EmissionDiscretization< X, Diag, OffDiag > Class Template Reference

#include <EmissionDiscretization.h>

Inheritance diagram for EmissionDiscretization< X, Diag, OffDiag >:

Collaboration diagram for EmissionDiscretization< X, Diag, OffDiag >:

Public Types
typedef NumTypeTraits< X > ::T_Scalar	T_Scalar
typedef Array< T_Scalar >	TArray
typedef Array< Vector < T_Scalar, 3 > >	VectorT3Array
typedef CRMatrix< Diag, OffDiag, X >	CCMatrix
typedef CCMatrix::DiagArray	DiagArray
typedef CCMatrix::OffDiagArray	OffDiagArray
typedef Array< X >	XArray

Public Member Functions
	EmissionDiscretization (const MeshList &meshes, const GeomFields &geomFields, const Field &varField, const Field &electricField, const ElectricModelConstants< T_Scalar > &constants)
void	discretize (const Mesh &mesh, MultiFieldMatrix &mfmatrix, MultiField &xField, MultiField &rField)
Public Member Functions inherited from Discretization
	Discretization (const MeshList &meshes)
virtual	~Discretization ()
	DEFINE_TYPENAME ("Discretization")

Private Attributes
const GeomFields &	_geomFields
const Field &	_varField
const Field &	_electricField
const ElectricModelConstants < T_Scalar > &	_constants

Additional Inherited Members
Protected Attributes inherited from Discretization
const MeshList &	_meshes

Detailed Description

template<class X, class Diag, class OffDiag>
class EmissionDiscretization< X, Diag, OffDiag >

Definition at line 41 of file EmissionDiscretization.h.

Member Typedef Documentation

template<class X , class Diag , class OffDiag >

typedef CRMatrix<Diag,OffDiag,X> EmissionDiscretization< X, Diag, OffDiag >::CCMatrix

Definition at line 48 of file EmissionDiscretization.h.

template<class X , class Diag , class OffDiag >

typedef CCMatrix::DiagArray EmissionDiscretization< X, Diag, OffDiag >::DiagArray

Definition at line 49 of file EmissionDiscretization.h.

template<class X , class Diag , class OffDiag >

typedef CCMatrix::OffDiagArray EmissionDiscretization< X, Diag, OffDiag >::OffDiagArray

Definition at line 50 of file EmissionDiscretization.h.

template<class X , class Diag , class OffDiag >

typedef NumTypeTraits<X>::T_Scalar EmissionDiscretization< X, Diag, OffDiag >::T_Scalar

Definition at line 45 of file EmissionDiscretization.h.

template<class X , class Diag , class OffDiag >

typedef Array<T_Scalar> EmissionDiscretization< X, Diag, OffDiag >::TArray

Definition at line 46 of file EmissionDiscretization.h.

template<class X , class Diag , class OffDiag >

typedef Array<Vector<T_Scalar,3> > EmissionDiscretization< X, Diag, OffDiag >::VectorT3Array

Definition at line 47 of file EmissionDiscretization.h.

template<class X , class Diag , class OffDiag >

typedef Array<X> EmissionDiscretization< X, Diag, OffDiag >::XArray

Definition at line 51 of file EmissionDiscretization.h.

Constructor & Destructor Documentation

template<class X , class Diag , class OffDiag >

EmissionDiscretization< X, Diag, OffDiag >::EmissionDiscretization ( const MeshList &  meshes, const GeomFields &  geomFields, const Field &  varField, const Field &  electricField, const ElectricModelConstants< T_Scalar > &  constants  )

inline

Definition at line 53 of file EmissionDiscretization.h.

                                                                           :
    Discretization(meshes),
    _geomFields(geomFields),
    _varField(varField),
    _electricField(electricField),
    _constants(constants)
    {}

Member Function Documentation

template<class X , class Diag , class OffDiag >

void EmissionDiscretization< X, Diag, OffDiag >::discretize ( const Mesh &  mesh, MultiFieldMatrix &  mfmatrix, MultiField &  xField, MultiField &  rField  )

inlinevirtual

Implements Discretization.

