::setCoeffR
void setCoeffR(const int f, const OffDiag &c)
Definition: FluxJacobianMatrix.h:68
BaseGenericBCS::_faceCells
const CRConnectivity & _faceCells
Definition: GenericBCS.h:449
BaseGenericBCS::_rFlux
XArray & _rFlux
Definition: GenericBCS.h:462
FluxJacobianMatrix::setCoeffL
void setCoeffL(const int f, const OffDiag &c)
Definition: FluxJacobianMatrix.h:67
BaseGenericBCS::_x
XArray & _x
Definition: GenericBCS.h:459
BaseGenericBCS::_r
XArray & _r
Definition: GenericBCS.h:460
CRMatrix::setBoundary
void setBoundary(const int nr)
Definition: CRMatrix.h:1056
BaseGenericBCS::_flux
XArray & _flux
Definition: GenericBCS.h:461
BaseGenericBCS::_dFluxdX
FMatrix & _dFluxdX
Definition: GenericBCS.h:455
BaseGenericBCS::_dRdXDiag
DiagArray & _dRdXDiag
Definition: GenericBCS.h:458
BaseGenericBCS::_dRdX
CCMatrix & _dRdX
Definition: GenericBCS.h:454
template<class X, class Diag, class OffDiag>
void BaseGenericBCS< X, Diag, OffDiag >::applyNeumannBC ( const int  f,
const X &  specifiedFlux
) const
inline

Definition at line 129 of file GenericBCS.h.

Referenced by BaseGenericBCS< Vector< T, N >, DiagonalTensor< T, N >, T >::applyNeumannBC().

131  {
132  const int c0 = _faceCells(f,0);
133  const int c1 = _faceCells(f,1);
134
135  if (_ibType[c0] != Mesh::IBTYPE_FLUID)
136  return;
137  // the current value of flux and its Jacobians
138  const X fluxB = -_r[c1];
139
140
141  // since we know the boundary flux, compute the boundary flux
142  // correction and add it to the c0 residual; also eliminate
143  // coeff to the boundary cell and remove it from the ap coeff
144
145  const X dFlux = specifiedFlux*_faceAreaMag[f] - fluxB;
146  // setup the equation for the boundary value; the coefficients
147  // are already computed so just need to set the rhs
148  _r[c1] = dFlux;
149
150  // mark this row as a "boundary" row so that we will update it
151  // after the overall system is solved
152  _dRdX.setBoundary(c1);
153
154  // fix the boundary flux to the specified value
155  _flux[f] = specifiedFlux*_faceAreaMag[f];
156  _dFluxdFlux[f] = NumTypeTraits<Diag>::getNegativeUnity();
157  }
BaseGenericBCS::_dFluxdFlux
BBMatrix & _dFluxdFlux
Definition: GenericBCS.h:456
BaseGenericBCS::_faceAreaMag
const TArray & _faceAreaMag
Definition: GenericBCS.h:464
BaseGenericBCS::_ibType
const IntArray & _ibType
Definition: GenericBCS.h:448
BaseGenericBCS::_faceCells
const CRConnectivity & _faceCells
Definition: GenericBCS.h:449
BaseGenericBCS::_r
XArray & _r
Definition: GenericBCS.h:460
CRMatrix::setBoundary
void setBoundary(const int nr)
Definition: CRMatrix.h:1056
BaseGenericBCS::_flux
XArray & _flux
Definition: GenericBCS.h:461
BaseGenericBCS::_dRdX
CCMatrix & _dRdX
Definition: GenericBCS.h:454
template<class X, class Diag, class OffDiag>
void BaseGenericBCS< X, Diag, OffDiag >::applyNeumannBC ( const X &  bFlux) const
inline

Definition at line 160 of file GenericBCS.h.

161  {
162  for(int i=0; i<_faces.getCount(); i++)
163  applyNeumannBC(i,bFlux);
164  }
BaseGenericBCS::_faces
const StorageSite & _faces
Definition: GenericBCS.h:446
BaseGenericBCS::applyNeumannBC
void applyNeumannBC(const int f, const X &specifiedFlux) const
Definition: GenericBCS.h:129
StorageSite::getCount
int getCount() const
Definition: StorageSite.h:39
template<class X, class Diag, class OffDiag>
void BaseGenericBCS< X, Diag, OffDiag >::applyNeumannBC ( const FloatValEvaluator< X > &  bFlux) const
inline

Definition at line 166 of file GenericBCS.h.

