#include <BatteryPC_BCS.h>

Collaboration diagram for BatteryPC_BCS< X, Diag, OffDiag >:

Public Types
typedef NumTypeTraits< X > ::T_Scalar	T_Scalar

typedef Array< T_Scalar >	TArray

typedef Array< int >	IntArray

typedef Vector< T_Scalar, 3 >	VectorT3

typedef CRMatrix< Diag, OffDiag, X >	CCMatrix

typedef CCMatrix::PairWiseAssembler	CCAssembler

typedef FluxJacobianMatrix < Diag, X >	FMatrix

typedef DiagonalMatrix< Diag, X >	BBMatrix

typedef Array< Diag >	DiagArray

typedef Array< OffDiag >	OffDiagArray

typedef Array< X >	XArray

typedef Array< VectorT3 >	VectorT3Array

Public Member Functions
	BatteryPC_BCS (const StorageSite &faces, const Mesh &mesh, const GeomFields &geomFields, Field &varField, Field &fluxField, MultiFieldMatrix &matrix, MultiField &xField, MultiField &rField)

void	applySingleEquationDirichletBC (int f, const T_Scalar &bValue, const int v) const

void	applySingleEquationDirichletBC (const FloatValEvaluator< T_Scalar > &bValue, const int v) const

void	applySingleEquationNeumannBC (const int f, const T_Scalar &specifiedFlux, const int v) const

void	applySingleEquationNeumannBC (const T_Scalar &bFlux, const int v) const

Protected Attributes
const StorageSite &	_faces

const StorageSite &	_cells

const IntArray &	_ibType

const CRConnectivity &	_faceCells

const Field &	_varField

const Field &	_fluxField

const MultiField::ArrayIndex	_xIndex

const MultiField::ArrayIndex	_fluxIndex

CCMatrix &	_dRdX

FMatrix &	_dFluxdX

BBMatrix &	_dFluxdFlux

CCAssembler &	_assembler

DiagArray &	_dRdXDiag

XArray &	_x

XArray &	_r

XArray &	_flux

XArray &	_rFlux

const Field &	_areaMagField

const TArray &	_faceAreaMag

const Field &	_areaField

const VectorT3Array &	_faceArea

const bool	_is2D

Detailed Description

template<class X, class Diag, class OffDiag>
class BatteryPC_BCS< X, Diag, OffDiag >

Definition at line 22 of file BatteryPC_BCS.h.

Member Typedef Documentation

template<class X , class Diag , class OffDiag >

typedef DiagonalMatrix<Diag,X> BatteryPC_BCS< X, Diag, OffDiag >::BBMatrix

Definition at line 37 of file BatteryPC_BCS.h.

template<class X , class Diag , class OffDiag >

typedef CCMatrix::PairWiseAssembler BatteryPC_BCS< X, Diag, OffDiag >::CCAssembler

Definition at line 34 of file BatteryPC_BCS.h.

template<class X , class Diag , class OffDiag >

typedef CRMatrix<Diag,OffDiag,X> BatteryPC_BCS< X, Diag, OffDiag >::CCMatrix

Definition at line 33 of file BatteryPC_BCS.h.

template<class X , class Diag , class OffDiag >

typedef Array<Diag> BatteryPC_BCS< X, Diag, OffDiag >::DiagArray

Definition at line 39 of file BatteryPC_BCS.h.

template<class X , class Diag , class OffDiag >

typedef FluxJacobianMatrix<Diag,X> BatteryPC_BCS< X, Diag, OffDiag >::FMatrix

Definition at line 36 of file BatteryPC_BCS.h.

template<class X , class Diag , class OffDiag >

typedef Array<int> BatteryPC_BCS< X, Diag, OffDiag >::IntArray

Definition at line 29 of file BatteryPC_BCS.h.

template<class X , class Diag , class OffDiag >

typedef Array<OffDiag> BatteryPC_BCS< X, Diag, OffDiag >::OffDiagArray

Definition at line 40 of file BatteryPC_BCS.h.