Definition at line 66 of file EmissionDiscretization.h.

References EmissionDiscretization< X, Diag, OffDiag >::_constants, EmissionDiscretization< X, Diag, OffDiag >::_electricField, EmissionDiscretization< X, Diag, OffDiag >::_geomFields, EmissionDiscretization< X, Diag, OffDiag >::_varField, E0_SI, ElectricModelConstants< T >::electron_trapdepth, Mesh::getCells(), CRMatrix< T_Diag, T_OffDiag, X >::getDiag(), MultiFieldMatrix::getMatrix(), StorageSite::getSelfCount(), K_SI, mag(), PI, QE, sqrt(), and GeomFields::volume.

  {
    const StorageSite& cells = mesh.getCells();

    const int nCells = cells.getSelfCount();

    const VectorT3Array& electric_field = dynamic_cast<const VectorT3Array&> (_electricField[cells]);

    const MultiField::ArrayIndex cVarIndex(&_varField,&cells);

    CCMatrix& matrix = dynamic_cast<CCMatrix&>(mfmatrix.getMatrix(cVarIndex,cVarIndex));

    const XArray& xCell = dynamic_cast<const XArray&>(_varField[cells]);

    const TArray& cellVolume =
      dynamic_cast<const TArray&>(_geomFields.volume[cells]);

    XArray& rCell = dynamic_cast<XArray&>(rField[cVarIndex]);

    DiagArray& diag = matrix.getDiag();

    //OffDiagArray& offdiag = matrix.getOffDiag();

    const T_Scalar optical_dielectric_constant = _constants["optical_dielectric_constant"];
    const T_Scalar temperature = _constants["OP_temperature"];
    const T_Scalar poole_frenkel_emission_frequency = _constants["poole_frenkel_emission_frequency"];
    const int nTrap = _constants["nTrap"];
    vector<T_Scalar> electron_trapdepth = _constants.electron_trapdepth;
    const T_Scalar beta = sqrt( QE / (PI * E0_SI * optical_dielectric_constant) );

    for(int c=0; c<nCells; c++){

      for (int i=0; i<nTrap; i++){

        T_Scalar expt = (electron_trapdepth[i] - beta * sqrt(mag(electric_field[c]))) * QE / (K_SI * temperature);

        //if (expt < 0.0)
        //throw CException("exponential error in Emission model");
        if (expt > 0.0)
        {

            T_Scalar fluxCoeff = cellVolume[c] * poole_frenkel_emission_frequency * exp(-expt);

            rCell[c][i] -= (fluxCoeff * xCell[c][i]);

            diag[c](i,i) -= fluxCoeff;
            //diag[c][i] -= fluxCoeff;

            rCell[c][nTrap] += fluxCoeff * xCell[c][i];
        }
      }
    }
  }

Member Data Documentation

template<class X , class Diag , class OffDiag >

const ElectricModelConstants<T_Scalar>& EmissionDiscretization< X, Diag, OffDiag >::_constants

private

Definition at line 125 of file EmissionDiscretization.h.

Referenced by EmissionDiscretization< X, Diag, OffDiag >::discretize().

template<class X , class Diag , class OffDiag >

const Field& EmissionDiscretization< X, Diag, OffDiag >::_electricField

private

Definition at line 124 of file EmissionDiscretization.h.

Referenced by EmissionDiscretization< X, Diag, OffDiag >::discretize().

template<class X , class Diag , class OffDiag >

const GeomFields& EmissionDiscretization< X, Diag, OffDiag >::_geomFields

private

Definition at line 122 of file EmissionDiscretization.h.

Referenced by EmissionDiscretization< X, Diag, OffDiag >::discretize().

template<class X , class Diag , class OffDiag >

const Field& EmissionDiscretization< X, Diag, OffDiag >::_varField

private

Definition at line 123 of file EmissionDiscretization.h.

Referenced by EmissionDiscretization< X, Diag, OffDiag >::discretize().

---

The documentation for this class was generated from the following file:

• EmissionDiscretization.h