167  {
168  for(int i=0; i<_faces.getCount(); i++)
169  applyNeumannBC(i,bFlux[i]);
170  }
BaseGenericBCS::_faces
const StorageSite & _faces
Definition: GenericBCS.h:446
BaseGenericBCS::applyNeumannBC
void applyNeumannBC(const int f, const X &specifiedFlux) const
Definition: GenericBCS.h:129
StorageSite::getCount
int getCount() const
Definition: StorageSite.h:39
template<class X, class Diag, class OffDiag>
void BaseGenericBCS< X, Diag, OffDiag >::applyNonzeroDiagBC ( ) const
inline

Definition at line 427 of file GenericBCS.h.

Referenced by BaseGenericBCS< Vector< T, N >, DiagonalTensor< T, N >, T >::applyNonzeroDiagBC().

428  {
429  for(int i=0; i<_faces.getCount(); i++)
430  applyNonzeroDiagBC(i);
431  }
BaseGenericBCS::applyNonzeroDiagBC
void applyNonzeroDiagBC() const
Definition: GenericBCS.h:427
BaseGenericBCS::_faces
const StorageSite & _faces
Definition: GenericBCS.h:446
StorageSite::getCount
int getCount() const
Definition: StorageSite.h:39
template<class X, class Diag, class OffDiag>
void BaseGenericBCS< X, Diag, OffDiag >::applyNonzeroDiagBC ( int  f) const
inline

Definition at line 433 of file GenericBCS.h.

434  {
435  const int c0 = _faceCells(f,0);
436  const int c1 = _faceCells(f,1);
437
438  if (_ibType[c0] != Mesh::IBTYPE_FLUID)
439  return;
440
441  _dRdXDiag[c1][0] = T_Scalar(-1.0);
442  }
BaseGenericBCS::_ibType
const IntArray & _ibType
Definition: GenericBCS.h:448
BaseGenericBCS::_faceCells
const CRConnectivity & _faceCells
Definition: GenericBCS.h:449
BaseGenericBCS::T_Scalar
NumTypeTraits< X >::T_Scalar T_Scalar
Definition: GenericBCS.h:26
BaseGenericBCS::_dRdXDiag
DiagArray & _dRdXDiag
Definition: GenericBCS.h:458
template<class X, class Diag, class OffDiag>
void BaseGenericBCS< X, Diag, OffDiag >::applyRadiationBC ( const int  f,
const X &  emissivity,
const X &  Xinf
) const
inline

Definition at line 253 of file GenericBCS.h.

255  {
256  const int c0 = _faceCells(f,0);
257  const int c1 = _faceCells(f,1);
258
259  if (_ibType[c0] != Mesh::IBTYPE_FLUID)
260  return;
261  //The value of the Stefan-Boltzman constant
262  double s_b_const = 5.670373E-8;
263
264  // the current value of flux and its Jacobians
265  const X fluxInterior = -_r[c1];
266
267  // flux based on current boundary value
268  const X fluxBoundary = -emissivity*s_b_const*\
269  (_x[c1]*_x[c1]*_x[c1]*_x[c1]-Xinf*Xinf*Xinf*Xinf)*_faceAreaMag[f];
270
271  const X dFlux = fluxBoundary-fluxInterior;
272
273  _r[c1] = dFlux;
274
275  // add this to complete the Jacobian wrt boundary value
276  _dRdXDiag[c1] -= \
277  4*emissivity*s_b_const*_x[c1]*_x[c1]*_x[c1]*_faceAreaMag[f];
278
279  // mark this row as a "boundary" row so that we will update it
280  // after the overall system is solved
281  _dRdX.setBoundary(c1);
282
283  _flux[f] = fluxBoundary;
284  _rFlux[f] = 0;
285  _dFluxdX.setCoeffL(f,NumTypeTraits<X>::getZero());
286  _dFluxdX.setCoeffR(f,-4*emissivity*s_b_const*_x[c1]*_x[c1]*_x[c1]*_faceAreaMag[f]);
287  _dFluxdFlux[f] = NumTypeTraits<Diag>::getNegativeUnity();
288  }
BaseGenericBCS::_dFluxdFlux
BBMatrix & _dFluxdFlux
Definition: GenericBCS.h:456
BaseGenericBCS::_faceAreaMag
const TArray & _faceAreaMag
Definition: GenericBCS.h:464
BaseGenericBCS::_ibType
const IntArray & _ibType
Definition: GenericBCS.h:448
FluxJacobianMatrix::setCoeffR
void setCoeffR(const int f, const OffDiag &c)
Definition: FluxJacobianMatrix.h:68
BaseGenericBCS::_faceCells
const CRConnectivity & _faceCells
Definition: GenericBCS.h:449
BaseGenericBCS::_rFlux
XArray & _rFlux
Definition: GenericBCS.h:462
FluxJacobianMatrix::setCoeffL
void setCoeffL(const int f, const OffDiag &c)
Definition: FluxJacobianMatrix.h:67
BaseGenericBCS::_x
XArray & _x
Definition: GenericBCS.h:459
BaseGenericBCS::_r
XArray & _r
Definition: GenericBCS.h:460
CRMatrix::setBoundary
void setBoundary(const int nr)
Definition: CRMatrix.h:1056
BaseGenericBCS::_flux
XArray & _flux
Definition: GenericBCS.h:461
BaseGenericBCS::_dFluxdX
FMatrix & _dFluxdX
Definition: GenericBCS.h:455
BaseGenericBCS::_dRdXDiag
DiagArray & _dRdXDiag
Definition: GenericBCS.h:458
BaseGenericBCS::_dRdX
CCMatrix & _dRdX
Definition: GenericBCS.h:454