template<class X , class Diag , class OffDiag >

typedef NumTypeTraits<X>::T_Scalar BatteryPC_BCS< X, Diag, OffDiag >::T_Scalar

Definition at line 26 of file BatteryPC_BCS.h.

template<class X , class Diag , class OffDiag >

typedef Array<T_Scalar> BatteryPC_BCS< X, Diag, OffDiag >::TArray

Definition at line 28 of file BatteryPC_BCS.h.

template<class X , class Diag , class OffDiag >

typedef Vector<T_Scalar,3> BatteryPC_BCS< X, Diag, OffDiag >::VectorT3

Definition at line 31 of file BatteryPC_BCS.h.

template<class X , class Diag , class OffDiag >

typedef Array<VectorT3> BatteryPC_BCS< X, Diag, OffDiag >::VectorT3Array

Definition at line 43 of file BatteryPC_BCS.h.

template<class X , class Diag , class OffDiag >

typedef Array<X> BatteryPC_BCS< X, Diag, OffDiag >::XArray

Definition at line 42 of file BatteryPC_BCS.h.

Constructor & Destructor Documentation

template<class X , class Diag , class OffDiag >

BatteryPC_BCS< X, Diag, OffDiag >::BatteryPC_BCS	(	const StorageSite &	faces,
		const Mesh &	mesh,
		const GeomFields &	geomFields,
		Field &	varField,
		Field &	fluxField,
		MultiFieldMatrix &	matrix,
		MultiField &	xField,
		MultiField &	rField
	)

inline

Definition at line 46 of file BatteryPC_BCS.h.

                                                      :
     _faces(faces),
     _cells(mesh.getCells()),
     _ibType(dynamic_cast<const IntArray&>(geomFields.ibType[_cells])),
     _faceCells(mesh.getFaceCells(_faces)),
     _varField(varField),
     _fluxField(fluxField),
     _xIndex(&_varField,&_cells),
     _fluxIndex(&_fluxField,&_faces),
     _dRdX(dynamic_cast<CCMatrix&>(matrix.getMatrix(_xIndex,_xIndex))),
     _dFluxdX(dynamic_cast<FMatrix&>(matrix.getMatrix(_fluxIndex,_xIndex))),
     _dFluxdFlux(dynamic_cast<BBMatrix&>(matrix.getMatrix(_fluxIndex,_fluxIndex))),
     _assembler(_dRdX.getPairWiseAssembler(_faceCells)),
     _dRdXDiag(_dRdX.getDiag()),
     _x(dynamic_cast<XArray&>(xField[_xIndex])),
     _r(dynamic_cast<XArray&>(rField[_xIndex])),
     _flux(dynamic_cast<XArray&>(xField[_fluxIndex])),
     _rFlux(dynamic_cast<XArray&>(rField[_fluxIndex])),
     _areaMagField(geomFields.areaMag),
     _faceAreaMag(dynamic_cast<const TArray&>(_areaMagField[_faces])),
     _areaField(geomFields.area),
     _faceArea(dynamic_cast<const VectorT3Array&>(_areaField[_faces])),
     _is2D(mesh.getDimension()==2)
   {}

Member Function Documentation

template<class X , class Diag , class OffDiag >

void BatteryPC_BCS< X, Diag, OffDiag >::applySingleEquationDirichletBC	(	int	f,
		const T_Scalar &	bValue,
		const int	v
	)		const

inline

Definition at line 77 of file BatteryPC_BCS.h.

Referenced by BatteryPC_BCS< X, Diag, OffDiag >::applySingleEquationDirichletBC().

   {
     const int c0 = _faceCells(f,0);
     const int c1 = _faceCells(f,1);

     if (_ibType[c0] != Mesh::IBTYPE_FLUID)
       return;

     // the current value of flux and its Jacobians
     const T_Scalar fluxB = -(_r[c1])[v];
     //const T_Scalar dFluxdXC0 = -(_assembler.getCoeff10(f))(v,v);
     const OffDiag dFluxdXC0_orig = -_assembler.getCoeff10(f);
     const T_Scalar dFluxdXC1 = -(_dRdXDiag[c1])[v];
     OffDiag dRC0dXC1_orig = _assembler.getCoeff01(f);
     const T_Scalar dRC0dXC1 = dRC0dXC1_orig[v];