Member Data Documentation

template<class X, class Diag, class OffDiag>
const Field& BaseGenericBCS< X, Diag, OffDiag >::_areaField
protected

Definition at line 465 of file GenericBCS.h.

template<class X, class Diag, class OffDiag>
const Field& BaseGenericBCS< X, Diag, OffDiag >::_areaMagField
protected

Definition at line 463 of file GenericBCS.h.

template<class X, class Diag, class OffDiag>
CCAssembler& BaseGenericBCS< X, Diag, OffDiag >::_assembler
protected

Definition at line 457 of file GenericBCS.h.

Referenced by BaseGenericBCS< Vector< T, N >, DiagonalTensor< T, N >, T >::applyDirichletBC(), BaseGenericBCS< Vector< T, N >, DiagonalTensor< T, N >, T >::applyExtrapolationBC(), BaseGenericBCS< Vector< T, N >, DiagonalTensor< T, N >, T >::applyInterfaceBC(), GenericBCS< X, Diag, OffDiag >::applySymmetryBC(), GenericBCS< Vector< T, N >, DiagonalTensor< T, N >, T >::applySymmetryBC(), GenericBCS< Vector< T, N >, DiagonalTensor< T, N >, DiagonalTensor< T, N > >::applySymmetryBC(), and GenericBCS< Vector< T, N >, SquareTensor< T, N >, SquareTensor< T, N > >::applySymmetryBC().

template<class X, class Diag, class OffDiag>
const StorageSite& BaseGenericBCS< X, Diag, OffDiag >::_cells
protected

Definition at line 447 of file GenericBCS.h.

Referenced by BaseGenericBCS< Vector< T, N >, DiagonalTensor< T, N >, T >::applyInterfaceBC().

template<class X, class Diag, class OffDiag>
BBMatrix& BaseGenericBCS< X, Diag, OffDiag >::_dFluxdFlux
protected

Definition at line 456 of file GenericBCS.h.

Referenced by BaseGenericBCS< Vector< T, N >, DiagonalTensor< T, N >, T >::applyConvectionBC(), BaseGenericBCS< Vector< T, N >, DiagonalTensor< T, N >, T >::applyDielectricInterfaceBC(), BaseGenericBCS< Vector< T, N >, DiagonalTensor< T, N >, T >::applyDirichletBC(), BaseGenericBCS< Vector< T, N >, DiagonalTensor< T, N >, T >::applyExtrapolationBC(), BaseGenericBCS< Vector< T, N >, DiagonalTensor< T, N >, T >::applyInterfaceBC(), BaseGenericBCS< Vector< T, N >, DiagonalTensor< T, N >, T >::applyMixedBC(), BaseGenericBCS< Vector< T, N >, DiagonalTensor< T, N >, T >::applyNeumannBC(), BaseGenericBCS< Vector< T, N >, DiagonalTensor< T, N >, T >::applyRadiationBC(), GenericBCS< X, Diag, OffDiag >::applySymmetryBC(), GenericBCS< Vector< T, N >, DiagonalTensor< T, N >, T >::applySymmetryBC(), GenericBCS< Vector< T, N >, DiagonalTensor< T, N >, DiagonalTensor< T, N > >::applySymmetryBC(), and GenericBCS< Vector< T, N >, SquareTensor< T, N >, SquareTensor< T, N > >::applySymmetryBC().

template<class X, class Diag, class OffDiag>
FMatrix& BaseGenericBCS< X, Diag, OffDiag >::_dFluxdX
protected

Definition at line 455 of file GenericBCS.h.