     // since we know the boundary value, compute the boundary
     // x correction and it's contribution to the residual for c0; we
     // can then eliminate the coefficient to the boundary cell

     const T_Scalar dXC1 = bValue - (_x[c1])[v];
     const T_Scalar dFlux = dFluxdXC1*dXC1;
     const T_Scalar dRC0 = dRC0dXC1*dXC1;
     (_r[c0])[v] += dRC0;

     (_assembler.getCoeff01(f))[v] = NumTypeTraits<T_Scalar>::getZero();

     // set the boundary value and make its correction equation an
     // identity
     (_x[c1])[v] = bValue;
     (_assembler.getCoeff10(f))[v] = NumTypeTraits<T_Scalar>::getZero();
     (_r[c1])[v] = NumTypeTraits<T_Scalar>::getZero();
     (_dRdXDiag[c1])[v] = NumTypeTraits<T_Scalar>::getNegativeUnity();

     //setup the equation for the boundary flux correction
     _dFluxdX.setCoeffL(f,dFluxdXC0_orig);
     dRC0dXC1_orig[v] = NumTypeTraits<T_Scalar>::getZero();
     _dFluxdX.setCoeffR(f,dRC0dXC1_orig);
     (_flux[f])[v] = fluxB;
     (_rFlux[f])[v] = dFlux;
     Diag _dFluxdFlux_orig = _dFluxdFlux[f];
     _dFluxdFlux_orig[v] = NumTypeTraits<T_Scalar>::getNegativeUnity();
     _dFluxdFlux[f] = _dFluxdFlux_orig;
   }

template<class X , class Diag , class OffDiag >

void BatteryPC_BCS< X, Diag, OffDiag >::applySingleEquationDirichletBC	(	const FloatValEvaluator< T_Scalar > &	bValue,
		const int	v
	)		const

inline

Definition at line 122 of file BatteryPC_BCS.h.

References BatteryPC_BCS< X, Diag, OffDiag >::_faces, BatteryPC_BCS< X, Diag, OffDiag >::applySingleEquationDirichletBC(), and StorageSite::getCount().

   {
     for(int i=0; i<_faces.getCount(); i++)
       applySingleEquationDirichletBC(i,bValue[i],v);
   }

template<class X , class Diag , class OffDiag >

void BatteryPC_BCS< X, Diag, OffDiag >::applySingleEquationNeumannBC	(	const int	f,
		const T_Scalar &	specifiedFlux,
		const int	v
	)		const

inline

Definition at line 128 of file BatteryPC_BCS.h.

References BatteryPC_BCS< X, Diag, OffDiag >::_dFluxdFlux, BatteryPC_BCS< X, Diag, OffDiag >::_dRdX, BatteryPC_BCS< X, Diag, OffDiag >::_faceAreaMag, BatteryPC_BCS< X, Diag, OffDiag >::_faceCells, BatteryPC_BCS< X, Diag, OffDiag >::_flux, BatteryPC_BCS< X, Diag, OffDiag >::_ibType, BatteryPC_BCS< X, Diag, OffDiag >::_r, Mesh::IBTYPE_FLUID, and CRMatrix< T_Diag, T_OffDiag, X >::setBoundary().

Referenced by BatteryPC_BCS< X, Diag, OffDiag >::applySingleEquationNeumannBC().

   {
     const int c0 = _faceCells(f,0);
     const int c1 = _faceCells(f,1);

     if (_ibType[c0] != Mesh::IBTYPE_FLUID)
       return;
     // the current value of flux and its Jacobians
     const T_Scalar fluxB = -(_r[c1])[v];


     // since we know the boundary flux, compute the boundary flux
     // correction and add it to the c0 residual; also eliminate
     // coeff to the boundary cell and remove it from the ap coeff

     const T_Scalar dFlux = specifiedFlux*_faceAreaMag[f] - fluxB;
     // setup the equation for the boundary value; the coefficients
     // are already computed so just need to set the rhs
     (_r[c1])[v] = dFlux;

     // mark this row as a "boundary" row so that we will update it
     // after the overall system is solved
     _dRdX.setBoundary(c1);

     // fix the boundary flux to the specified value
     (_flux[f])[v] = specifiedFlux*_faceAreaMag[f];

     Diag _dFluxdFlux_orig = _dFluxdFlux[f];
     _dFluxdFlux_orig[v] = NumTypeTraits<T_Scalar>::getNegativeUnity();
     _dFluxdFlux[f] = _dFluxdFlux_orig;
   }

template<class X , class Diag , class OffDiag >

void BatteryPC_BCS< X, Diag, OffDiag >::applySingleEquationNeumannBC	(	const T_Scalar &	bFlux,
		const int	v
	)		const

inline

Definition at line 161 of file BatteryPC_BCS.h.

References BatteryPC_BCS< X, Diag, OffDiag >::_faces, BatteryPC_BCS< X, Diag, OffDiag >::applySingleEquationNeumannBC(), and StorageSite::getCount().

   {
     for(int i=0; i<_faces.getCount(); i++)
       applySingleEquationNeumannBC(i,bFlux,v);
   }

Member Data Documentation

template<class X , class Diag , class OffDiag >

const Field& BatteryPC_BCS< X, Diag, OffDiag >::_areaField

protected

Definition at line 187 of file BatteryPC_BCS.h.

template<class X , class Diag , class OffDiag >

const Field& BatteryPC_BCS< X, Diag, OffDiag >::_areaMagField

protected

Definition at line 185 of file BatteryPC_BCS.h.

template<class X , class Diag , class OffDiag >

CCAssembler& BatteryPC_BCS< X, Diag, OffDiag >::_assembler

protected

Definition at line 179 of file BatteryPC_BCS.h.

Referenced by BatteryPC_BCS< X, Diag, OffDiag >::applySingleEquationDirichletBC().

template<class X , class Diag , class OffDiag >

const StorageSite& BatteryPC_BCS< X, Diag, OffDiag >::_cells

protected

Definition at line 169 of file BatteryPC_BCS.h.

template<class X , class Diag , class OffDiag >

BBMatrix& BatteryPC_BCS< X, Diag, OffDiag >::_dFluxdFlux

protected

Definition at line 178 of file BatteryPC_BCS.h.

Referenced by BatteryPC_BCS< X, Diag, OffDiag >::applySingleEquationDirichletBC(), and BatteryPC_BCS< X, Diag, OffDiag >::applySingleEquationNeumannBC().

template<class X , class Diag , class OffDiag >

FMatrix& BatteryPC_BCS< X, Diag, OffDiag >::_dFluxdX

protected

Definition at line 177 of file BatteryPC_BCS.h.

Referenced by BatteryPC_BCS< X, Diag, OffDiag >::applySingleEquationDirichletBC().

template<class X , class Diag , class OffDiag >

CCMatrix& BatteryPC_BCS< X, Diag, OffDiag >::_dRdX

protected

Definition at line 176 of file BatteryPC_BCS.h.

Referenced by BatteryPC_BCS< X, Diag, OffDiag >::applySingleEquationNeumannBC().

template<class X , class Diag , class OffDiag >

DiagArray& BatteryPC_BCS< X, Diag, OffDiag >::_dRdXDiag

protected

Definition at line 180 of file BatteryPC_BCS.h.

Referenced by BatteryPC_BCS< X, Diag, OffDiag >::applySingleEquationDirichletBC().

template<class X , class Diag , class OffDiag >

const VectorT3Array& BatteryPC_BCS< X, Diag, OffDiag >::_faceArea

protected

Definition at line 188 of file BatteryPC_BCS.h.

template<class X , class Diag , class OffDiag >

const TArray& BatteryPC_BCS< X, Diag, OffDiag >::_faceAreaMag

protected

Definition at line 186 of file BatteryPC_BCS.h.

Referenced by BatteryPC_BCS< X, Diag, OffDiag >::applySingleEquationNeumannBC().

template<class X , class Diag , class OffDiag >

const CRConnectivity& BatteryPC_BCS< X, Diag, OffDiag >::_faceCells

protected

Definition at line 171 of file BatteryPC_BCS.h.

Referenced by BatteryPC_BCS< X, Diag, OffDiag >::applySingleEquationDirichletBC(), and BatteryPC_BCS< X, Diag, OffDiag >::applySingleEquationNeumannBC().

template<class X , class Diag , class OffDiag >

const StorageSite& BatteryPC_BCS< X, Diag, OffDiag >::_faces

protected

Definition at line 168 of file BatteryPC_BCS.h.

Referenced by BatteryPC_BCS< X, Diag, OffDiag >::applySingleEquationDirichletBC(), and BatteryPC_BCS< X, Diag, OffDiag >::applySingleEquationNeumannBC().

template<class X , class Diag , class OffDiag >

XArray& BatteryPC_BCS< X, Diag, OffDiag >::_flux

protected

Definition at line 183 of file BatteryPC_BCS.h.

Referenced by BatteryPC_BCS< X, Diag, OffDiag >::applySingleEquationDirichletBC(), and BatteryPC_BCS< X, Diag, OffDiag >::applySingleEquationNeumannBC().

template<class X , class Diag , class OffDiag >

const Field& BatteryPC_BCS< X, Diag, OffDiag >::_fluxField

protected

Definition at line 173 of file BatteryPC_BCS.h.

template<class X , class Diag , class OffDiag >

const MultiField::ArrayIndex BatteryPC_BCS< X, Diag, OffDiag >::_fluxIndex

protected

Definition at line 175 of file BatteryPC_BCS.h.

template<class X , class Diag , class OffDiag >

const IntArray& BatteryPC_BCS< X, Diag, OffDiag >::_ibType

protected

Definition at line 170 of file BatteryPC_BCS.h.

Referenced by BatteryPC_BCS< X, Diag, OffDiag >::applySingleEquationDirichletBC(), and BatteryPC_BCS< X, Diag, OffDiag >::applySingleEquationNeumannBC().

template<class X , class Diag , class OffDiag >

const bool BatteryPC_BCS< X, Diag, OffDiag >::_is2D

protected

Definition at line 189 of file BatteryPC_BCS.h.

template<class X , class Diag , class OffDiag >

XArray& BatteryPC_BCS< X, Diag, OffDiag >::_r

protected

Definition at line 182 of file BatteryPC_BCS.h.

Referenced by BatteryPC_BCS< X, Diag, OffDiag >::applySingleEquationDirichletBC(), and BatteryPC_BCS< X, Diag, OffDiag >::applySingleEquationNeumannBC().

template<class X , class Diag , class OffDiag >

XArray& BatteryPC_BCS< X, Diag, OffDiag >::_rFlux

protected

Definition at line 184 of file BatteryPC_BCS.h.

Referenced by BatteryPC_BCS< X, Diag, OffDiag >::applySingleEquationDirichletBC().

template<class X , class Diag , class OffDiag >

const Field& BatteryPC_BCS< X, Diag, OffDiag >::_varField

protected

Definition at line 172 of file BatteryPC_BCS.h.

template<class X , class Diag , class OffDiag >

XArray& BatteryPC_BCS< X, Diag, OffDiag >::_x

protected

Definition at line 181 of file BatteryPC_BCS.h.

Referenced by BatteryPC_BCS< X, Diag, OffDiag >::applySingleEquationDirichletBC().

template<class X , class Diag , class OffDiag >

const MultiField::ArrayIndex BatteryPC_BCS< X, Diag, OffDiag >::_xIndex

protected

Definition at line 174 of file BatteryPC_BCS.h.

The documentation for this class was generated from the following file:

BatteryPC_BCS.h

Public Types

Public Member Functions

Protected Attributes

Detailed Description

template<class X, class Diag, class OffDiag> class BatteryPC_BCS< X, Diag, OffDiag >

Member Typedef Documentation

Constructor & Destructor Documentation

Member Function Documentation

Member Data Documentation

template<class X, class Diag, class OffDiag>
class BatteryPC_BCS< X, Diag, OffDiag >