Referenced by BaseGenericBCS< Vector< T, N >, DiagonalTensor< T, N >, T >::applyConvectionBC(), BaseGenericBCS< Vector< T, N >, DiagonalTensor< T, N >, T >::applyDielectricInterfaceBC(), BaseGenericBCS< Vector< T, N >, DiagonalTensor< T, N >, T >::applyDirichletBC(), BaseGenericBCS< Vector< T, N >, DiagonalTensor< T, N >, T >::applyExtrapolationBC(), BaseGenericBCS< Vector< T, N >, DiagonalTensor< T, N >, T >::applyInterfaceBC(), BaseGenericBCS< Vector< T, N >, DiagonalTensor< T, N >, T >::applyMixedBC(), BaseGenericBCS< Vector< T, N >, DiagonalTensor< T, N >, T >::applyRadiationBC(), GenericBCS< Vector< T, N >, DiagonalTensor< T, N >, T >::applySymmetryBC(), and GenericBCS< Vector< T, N >, DiagonalTensor< T, N >, DiagonalTensor< T, N > >::applySymmetryBC().

template<class X, class Diag, class OffDiag>
CCMatrix& BaseGenericBCS< X, Diag, OffDiag >::_dRdX
protected

Definition at line 454 of file GenericBCS.h.

Referenced by BaseGenericBCS< Vector< T, N >, DiagonalTensor< T, N >, T >::applyConvectionBC(), BaseGenericBCS< Vector< T, N >, DiagonalTensor< T, N >, T >::applyDielectricInterfaceBC(), BaseGenericBCS< Vector< T, N >, DiagonalTensor< T, N >, T >::applyExtrapolationBC(), BaseGenericBCS< Vector< T, N >, DiagonalTensor< T, N >, T >::applyMixedBC(), BaseGenericBCS< Vector< T, N >, DiagonalTensor< T, N >, T >::applyNeumannBC(), BaseGenericBCS< Vector< T, N >, DiagonalTensor< T, N >, T >::applyRadiationBC(), GenericBCS< X, Diag, OffDiag >::applySymmetryBC(), GenericBCS< Vector< T, N >, DiagonalTensor< T, N >, T >::applySymmetryBC(), GenericBCS< Vector< T, N >, DiagonalTensor< T, N >, DiagonalTensor< T, N > >::applySymmetryBC(), and GenericBCS< Vector< T, N >, SquareTensor< T, N >, SquareTensor< T, N > >::applySymmetryBC().

template<class X, class Diag, class OffDiag>
DiagArray& BaseGenericBCS< X, Diag, OffDiag >::_dRdXDiag
protected

Definition at line 458 of file GenericBCS.h.

Referenced by BaseGenericBCS< Vector< T, N >, DiagonalTensor< T, N >, T >::applyConvectionBC(), BaseGenericBCS< Vector< T, N >, DiagonalTensor< T, N >, T >::applyDielectricInterfaceBC(), BaseGenericBCS< Vector< T, N >, DiagonalTensor< T, N >, T >::applyDirichletBC(), BaseGenericBCS< Vector< T, N >, DiagonalTensor< T, N >, T >::applyExtrapolationBC(), BaseGenericBCS< Vector< T, N >, DiagonalTensor< T, N >, T >::applyMixedBC(), BaseGenericBCS< Vector< T, N >, DiagonalTensor< T, N >, T >::applyNonzeroDiagBC(), BaseGenericBCS< Vector< T, N >, DiagonalTensor< T, N >, T >::applyRadiationBC(), GenericBCS< X, Diag, OffDiag >::applySymmetryBC(), GenericBCS< Vector< T, N >, DiagonalTensor< T, N >, T >::applySymmetryBC(), GenericBCS< Vector< T, N >, DiagonalTensor< T, N >, DiagonalTensor< T, N > >::applySymmetryBC(), and GenericBCS< Vector< T, N >, SquareTensor< T, N >, SquareTensor< T, N > >::applySymmetryBC().

template<class X, class Diag, class OffDiag>
const VectorT3Array& BaseGenericBCS< X, Diag, OffDiag >::_faceArea
protected

Definition at line 466 of file GenericBCS.h.

Referenced by GenericBCS< Vector< T, N >, DiagonalTensor< T, N >, T >::applySymmetryBC(), GenericBCS< Vector< T, N >, DiagonalTensor< T, N >, DiagonalTensor< T, N > >::applySymmetryBC(), and GenericBCS< Vector< T, N >, SquareTensor< T, N >, SquareTensor< T, N > >::applySymmetryBC().

template<class X, class Diag, class OffDiag>
const TArray& BaseGenericBCS< X, Diag, OffDiag >::_faceAreaMag
protected

Definition at line 464 of file GenericBCS.h.

Referenced by BaseGenericBCS< Vector< T, N >, DiagonalTensor< T, N >, T >::applyConvectionBC(), BaseGenericBCS< Vector< T, N >, DiagonalTensor< T, N >, T >::applyDielectricInterfaceBC(), BaseGenericBCS< Vector< T, N >, DiagonalTensor< T, N >, T >::applyMixedBC(), BaseGenericBCS< Vector< T, N >, DiagonalTensor< T, N >, T >::applyNeumannBC(), BaseGenericBCS< Vector< T, N >, DiagonalTensor< T, N >, T >::applyRadiationBC(), GenericBCS< Vector< T, N >, DiagonalTensor< T, N >, T >::applySymmetryBC(), GenericBCS< Vector< T, N >, DiagonalTensor< T, N >, DiagonalTensor< T, N > >::applySymmetryBC(), and GenericBCS< Vector< T, N >, SquareTensor< T, N >, SquareTensor< T, N > >::applySymmetryBC().

template<class X, class Diag, class OffDiag>
const CRConnectivity& BaseGenericBCS< X, Diag, OffDiag >::_faceCells
protected

Definition at line 449 of file GenericBCS.h.

Referenced by BaseGenericBCS< Vector< T, N >, DiagonalTensor< T, N >, T >::applyConvectionBC(), BaseGenericBCS< Vector< T, N >, DiagonalTensor< T, N >, T >::applyDielectricInterfaceBC(), BaseGenericBCS< Vector< T, N >, DiagonalTensor< T, N >, T >::applyDirichletBC(), BaseGenericBCS< Vector< T, N >, DiagonalTensor< T, N >, T >::applyExtrapolationBC(), BaseGenericBCS< Vector< T, N >, DiagonalTensor< T, N >, T >::applyInterfaceBC(), BaseGenericBCS< Vector< T, N >, DiagonalTensor< T, N >, T >::applyMixedBC(), BaseGenericBCS< Vector< T, N >, DiagonalTensor< T, N >, T >::applyNeumannBC(), BaseGenericBCS< Vector< T, N >, DiagonalTensor< T, N >, T >::applyNonzeroDiagBC(), BaseGenericBCS< Vector< T, N >, DiagonalTensor< T, N >, T >::applyRadiationBC(), GenericBCS< X, Diag, OffDiag >::applySymmetryBC(), GenericBCS< Vector< T, N >, DiagonalTensor< T, N >, T >::applySymmetryBC(), GenericBCS< Vector< T, N >, DiagonalTensor< T, N >, DiagonalTensor< T, N > >::applySymmetryBC(), and GenericBCS< Vector< T, N >, SquareTensor< T, N >, SquareTensor< T, N > >::applySymmetryBC().

template<class X, class Diag, class OffDiag>
const StorageSite& BaseGenericBCS< X, Diag, OffDiag >::_faces
protected

Definition at line 446 of file GenericBCS.h.

Referenced by BaseGenericBCS< Vector< T, N >, DiagonalTensor< T, N >, T >::applyConvectionBC(), BaseGenericBCS< Vector< T, N >, DiagonalTensor< T, N >, T >::applyDielectricInterfaceBC(), BaseGenericBCS< Vector< T, N >, DiagonalTensor< T, N >, T >::applyDirichletBC(), BaseGenericBCS< Vector< T, N >, DiagonalTensor< T, N >, T >::applyExtrapolationBC(), BaseGenericBCS< Vector< T, N >, DiagonalTensor< T, N >, T >::applyFlowBC(), BaseGenericBCS< Vector< T, N >, DiagonalTensor< T, N >, T >::applyInterfaceBC(), BaseGenericBCS< Vector< T, N >, DiagonalTensor< T, N >, T >::applyNeumannBC(), BaseGenericBCS< Vector< T, N >, DiagonalTensor< T, N >, T >::applyNonzeroDiagBC(), GenericBCS< X, Diag, OffDiag >::applySymmetryBC(), GenericBCS< Vector< T, N >, DiagonalTensor< T, N >, T >::applySymmetryBC(), GenericBCS< Vector< T, N >, DiagonalTensor< T, N >, DiagonalTensor< T, N > >::applySymmetryBC(), and GenericBCS< Vector< T, N >, SquareTensor< T, N >, SquareTensor< T, N > >::applySymmetryBC().

template<class X, class Diag, class OffDiag>
XArray& BaseGenericBCS< X, Diag, OffDiag >::_flux
protected

Definition at line 461 of file GenericBCS.h.

Referenced by BaseGenericBCS< Vector< T, N >, DiagonalTensor< T, N >, T >::applyConvectionBC(), BaseGenericBCS< Vector< T, N >, DiagonalTensor< T, N >, T >::applyDielectricInterfaceBC(), BaseGenericBCS< Vector< T, N >, DiagonalTensor< T, N >, T >::applyDirichletBC(), BaseGenericBCS< Vector< T, N >, DiagonalTensor< T, N >, T >::applyExtrapolationBC(), BaseGenericBCS< Vector< T, N >, DiagonalTensor< T, N >, T >::applyInterfaceBC(), BaseGenericBCS< Vector< T, N >, DiagonalTensor< T, N >, T >::applyMixedBC(), BaseGenericBCS< Vector< T, N >, DiagonalTensor< T, N >, T >::applyNeumannBC(), BaseGenericBCS< Vector< T, N >, DiagonalTensor< T, N >, T >::applyRadiationBC(), GenericBCS< X, Diag, OffDiag >::applySymmetryBC(), GenericBCS< Vector< T, N >, DiagonalTensor< T, N >, T >::applySymmetryBC(), and GenericBCS< Vector< T, N >, SquareTensor< T, N >, SquareTensor< T, N > >::applySymmetryBC().

template<class X, class Diag, class OffDiag>
const Field& BaseGenericBCS< X, Diag, OffDiag >::_fluxField
protected

Definition at line 451 of file GenericBCS.h.

template<class X, class Diag, class OffDiag>
const MultiField::ArrayIndex BaseGenericBCS< X, Diag, OffDiag >::_fluxIndex
protected

Definition at line 453 of file GenericBCS.h.

template<class X, class Diag, class OffDiag>
const IntArray& BaseGenericBCS< X, Diag, OffDiag >::_ibType
protected

Definition at line 448 of file GenericBCS.h.

Referenced by BaseGenericBCS< Vector< T, N >, DiagonalTensor< T, N >, T >::applyConvectionBC(), BaseGenericBCS< Vector< T, N >, DiagonalTensor< T, N >, T >::applyDielectricInterfaceBC(), BaseGenericBCS< Vector< T, N >, DiagonalTensor< T, N >, T >::applyDirichletBC(), BaseGenericBCS< Vector< T, N >, DiagonalTensor< T, N >, T >::applyExtrapolationBC(), BaseGenericBCS< Vector< T, N >, DiagonalTensor< T, N >, T >::applyMixedBC(), BaseGenericBCS< Vector< T, N >, DiagonalTensor< T, N >, T >::applyNeumannBC(), BaseGenericBCS< Vector< T, N >, DiagonalTensor< T, N >, T >::applyNonzeroDiagBC(), and BaseGenericBCS< Vector< T, N >, DiagonalTensor< T, N >, T >::applyRadiationBC().

template<class X, class Diag, class OffDiag>
const bool BaseGenericBCS< X, Diag, OffDiag >::_is2D
protected

Definition at line 467 of file GenericBCS.h.

Referenced by BaseGenericBCS< Vector< T, N >, DiagonalTensor< T, N >, T >::applyDielectricInterfaceBC().

template<class X, class Diag, class OffDiag>
XArray& BaseGenericBCS< X, Diag, OffDiag >::_r
protected

Definition at line 460 of file GenericBCS.h.

Referenced by BaseGenericBCS< Vector< T, N >, DiagonalTensor< T, N >, T >::applyConvectionBC(), BaseGenericBCS< Vector< T, N >, DiagonalTensor< T, N >, T >::applyDielectricInterfaceBC(), BaseGenericBCS< Vector< T, N >, DiagonalTensor< T, N >, T >::applyDirichletBC(), BaseGenericBCS< Vector< T, N >, DiagonalTensor< T, N >, T >::applyExtrapolationBC(), BaseGenericBCS< Vector< T, N >, DiagonalTensor< T, N >, T >::applyInterfaceBC(), BaseGenericBCS< Vector< T, N >, DiagonalTensor< T, N >, T >::applyMixedBC(), BaseGenericBCS< Vector< T, N >, DiagonalTensor< T, N >, T >::applyNeumannBC(), BaseGenericBCS< Vector< T, N >, DiagonalTensor< T, N >, T >::applyRadiationBC(), GenericBCS< X, Diag, OffDiag >::applySymmetryBC(), GenericBCS< Vector< T, N >, DiagonalTensor< T, N >, T >::applySymmetryBC(), GenericBCS< Vector< T, N >, DiagonalTensor< T, N >, DiagonalTensor< T, N > >::applySymmetryBC(), and GenericBCS< Vector< T, N >, SquareTensor< T, N >, SquareTensor< T, N > >::applySymmetryBC().

template<class X, class Diag, class OffDiag>
XArray& BaseGenericBCS< X, Diag, OffDiag >::_rFlux
protected

Definition at line 462 of file GenericBCS.h.

Referenced by BaseGenericBCS< Vector< T, N >, DiagonalTensor< T, N >, T >::applyConvectionBC(), BaseGenericBCS< Vector< T, N >, DiagonalTensor< T, N >, T >::applyDielectricInterfaceBC(), BaseGenericBCS< Vector< T, N >, DiagonalTensor< T, N >, T >::applyDirichletBC(), BaseGenericBCS< Vector< T, N >, DiagonalTensor< T, N >, T >::applyExtrapolationBC(), BaseGenericBCS< Vector< T, N >, DiagonalTensor< T, N >, T >::applyInterfaceBC(), BaseGenericBCS< Vector< T, N >, DiagonalTensor< T, N >, T >::applyMixedBC(), BaseGenericBCS< Vector< T, N >, DiagonalTensor< T, N >, T >::applyRadiationBC(), GenericBCS< X, Diag, OffDiag >::applySymmetryBC(), GenericBCS< Vector< T, N >, DiagonalTensor< T, N >, T >::applySymmetryBC(), and GenericBCS< Vector< T, N >, SquareTensor< T, N >, SquareTensor< T, N > >::applySymmetryBC().

template<class X, class Diag, class OffDiag>
const Field& BaseGenericBCS< X, Diag, OffDiag >::_varField
protected

Definition at line 450 of file GenericBCS.h.

template<class X, class Diag, class OffDiag>
XArray& BaseGenericBCS< X, Diag, OffDiag >::_x
protected

Definition at line 459 of file GenericBCS.h.

Referenced by BaseGenericBCS< Vector< T, N >, DiagonalTensor< T, N >, T >::applyConvectionBC(), BaseGenericBCS< Vector< T, N >, DiagonalTensor< T, N >, T >::applyDielectricInterfaceBC(), BaseGenericBCS< Vector< T, N >, DiagonalTensor< T, N >, T >::applyDirichletBC(), BaseGenericBCS< Vector< T, N >, DiagonalTensor< T, N >, T >::applyExtrapolationBC(), BaseGenericBCS< Vector< T, N >, DiagonalTensor< T, N >, T >::applyMixedBC(), BaseGenericBCS< Vector< T, N >, DiagonalTensor< T, N >, T >::applyRadiationBC(), GenericBCS< X, Diag, OffDiag >::applySymmetryBC(), GenericBCS< Vector< T, N >, DiagonalTensor< T, N >, T >::applySymmetryBC(), GenericBCS< Vector< T, N >, DiagonalTensor< T, N >, DiagonalTensor< T, N > >::applySymmetryBC(), and GenericBCS< Vector< T, N >, SquareTensor< T, N >, SquareTensor< T, N > >::applySymmetryBC().

template<class X, class Diag, class OffDiag>
const MultiField::ArrayIndex BaseGenericBCS< X, Diag, OffDiag >::_xIndex
protected

Definition at line 452 of file GenericBCS.h.

The documentation for this class was generated from the following file:
