MeshPartitioner Class Reference

#include <MeshPartitioner.h>

Collaboration diagram for MeshPartitioner:

Public Types
enum	ETYPE { TRI = 1, QUAD = 2, TETRA = 3, HEXA = 4 }
enum	WTYPE { NOWEIGHTS = 0, WEIGHTS_ONLY_EDGES = 1, WEIGTHS_ONLY_VERTICES = 2, WEIGHTS_BOTH_VERTICES_EDGES = 3 }
enum	NUMFLAG { C_STYLE = 0, FORTRAN_STYLE = 1 }
enum	CELLTYPE { INTERIOR = 1, GHOST_BOUNDARY_CELL = 2, GHOST_INTERFACE_CELL }
enum	PARTTYPE { PARMETIS = 1, FIEDLER =2 }
typedef shared_ptr< StorageSite >	StorageSitePtr
typedef shared_ptr < CRConnectivity >	CRConnectivityPtr
typedef shared_ptr< Array< int > >	ArrayIntPtr
typedef shared_ptr< Array < Mesh::VecD3 > >	ArrayVecD3Ptr
typedef shared_ptr< Mesh >	MeshPtr
typedef map< int, int >	IntMap
typedef map< int, vector< int > >	VectorMap
typedef pair< int, int >	IntPair

Public Member Functions
	MeshPartitioner (const MeshList &mesh_list, vector< int > npart, vector< int > eType)
	~MeshPartitioner ()
void	partition ()
void	fiedler_order (const string &fname)
void	mesh ()
const MeshList &	meshList () const
void	extractBoundaryMesh ()
const Mesh &	getBoundaryMesh () const
void	debug_print ()
void	mesh_xdmfplot ()
void	setWeightType (int weight_type)
void	setNumFlag (int num_flag)
void	cleanup ()
void	isCleanup (bool clean_up)
void	isDebug (bool debug)
void	DEBUG_compute_elem_dist ()
void	DEBUG_parmetis_mesh ()
void	DEBUG_fiedler_partition ()
void	DEBUG_elem_connectivity ()
void	DEBUG_map_part_elms ()
void	DEBUG_count_elems_part ()
void	DEBUG_exchange_part_elems ()
void	DEBUG_mapBounIDAndCell ()
void	DEBUG_resize_elem ()
void	DEBUG_CRConnectivity_cellParts ()
void	DEBUG_CRConnectivity_faceParts ()
void	DEBUG_interfaces ()
void	DEBUG_faceCells_faceNodes ()
void	DEBUG_non_interior_cells ()
void	DEBUG_preserve_cell_order ()
void	DEBUG_order_faceCells_faceNodes ()
void	DEBUG_coordinates ()
void	DEBUG_exchange_interface_meshes ()
void	DEBUG_mesh ()
void	DEBUG_local_global ()
void	DEBUG_cellcells_global ()
void	DEBUG_globalCellID_procID_map ()
void	DEBUG_gatherCellsLevel1_partID_map ()
void	DEBUG_level1_scatter_gather_cells ()
void	DEBUG_CRConnectivity_cellCells2 ()

Private Member Functions
	MeshPartitioner (const MeshPartitioner &part_mesh)
void	init ()
void	compute_elem_dist ()
void	elem_connectivity ()
void	parmetis_mesh ()
void	fiedler_partition ()
int	get_local_nodes (int id)
void	set_eptr_eind (int id)
void	map_part_elms ()
void	count_elems_part ()
void	exchange_part_elems ()
void	shift_sum_row ()
void	mesh_setup ()
int	global_offset ()
void	set_local_global ()
void	set_cellcells_global ()
void	cellcells_global_extension ()
void	globalCellID_procID_map ()
void	gatherCellsLevel1_partID_map ()
void	level1_scatter_gather_cells ()
void	CRConnectivity_cellParts ()
void	mapBounIDAndCell (int id)
void	resize_elem (int id)
void	CRConnectivity_faceParts ()
void	faceCells_faceNodes ()
void	interfaces ()
void	coordinates ()
int	count_interior_faces (int id)
void	order_faceCells_faceNodes ()
void	non_interior_cells ()
void	exchange_interface_meshes ()
void	mappers ()
void	create_window (int id)
void	free_window ()
void	fence_window ()
int	get_window_displ (int id, int neigh_mesh_id)
void	construct_mesh (int id)
void	setMeshColors ()
void	preserve_cell_order ()
void	scatterCellsLevel1 ()
void	mesh_xdmf_header ()
void	mesh_file ()
void	mesh_tecplot ()
void	cleanup_follow_exchange_part_elems ()
void	cleanup_follow_faceCells_faceNodes ()
void	cleanup_follow_mappers ()
void	CRConnectivityPrint (const CRConnectivity &conn, int procID, const string &name)
void	CRConnectivityPrintFile (const CRConnectivity &conn, const string &name)
void	debug_file_open (const string &fname)
void	debug_file_close ()

Private Attributes
const MeshList	_meshList
vector< int >	_nPart
vector< int >	_totElems
vector< int >	_totElemsAndGhosts
vector< Array< int > * >	_elemDist
vector< Array< int > * >	_globalIndx
vector< int * >	_ePtr
vector< int * >	_eInd
vector< int * >	_eElm
vector< int * >	_elmWght
vector< int >	_wghtFlag
vector< int >	_numFlag
vector< int >	_ncon
vector< int >	_ncommonNodes
vector< int >	_eType
vector< float * >	_tpwgts
vector< float * >	_ubvec
int	_options
int	_procID
vector< int >	_edgecut
vector< int * >	_part
vector< multimap< int, int > >	_mapPartAndElms
vector< int * >	_row
vector< int * >	_col
vector< int * >	_elem
vector< set< int > >	_elemSet
vector< int * >	_elemWithGhosts
vector< int >	_nelems
vector< int >	_nelemsWithGhosts
vector< int >	_colDim
int	_nmesh
vector< StorageSitePtr >	_cellSiteGlobal
vector< StorageSitePtr >	_cellSite
vector< StorageSitePtr >	_nodeSite
vector< StorageSitePtr >	_faceSite
vector< StorageSitePtr >	_partSite
vector< const CRConnectivity * >	_faceCellsGlobal
vector< const CRConnectivity * >	_faceNodesGlobal
vector< CRConnectivityPtr >	_faceCells
vector< CRConnectivityPtr >	_faceNodes
vector< CRConnectivityPtr >	_cellCells
vector< CRConnectivityPtr >	_cellNodes
vector< CRConnectivityPtr >	_faceCellsOrdered
vector< CRConnectivityPtr >	_faceNodesOrdered
vector< CRConnectivityPtr >	_cellParts
vector< CRConnectivityPtr >	_partCells
vector< CRConnectivityPtr >	_faceParts
vector< CRConnectivityPtr >	_partFaces
vector< CRConnectivityPtr >	_partNodes
vector< set< int > >	_boundarySet
vector< multimap< int, int > >	_mapBounIDAndCell
vector< map< int, string > >	_mapBounIDAndBounType
vector< ArrayVecD3Ptr >	_coord
vector< set< int > >	_interfaceSet
vector< multimap< int, int > >	_interfaceMap
vector< set< int > >	_nonInteriorCells
vector< map< int, int > >	_bndryOffsets
vector< map< int, int > >	_interfaceOffsets
vector< vector< int > >	_cellToOrderedCell
vector< multimap< int, int > >	_globalToLocalMappers
vector< map< int, int > >	_localToGlobalMappers
map< int, int >	_globalToLocal
map< int, int >	_cellToPreservedOrderCell
map< int, int >	_cellsLevel1PartID
map< int, int >	_gatherCellsLevel1PartIDMap
vector< ArrayIntPtr >	_interfaceMeshCounts
vector< ArrayIntPtr >	_offsetInterfaceCells
vector< ArrayIntPtr >	_procTotalInterfaces
vector< ArrayIntPtr >	_interfaceMeshIDs
vector< ArrayIntPtr >	_ghostCellsGlobal
vector< ArrayIntPtr >	_ghostCellsLocal
vector< int >	_windowSize
vector< vector< ArrayIntPtr > >	_fromIndices
vector< vector< ArrayIntPtr > >	_toIndices
ArrayIntPtr	_fiedlerMap
PARTTYPE	_partTYPE
MPI::Win	_winGlobal
MPI::Win	_winLocal
bool	_cleanup
bool	_debugMode
ofstream	_debugFile
vector< Mesh * >	_meshListLocal
Mesh *	_bMesh

Detailed Description

Definition at line 22 of file MeshPartitioner.h.

Member Typedef Documentation

typedef shared_ptr< Array<int> > MeshPartitioner::ArrayIntPtr

Definition at line 28 of file MeshPartitioner.h.

typedef shared_ptr< Array<Mesh::VecD3> > MeshPartitioner::ArrayVecD3Ptr

Definition at line 29 of file MeshPartitioner.h.

typedef shared_ptr< CRConnectivity > MeshPartitioner::CRConnectivityPtr

Definition at line 27 of file MeshPartitioner.h.

typedef map<int, int> MeshPartitioner::IntMap

Definition at line 31 of file MeshPartitioner.h.

typedef pair<int,int> MeshPartitioner::IntPair

Definition at line 33 of file MeshPartitioner.h.

typedef shared_ptr< Mesh > MeshPartitioner::MeshPtr

Definition at line 30 of file MeshPartitioner.h.

typedef shared_ptr< StorageSite > MeshPartitioner::StorageSitePtr

Definition at line 26 of file MeshPartitioner.h.

typedef map<int, vector<int> > MeshPartitioner::VectorMap

Definition at line 32 of file MeshPartitioner.h.

Member Enumeration Documentation

enum MeshPartitioner::CELLTYPE

Enumerator
INTERIOR
GHOST_BOUNDARY_CELL
GHOST_INTERFACE_CELL

Definition at line 39 of file MeshPartitioner.h.

{ INTERIOR = 1, GHOST_BOUNDARY_CELL = 2, GHOST_INTERFACE_CELL};

enum MeshPartitioner::ETYPE

Enumerator
TRI
QUAD
TETRA
HEXA

Definition at line 35 of file MeshPartitioner.h.

{ TRI = 1, QUAD = 2, TETRA = 3, HEXA = 4 };

enum MeshPartitioner::NUMFLAG

Enumerator
C_STYLE
FORTRAN_STYLE

Definition at line 38 of file MeshPartitioner.h.

{ C_STYLE = 0, FORTRAN_STYLE = 1 };

enum MeshPartitioner::PARTTYPE

Enumerator
PARMETIS
FIEDLER

Definition at line 40 of file MeshPartitioner.h.

{ PARMETIS = 1, FIEDLER =2};

enum MeshPartitioner::WTYPE

Enumerator
NOWEIGHTS
WEIGHTS_ONLY_EDGES
WEIGTHS_ONLY_VERTICES
WEIGHTS_BOTH_VERTICES_EDGES

Definition at line 36 of file MeshPartitioner.h.

              { NOWEIGHTS = 0, WEIGHTS_ONLY_EDGES = 1, WEIGTHS_ONLY_VERTICES  = 2,
                WEIGHTS_BOTH_VERTICES_EDGES = 3};

Constructor & Destructor Documentation

MeshPartitioner::MeshPartitioner ( const MeshList &  mesh_list, vector< int >  npart, vector< int >  eType  )

explicit

Definition at line 27 of file MeshPartitioner.cpp.

References _meshList, and init().

                                                                                                  :
_meshList(mesh_list), _nPart(nPart), _eType(eType), _options(0), _bMesh(NULL)
{
   if ( !MPI::Is_initialized() )  MPI::Init();
   init();
   assert( _meshList.size() == 1 );
}

MeshPartitioner::~MeshPartitioner

(

)

Definition at line 36 of file MeshPartitioner.cpp.

References _bMesh, _cleanup, _col, _eElm, _eInd, _elem, _elemDist, _elemWithGhosts, _elmWght, _ePtr, _globalIndx, _meshListLocal, _part, _row, _tpwgts, and _ubvec.

{

    MPI::COMM_WORLD.Barrier();
    //releae memory of vector elements dynamically allocated memory
    vector< Array<int>* > ::iterator it_array;
    for ( it_array = _elemDist.begin(); it_array != _elemDist.end(); it_array++)
       delete *it_array;

    for ( it_array = _globalIndx.begin(); it_array != _globalIndx.end(); it_array++)
       delete *it_array;

   if ( !_cleanup ){
      vector< int* > ::iterator it_int;
      for ( it_int = _ePtr.begin(); it_int != _ePtr.end(); it_int++)
          delete [] *it_int;

       for ( it_int = _eInd.begin(); it_int != _eInd.end(); it_int++)
          delete [] *it_int;

       for ( it_int = _eElm.begin(); it_int != _eElm.end(); it_int++)
          delete [] *it_int;

       for ( it_int = _elmWght.begin(); it_int != _elmWght.end(); it_int++)
          delete [] *it_int;

       for ( it_int = _row.begin(); it_int != _row.end(); it_int++)
          delete [] *it_int;

       for ( it_int = _col.begin(); it_int != _col.end(); it_int++)
          delete [] *it_int;

       for ( it_int  = _elem.begin(); it_int != _elem.end(); it_int++)
          delete [] *it_int;
   }

    vector< float* > ::iterator it_float;
    for ( it_float = _tpwgts.begin(); it_float != _tpwgts.end(); it_float++)
       delete [] *it_float;

    for ( it_float = _ubvec.begin(); it_float != _ubvec.end(); it_float++)
       delete [] *it_float;
    vector< int* > ::iterator it_int;
    for ( it_int = _part.begin(); it_int != _part.end(); it_int++)
       delete [] *it_int;


   for ( it_int  = _elemWithGhosts.begin(); it_int != _elemWithGhosts.end(); it_int++)
       delete [] *it_int;



   vector< Mesh* >::iterator it_mesh;
   for ( it_mesh = _meshListLocal.begin(); it_mesh != _meshListLocal.end(); it_mesh++)
        delete *it_mesh;

   if ( _bMesh ) delete  _bMesh;
}

MeshPartitioner::MeshPartitioner ( const MeshPartitioner &  part_mesh )

private

Member Function Documentation

void MeshPartitioner::cellcells_global_extension ( )

private

Definition at line 2284 of file MeshPartitioner.cpp.

References _meshListLocal, _nmesh, _nPart, Mesh::getAllFaceCells(), Mesh::getCellCells(), Mesh::getCellCellsGlobal(), Mesh::getCells(), CRConnectivity::getCount(), Mesh::getDimension(), Mesh::getInterfaceGroupCount(), Mesh::getInterfaceGroups(), Mesh::getLocalToGlobal(), and StorageSite::getSelfCount().

Referenced by set_cellcells_global().

{
      for ( int id = 0; id < _nmesh; id++ ){
          Mesh& mesh = *_meshListLocal.at(id);
          StorageSite& cellSite = mesh.getCells();
          const int ndim = mesh.getDimension();
          const int selfCount = cellSite.getSelfCount();
          //estimated sizes for buffers
          const int scatterSize = 6 * int( (ndim == 2) ? pow(selfCount,0.5) : pow(selfCount,2.0/3.0) ); //6 is maximum face count in hexa
          //array to hold local processors scatterBuffer (it might repeat several cells, it is ok)
          vector<int> scatterBuffer;
          //local array to hold cellCells for scattercells
          vector<int> cellCellsBuffer;
          //local array to hold count of cells around scatter cells
          vector<int> cellCellsCountBuffer;
          //scatterSize is not fill in capacity of scatterSize!!!!!!!!!!!!!, you have to call vector::size()  method
          scatterBuffer.reserve       ( scatterSize  );
          cellCellsCountBuffer.reserve( scatterSize  );
          cellCellsBuffer.reserve     ( 6*scatterSize);


          const Array<int>&      localToGlobal = mesh.getLocalToGlobal();
          const CRConnectivity&  cellCells     = mesh.getCellCells();
          const CRConnectivity&  faceCells     = mesh.getAllFaceCells();
          const FaceGroupList&   faceGroupList = mesh.getInterfaceGroups();
          //loop over interfaces
          for ( int i = 0; i < mesh.getInterfaceGroupCount(); i++ ){
             const int ibeg = faceGroupList[i]->site.getOffset();
             const int iend = ibeg + faceGroupList[i]->site.getCount();
             for ( int i = ibeg; i < iend; i++ ){
                 const int localCellID = faceCells(i,0);
                 const int globalCellID = localToGlobal[ localCellID ];
                 scatterBuffer.push_back(globalCellID);
                 int indx = 0;
                 for ( int j = 0; j < cellCells.getCount(localCellID); j++ ){
                     const int nextcellID  = localToGlobal[ cellCells(localCellID,j) ];
                     cellCellsBuffer.push_back(nextcellID);
                     indx++;
                 }
                 cellCellsCountBuffer.push_back(indx);
              }
          }

         //MPI collective operations

         //first decide global buffer sizes
         int scatterGlobalSize;
         int cellCellsGlobalSize;
         int cellCellsCountGlobalSize;
         int sendbuffer = int( scatterBuffer.size() );
         MPI::COMM_WORLD.Allreduce( &sendbuffer, &scatterGlobalSize, 1, MPI::INT, MPI::SUM );
         sendbuffer = int( cellCellsBuffer.size() );
         MPI::COMM_WORLD.Allreduce( &sendbuffer, &cellCellsGlobalSize, 1, MPI::INT, MPI::SUM );
         sendbuffer = int( cellCellsCountBuffer.size() );
         MPI::COMM_WORLD.Allreduce( &sendbuffer, &cellCellsCountGlobalSize, 1, MPI::INT, MPI::SUM );

         //create array for
         //scatterCellsGlobal
         shared_ptr< Array<int> > scatterCellsGlobal = ArrayIntPtr( new Array<int>(scatterGlobalSize  ) );
         int *recv_counts = new int[ _nPart.at(id) ];
         int sendcount = int( scatterBuffer.size() );
         MPI::COMM_WORLD.Allgather( &sendcount, 1, MPI::INT, recv_counts, 1, MPI::INT );

         int *displ = new int[ _nPart.at(id) ];
         displ[0] = 0;
         for ( int i = 1; i < _nPart.at(id); i++)
            displ[i] = recv_counts[i-1] + displ[i-1];
         //now gather for scatterBuffer
         MPI::COMM_WORLD.Allgatherv( &scatterBuffer[0], sendcount , MPI::INT,
                  scatterCellsGlobal->getData(), recv_counts, displ, MPI::INT);

         // cellCellsCountGlobal
         shared_ptr< Array<int> > cellCellsCountGlobal = ArrayIntPtr( new Array<int>(cellCellsCountGlobalSize  ) );
         sendcount = int( cellCellsCountBuffer.size() );
         MPI::COMM_WORLD.Allgather( &sendcount, 1, MPI::INT, recv_counts, 1, MPI::INT );

         displ[0] = 0;
         for ( int i = 1; i < _nPart.at(id); i++)
            displ[i] = recv_counts[i-1] + displ[i-1];
         //now gather for scatterBuffer
         MPI::COMM_WORLD.Allgatherv( &cellCellsCountBuffer[0], sendcount , MPI::INT,
                  cellCellsCountGlobal->getData(), recv_counts, displ, MPI::INT);

         // cellCellsGlobal
         shared_ptr< Array<int> > cellCellsGlobal = ArrayIntPtr( new Array<int>(cellCellsGlobalSize  ) );
         sendcount = int( cellCellsBuffer.size() );
         MPI::COMM_WORLD.Allgather( &sendcount, 1, MPI::INT, recv_counts, 1, MPI::INT );

         displ[0] = 0;
         for ( int i = 1; i < _nPart.at(id); i++)
            displ[i] = recv_counts[i-1] + displ[i-1];
         //now gather for scatterBuffer
         MPI::COMM_WORLD.Allgatherv( &cellCellsBuffer[0], sendcount , MPI::INT,
                  cellCellsGlobal->getData(), recv_counts, displ, MPI::INT);


         //create mapping index location where connectivity starts
         //and map index show index location, {12,82,23}, I want to know what is 82 index = 1
         map<int,int>  cellPointer;
         map<int,int>  locaterIndx;
         int pointerIndx = 0;
         for ( int i = 0; i < scatterGlobalSize; i++ ){
             const int cellID = (*scatterCellsGlobal  )[i];
             const int count  = (*cellCellsCountGlobal)[i];
             cellPointer[cellID] = pointerIndx;
             pointerIndx  += count;
             locaterIndx[cellID] = i;
         }

         Mesh::multiMap&  cellCellsMap = mesh.getCellCellsGlobal();
         //loop over interface, and get ghost cells(globalid), then go to scatterCells,
         //loop over interfaces  for gather
         for ( int i = 0; i < mesh.getInterfaceGroupCount(); i++ ){
             const int ibeg = faceGroupList[i]->site.getOffset();
             const int iend = ibeg + faceGroupList[i]->site.getCount();
             for ( int i = ibeg; i < iend; i++ ){
                 const int localCellID  = faceCells(i,1);  //gather cellID(local)
                 const int globalCellID = localToGlobal[localCellID ];
                 const int count        = (*cellCellsCountGlobal)[ locaterIndx[globalCellID] ];
                 const int offset       = cellPointer[globalCellID];
                 //erase ghost cell to not duplicate
                 cellCellsMap.erase( localCellID );
                 //add itself
//                 cellCellsMap.insert( pair<int,int>( localCellID,globalCellID) );
                 for ( int j = 0; j < count; j++ ){
                     const int cellID = (*cellCellsGlobal)[offset+j];

                     cellCellsMap.insert( pair<int,int>(localCellID,cellID) );
                 }
             }
         }
         delete [] recv_counts;
         delete [] displ;
      }

 }

void MeshPartitioner::cleanup

(

)

void MeshPartitioner::cleanup_follow_exchange_part_elems ( )

private

Definition at line 896 of file MeshPartitioner.cpp.

References _col, _eElm, _eInd, _elmWght, _ePtr, and _row.

Referenced by exchange_part_elems().

{
    //dont release memory until all process reach this point
    MPI::COMM_WORLD.Barrier();
    vector< int* > ::iterator it_int;
    for ( it_int = _ePtr.begin(); it_int != _ePtr.end(); it_int++)
       delete [] *it_int;

    for ( it_int = _eInd.begin(); it_int != _eInd.end(); it_int++)
       delete [] *it_int;

    for ( it_int = _eElm.begin(); it_int != _eElm.end(); it_int++)
       delete [] *it_int;

    for ( it_int = _elmWght.begin(); it_int != _elmWght.end(); it_int++)
       delete [] *it_int;

    for ( it_int = _row.begin(); it_int != _row.end(); it_int++)
       delete [] *it_int;

    for ( it_int = _col.begin(); it_int != _col.end(); it_int++)
       delete [] *it_int;


}

void MeshPartitioner::cleanup_follow_faceCells_faceNodes ( )

private

Definition at line 1455 of file MeshPartitioner.cpp.

References _elem, _faceCellsGlobal, and _faceNodesGlobal.

Referenced by faceCells_faceNodes().

{
    MPI::COMM_WORLD.Barrier();
   _faceCellsGlobal.clear();
   _faceNodesGlobal.clear();
    vector< int* > ::iterator it_int;
    for ( it_int  = _elem.begin(); it_int != _elem.end(); it_int++)
       delete [] *it_int;


}

void MeshPartitioner::cleanup_follow_mappers ( )

private

Definition at line 3055 of file MeshPartitioner.cpp.

References _globalToLocalMappers, and _localToGlobalMappers.

Referenced by mappers().

{
    MPI::COMM_WORLD.Barrier();
   _localToGlobalMappers.clear();
   _globalToLocalMappers.clear();
}

void MeshPartitioner::compute_elem_dist ( )

private

Definition at line 389 of file MeshPartitioner.cpp.

References _debugMode, _elemDist, _globalIndx, _nmesh, _nPart, _part, _procID, _totElems, and DEBUG_compute_elem_dist().

Referenced by partition().

{

   for (int id = 0; id < _nmesh; id++){
      int nelems = _totElems[id];
      int npart  = _nPart[id];
      int nremainder = nelems % npart;
      int init_dist = (nelems - nremainder) / npart;
      _elemDist.push_back( new Array<int>( npart) );
      _globalIndx.push_back( new Array<int>(npart+1) );
      *_elemDist.at(id) = init_dist;

       int p = 0;
       while ( nremainder != 0 ){
           (*_elemDist.at(id))[p % npart]++;
            nremainder--;
            p++;
       }

       (*_globalIndx[id]) = 0;
       int sum_elem = 0;
       for ( int n = 1; n <= npart; n++){
           sum_elem += (*_elemDist.at(id))[n-1];
           ((*_globalIndx.at(id))[n]) =  sum_elem;
       }
   }

   for (int id = 0; id < _nmesh; id++){
       int mesh_nlocal = (*_elemDist.at(id))[_procID];
     _part.push_back( new  int[mesh_nlocal] );
      for ( int n = 0; n < mesh_nlocal; n++)
         _part.at(id)[n] = -1;
   }

   if ( _debugMode )
      DEBUG_compute_elem_dist();

}

void MeshPartitioner::construct_mesh ( int  id )

private

Definition at line 1881 of file MeshPartitioner.cpp.

References _interfaceMap, _meshList, _meshListLocal, _nelems, _nelemsWithGhosts, _partFaces, _partNodes, _procID, Mesh::setCellZoneID(), StorageSite::setCount(), and Mesh::setID().

Referenced by order_faceCells_faceNodes().

{
        int dim = _meshList.at(id)->getDimension();
        int cellZoneId = _meshList.at(id)->getCellZoneID();
        Mesh *pmesh = new Mesh(dim);
        pmesh->setID(_meshList.at(id)->getID());
        pmesh->setCellZoneID(cellZoneId);
        _meshListLocal.push_back( pmesh   );

        StorageSite& faceSite = _meshListLocal.at(id)->getFaces();
        StorageSite& cellSite = _meshListLocal.at(id)->getCells();
        StorageSite& nodeSite = _meshListLocal.at(id)->getNodes();
        int nface_local = _partFaces.at(id)->getCount( _procID );
        int tot_cells = _nelemsWithGhosts.at(id) + _interfaceMap.at(id).size();
        int nGhostCell_local =  tot_cells - _nelems.at(id);
        int nnode_local =_partNodes.at(id)->getCount( _procID );

        //Storage sites
        faceSite.setCount( nface_local );
        cellSite.setCount( _nelems.at(id), nGhostCell_local );
        nodeSite.setCount( nnode_local );
}

void MeshPartitioner::coordinates ( )

private

Definition at line 1516 of file MeshPartitioner.cpp.

References _coord, _debugMode, _meshList, _nmesh, _partNodes, _procID, DEBUG_coordinates(), and Mesh::getNodeCoordinates().

Referenced by mesh().

{

  for ( int id = 0; id < _nmesh; id++){
      const Mesh& mesh = *(_meshList.at(id));
        const Array<Mesh::VecD3>&   global_coord = mesh.getNodeCoordinates();
        int node_count = _partNodes.at(id)->getCount( _procID );
        _coord.push_back( ArrayVecD3Ptr(new Array<Mesh::VecD3>(node_count)) );
        const Array<int>&    rowPartNodes = _partNodes.at(id)->getRow();
        const Array<int>&    colPartNodes = _partNodes.at(id)->getCol();

        for ( int node = 0; node < node_count; node++)
            (*_coord.at(id))[node] = global_coord[ colPartNodes[rowPartNodes[_procID]+node] ];
    }

    if ( _debugMode )
        DEBUG_coordinates();

}

void MeshPartitioner::count_elems_part ( )

private

Definition at line 725 of file MeshPartitioner.cpp.

References _col, _colDim, _debugMode, _elem, _ePtr, _mapPartAndElms, _nelems, _nmesh, _nPart, _row, and DEBUG_count_elems_part().

Referenced by partition().

{
   for ( int id = 0; id < _nmesh; id++){
       for ( int partID = 0; partID < _nPart.at(id); partID++){
          int nelems_local = _mapPartAndElms.at(id).count(partID);

          //sum to find size of ncol
          multimap<int,int>::const_iterator it = _mapPartAndElms.at(id).find(partID);
          multimap<int,int>::const_iterator itlow = _mapPartAndElms.at(id).lower_bound(partID);
          multimap<int,int>::const_iterator itup = _mapPartAndElms.at(id).upper_bound(partID);
          int ncol_local = 0;
          for ( it = itlow; it != itup; it++){
              int pos = it->second;  // element number
              ncol_local += _ePtr.at(id)[pos+1] - _ePtr.at(id)[pos];
          }

          MPI::COMM_WORLD.Reduce(&nelems_local, &_nelems.at(id), 1, MPI::INT, MPI::SUM, partID);
          MPI::COMM_WORLD.Reduce(&ncol_local, &_colDim.at(id), 1, MPI::INT, MPI::SUM, partID);

       }
       //now each processor now how many elements and nodes
      _row.push_back ( new int[_nelems.at(id)+1] );
      _elem.push_back( new int[_nelems.at(id) ] );
      _col.push_back ( new int[_colDim.at(id)]   );
       for ( int n = 0; n < _nelems.at(id)+1; n++ )
            _row.at(id)[n] = -1;
       for ( int n = 0; n < _colDim.at(id); n++)
            _col.at(id)[n] = -1;
       for ( int n = 0; n < _nelems.at(id); n++)
            _elem.at(id)[n] = -1;

   }

   if ( _debugMode )
      DEBUG_count_elems_part();

}

int MeshPartitioner::count_interior_faces ( int  id )

private

Definition at line 1555 of file MeshPartitioner.cpp.

References _interfaceMap, _nelems, _nelemsWithGhosts, _partFaces, and _procID.

Referenced by mesh_setup().

{
   return _partFaces.at(id)->getCount(_procID) - (_nelemsWithGhosts.at(id) - _nelems.at(id))
          - _interfaceMap.at(id).size();

}

void MeshPartitioner::CRConnectivity_cellParts ( )

private

Definition at line 1167 of file MeshPartitioner.cpp.

References _cellParts, _cellSiteGlobal, _debugMode, _elemWithGhosts, _nelemsWithGhosts, _nmesh, _nPart, _partCells, _partSite, _totElems, _totElemsAndGhosts, DEBUG_CRConnectivity_cellParts(), mapBounIDAndCell(), and resize_elem().

Referenced by mesh().

{
    vector< int* >  elemGlobal;
    vector< int* >  distGlobal;  //total partition + 1 suche that 0, 5, 10, 15

    for ( int id = 0; id < _nmesh; id++){
        mapBounIDAndCell(id);
        resize_elem(id);

        elemGlobal.push_back( new int [_totElemsAndGhosts.at(id) ]   ); //global array to aggregation
        distGlobal.push_back( new int [ _nPart.at(id) + 1 ] );
        int *offsets = new int [ _nPart.at(id) ];


        MPI::COMM_WORLD.Allgather(&_nelemsWithGhosts.at(id), 1, MPI::INT, distGlobal.at(id), 1, MPI::INT);
        //form offsets
        offsets[0]  = 0;
        for ( int p = 1; p < int(_nPart.at(id)); p++ ){
           offsets[p]  = distGlobal.at(id)[p-1]  + offsets[p-1];
        }

        //gathering partial partions for _row and _col
        MPI::COMM_WORLD.Allgatherv(_elemWithGhosts.at(id), _nelemsWithGhosts.at(id), MPI::INT, elemGlobal.at(id),
                                distGlobal.at(id), offsets, MPI::INT);


       //shift  distGlobal to one right
        for ( int i = int(_nPart.at(id)); i > 0; i--)
           distGlobal.at(id)[i] = distGlobal.at(id)[i-1];

        distGlobal.at(id)[0] = 0;

       //summing distGlobal
        for ( int i = 1; i < _nPart.at(id)+1; i++ ){
             distGlobal.at(id)[i] += distGlobal.at(id)[i-1];
        }
        delete [] offsets;


      //forming CRConnectivity for cellPart
       int nghost = _totElemsAndGhosts.at(id) - _totElems.at(id);
      _cellSiteGlobal.push_back( StorageSitePtr(new StorageSite(_totElems.at(id), nghost )) );
      _partSite.push_back( StorageSitePtr(new StorageSite(_nPart.at(id)) )  );

       _cellParts.push_back( CRConnectivityPtr(new CRConnectivity( *_cellSiteGlobal.at(id), *_partSite.at(id)) ) );

      _cellParts.at(id)->initCount();

      for ( int indx = 0; indx < _totElemsAndGhosts.at(id); indx++)
          _cellParts.at(id)->addCount(indx,1);

      _cellParts.at(id)->finishCount();

      int index = 0;
      while ( index < _nPart.at(id) ){
         for ( int n = distGlobal.at(id)[index]; n < distGlobal.at(id)[index+1]; n++){

             _cellParts.at(id)->add(elemGlobal.at(id)[n],index);
         }
         index++;
      }

      _cellParts.at(id)->finishAdd();
      _partCells.push_back( _cellParts.at(id)->getTranspose() );
   }


    //deleting allocated arrays in this method
    vector< int* > ::iterator it_int;
    for ( it_int = elemGlobal.begin(); it_int != elemGlobal.end(); it_int++)
       delete [] *it_int;

    for ( it_int = distGlobal.begin(); it_int != distGlobal.end(); it_int++)
       delete [] *it_int;

    if ( _debugMode )
         DEBUG_CRConnectivity_cellParts();

}

void MeshPartitioner::CRConnectivity_faceParts ( )

private

Definition at line 1276 of file MeshPartitioner.cpp.

References _cellParts, _debugMode, _faceCellsGlobal, _faceNodesGlobal, _faceParts, _meshList, _nmesh, _partFaces, _partNodes, and DEBUG_CRConnectivity_faceParts().

Referenced by mesh().

{
     for ( int id = 0; id < _nmesh; id++){
          _faceCellsGlobal.push_back( &_meshList.at(id)->getAllFaceCells() );
          _faceNodesGlobal.push_back( &_meshList.at(id)->getAllFaceNodes() );

          _faceParts.push_back( _faceCellsGlobal.at(id)->multiply( *_cellParts.at(id), false) );
          _partFaces.push_back( _faceParts.at(id)->getTranspose() );
          _partNodes.push_back( _partFaces.at(id)->multiply( *_faceNodesGlobal.at(id), false) );
    }

    if ( _debugMode )
       DEBUG_CRConnectivity_faceParts();
}

void MeshPartitioner::CRConnectivityPrint ( const CRConnectivity &  conn, int  procID, const string &  name  )

private

Definition at line 3376 of file MeshPartitioner.cpp.

References CRConnectivity::getCol(), Array< T >::getLength(), and CRConnectivity::getRow().

{

   if ( MPI::COMM_WORLD.Get_rank() == procID ){
      cout <<  name << " :" << endl;
      const Array<int>& row = conn.getRow();
      const Array<int>& col = conn.getCol();
      for ( int i = 0; i < row.getLength()-1; i++ ){
         cout << " i = " << i << ",    ";
         for ( int j = row[i]; j < row[i+1]; j++ )
            cout << col[j] << "  ";
         cout << endl;
      }
   }

}

void MeshPartitioner::CRConnectivityPrintFile ( const CRConnectivity &  conn, const string &  name  )

private

Definition at line 3395 of file MeshPartitioner.cpp.

References _debugFile, CRConnectivity::getCol(), Array< T >::getLength(), and CRConnectivity::getRow().

Referenced by DEBUG_CRConnectivity_cellCells2(), and DEBUG_fiedler_partition().

{
      _debugFile <<  name << " :" << endl;
      _debugFile << endl;
      const Array<int>& row = conn.getRow();
      const Array<int>& col = conn.getCol();
      for ( int i = 0; i < row.getLength()-1; i++ ){
         _debugFile << " i = " << i << ",    ";
         for ( int j = row[i]; j < row[i+1]; j++ )
            _debugFile << col[j] << "  ";
         _debugFile << endl;
      }
      _debugFile << endl;
}

void MeshPartitioner::create_window ( int  id )

private

Definition at line 3080 of file MeshPartitioner.cpp.

References _ghostCellsGlobal, _ghostCellsLocal, _windowSize, _winGlobal, and _winLocal.

Referenced by mappers().

{
           int int_size = MPI::INT.Get_size();
           MPI::Aint lb, sizeofAint;
           MPI::INT.Get_extent(lb,sizeofAint);

           int window_size = _windowSize.at(id);  //already MPI::MAX  has taken  maximum size
           _winLocal  = MPI::Win::Create(_ghostCellsLocal.at(id)->getData(), window_size*sizeofAint, int_size,
                                         MPI_INFO_NULL, MPI::COMM_WORLD);
           _winGlobal = MPI::Win::Create(_ghostCellsGlobal.at(id)->getData(), window_size*sizeofAint, int_size,
                                         MPI_INFO_NULL, MPI::COMM_WORLD);

}

void MeshPartitioner::DEBUG_cellcells_global

(

)

Definition at line 2423 of file MeshPartitioner.cpp.

References _debugFile, _meshListLocal, _nmesh, debug_file_close(), debug_file_open(), Mesh::getCellCellsGlobal(), Mesh::getCells(), and StorageSite::getCount().

Referenced by set_cellcells_global().

{
    //open file
   debug_file_open("cellcells_global");
   //loop over meshes
    for ( int id = 0 ; id < _nmesh ; id++ ){
       Mesh&    mesh = *_meshListLocal.at(id);
       const multimap<int,int>& cellCellsGlobal  = mesh.getCellCellsGlobal();
       const StorageSite&     cellSite  = mesh.getCells();
       const int ncells = cellSite.getCount();
       _debugFile << "Mesh ID = " << id << endl;
       //loop over all meshinterfaces  (key = all other meshes)
       for ( int n = 0; n < ncells; n++ ){
         _debugFile << "   localCellID = " << n << "       itself and cells around (global number) = ";
          multimap<int,int>::const_iterator it;
          for ( it = cellCellsGlobal.equal_range(n).first; it != cellCellsGlobal.equal_range(n).second; it++ ){
             _debugFile << it->second << "  ";
          }
          _debugFile << endl;
       }
    }
   //close file
   debug_file_close();
}

void MeshPartitioner::DEBUG_compute_elem_dist

(

)

Definition at line 431 of file MeshPartitioner.cpp.

References _debugFile, _elemDist, _globalIndx, _nPart, _totElems, debug_file_close(), and debug_file_open().

Referenced by compute_elem_dist().

{
   //open file
   debug_file_open("compute_elem_dist");
  //_totElms
  _debugFile << "_totElems = " << _totElems[0] << endl;
  _debugFile << endl;
  //_npart
  _debugFile << "_npart    = " << _nPart[0]    << endl;
  _debugFile << endl;
  //_elemDist
  _debugFile << "_elemDist : " << endl;
  _debugFile << endl;
  for( int n = 0; n < _nPart[0]; n++ )
     _debugFile << "_elemDist[" << n << "] = " << (*_elemDist[0])[n] << endl;
  _debugFile << endl;
  //_globalIndx
  _debugFile << "_globalIndx : " << endl;
  for( int n = 0; n < _nPart[0]+1; n++ )
     _debugFile << "_globalIndx[" << n << "] = " << (*_globalIndx[0])[n] << endl;
  _debugFile << endl;
  //close file
   debug_file_close();

}

void MeshPartitioner::DEBUG_coordinates

(

)

Definition at line 1537 of file MeshPartitioner.cpp.

References _coord, _debugFile, _partNodes, _procID, debug_file_close(), and debug_file_open().

Referenced by coordinates().

{
     debug_file_open("coordinates");
    //node coordinates
    _debugFile << "coordinates : " << endl;
    _debugFile << endl;
    int node_count = _partNodes.at(0)->getCount( _procID );
    for ( int node = 0; node < node_count; node++){
        _debugFile << fixed;
        _debugFile << " node ID = " <<setw(10)<< node << setprecision(7) << ",  x = " << (*_coord.at(0))[node][0] <<
         setprecision(7) << ",  y = " << (*_coord.at(0))[node][1] <<
         setprecision(7) << ",  z = " << (*_coord.at(0))[node][2] << endl;
    }
    _debugFile << endl;
     debug_file_close();
}

void MeshPartitioner::DEBUG_count_elems_part

(

)

Definition at line 765 of file MeshPartitioner.cpp.

References _colDim, _debugFile, _nelems, debug_file_close(), and debug_file_open().

Referenced by count_elems_part().

{
  //open debug file
  debug_file_open("count_elems_part");
  //_nelems
  _debugFile << "_nelems = " << _nelems.at(0) << endl;
  _debugFile << endl;
  //_colDim
  _debugFile << "_colDim = " << _colDim.at(0) << endl;
  //close debug file
  debug_file_close();



}

void MeshPartitioner::DEBUG_CRConnectivity_cellCells2

(

)

Definition at line 3038 of file MeshPartitioner.cpp.

References _meshListLocal, CRConnectivityPrintFile(), debug_file_close(), and debug_file_open().

{
    const CRConnectivity& cellCells2 = _meshListLocal[0]->getCellCells2();
    //openfile
    debug_file_open("CRConnectivity_cellCells2");
    //print connectivity
    CRConnectivityPrintFile( cellCells2, "CellCells2" );
   //close file
    debug_file_close();
}

void MeshPartitioner::DEBUG_CRConnectivity_cellParts

(

)

Definition at line 1249 of file MeshPartitioner.cpp.

References _cellParts, _debugFile, debug_file_close(), and debug_file_open().

Referenced by CRConnectivity_cellParts().

{
    //open file
    debug_file_open("CRConnectivity_cellParts");
    //_cellParts
    _debugFile << " _cellParts : " << endl;
    _debugFile << endl;
    _debugFile << " _cellParts->getRowDim() = " << _cellParts.at(0)->getRowDim() << endl;
    _debugFile << " _cellParts->getColDim() = " << _cellParts.at(0)->getColDim() << endl;
    _debugFile << endl;
    const Array<int>&   rowCellParts = _cellParts.at(0)->getRow();
    const Array<int>&   colCellParts = _cellParts.at(0)->getCol();
    for ( int n  = 0;n < _cellParts.at(0)->getRowDim(); n++){
        _debugFile << " row[" << n << "] = " << rowCellParts[n] << "    ";
        int nnodes = rowCellParts[n+1] - rowCellParts[n];
        for ( int node = 0; node < nnodes; node++){
             _debugFile  << colCellParts[ rowCellParts[n] + node ] << "    ";
        }
        _debugFile << endl;
    }
   //close file
   debug_file_close();

}

void MeshPartitioner::DEBUG_CRConnectivity_faceParts

(

)

Definition at line 1293 of file MeshPartitioner.cpp.

References _debugFile, _faceParts, debug_file_close(), and debug_file_open().

Referenced by CRConnectivity_faceParts().

{
   //open file
   debug_file_open("CRConnectivity_faceParts");
   //faceParts
   _debugFile << " _faceParts : " << endl;
   _debugFile << endl;
   _debugFile << " _faceParts->getRowDim() = " << _faceParts.at(0)->getRowDim() << endl;
   _debugFile << " _faceParts->getColDim() = " << _faceParts.at(0)->getColDim() << endl;
    const Array<int>&   rowFaceParts = _faceParts.at(0)->getRow();
    const Array<int>&   colFaceParts = _faceParts.at(0)->getCol();
    for ( int n = 0; n < _faceParts.at(0)->getRowDim();n++){
        _debugFile << " row[" << n <<"] = " ;
        int nnodes = rowFaceParts[n+1] - rowFaceParts[n];
        for ( int node = 0; node < nnodes; node++){
            _debugFile << colFaceParts[ rowFaceParts[n] + node ] << "    ";
        }
        _debugFile << endl;
    }

    _debugFile << endl;
   //close file
   debug_file_close();


}

void MeshPartitioner::DEBUG_elem_connectivity

(

)

Definition at line 546 of file MeshPartitioner.cpp.

References _debugFile, _eElm, _eInd, _elemDist, _ePtr, _procID, debug_file_close(), and debug_file_open().

Referenced by elem_connectivity().

{
    debug_file_open("elem_connectivity");
    //ePtr
    _debugFile << " _ePtr :" << endl;
    _debugFile << endl;
    int mesh_nlocal = (*_elemDist.at(0))[_procID];
     for ( int i = 0; i <= mesh_nlocal; i++ ){
         _debugFile << " _ePtr[" << i << "] = " << _ePtr[0][i] << endl;
     }
    _debugFile << endl;
    //eInd
    _debugFile << "_eInd : " << endl;
    _debugFile << endl;
    for ( int i = 0; i < mesh_nlocal; i++ ){
       _debugFile << "_eInd[" << i << "], glblCellID =  " << setw(3) << _eElm.at(0)[i] << ",  ";
       for ( int j = _ePtr[0][i]; j < _ePtr[0][i+1]; j++ ){
           _debugFile << setw(5) <<  _eInd.at(0)[j] << "   ";
       }
       _debugFile << endl;
    }
    _debugFile << endl;
    debug_file_close();
}

void MeshPartitioner::DEBUG_exchange_interface_meshes

(

)

Definition at line 1986 of file MeshPartitioner.cpp.

References _debugFile, _ghostCellsGlobal, _ghostCellsLocal, _interfaceMeshCounts, _interfaceMeshIDs, _nPart, _offsetInterfaceCells, debug_file_close(), and debug_file_open().

Referenced by exchange_interface_meshes().

{
     debug_file_open("exchange_interface_meshes");
     //interfaceMesheCounts
     for ( int proc = 0; proc < _nPart.at(0); proc++)
         _debugFile << " total mesh surrounding = " << (*_interfaceMeshCounts.at(0))[proc] << endl;
     _debugFile << endl;

     //ofsest
     _debugFile << " offset for ghost Cells from adjacent meshes to read data from _ghostCellsGlobal : "  << endl;
     for ( int n = 0; n < _offsetInterfaceCells.at(0)->getLength(); n++ )
         _debugFile << "    n  =  " << n << " offsetInterfaceCells = " << (*_offsetInterfaceCells.at(0))[n] << endl;
     _debugFile << endl;
     //interfaceMeshIDs
     _debugFile << " neightboorhood cell IDs : "  << endl;
     for ( int n = 0; n < _interfaceMeshIDs.at(0)->getLength(); n++ )
        _debugFile << "    n  =  " << n << "  interfaced Mesh ID = " <<  (*_interfaceMeshIDs.at(0))[n] << endl;
     _debugFile << endl;

     //global Interface cells (interior ones, global numbering)
     _debugFile << "interface cells looking interior domain (global numbering)  : " << endl;
      for ( int n = 0; n < _ghostCellsGlobal.at(0)->getLength(); n++ )
         _debugFile << "    n  =  " << n << "  cell ID = " <<  (*_ghostCellsGlobal.at(0))[n] << endl;

     //global Interface cells (interior ones, global numbering)
     _debugFile << "interface cells looking interior domain (local numbering)  : " << endl;
     for ( int n = 0; n < _ghostCellsLocal.at(0)->getLength(); n++ )
         _debugFile << "    n  =  " << n << "  interfaced Mesh ID = " <<  (*_ghostCellsLocal.at(0))[n] << endl;
     debug_file_close();

}

void MeshPartitioner::DEBUG_exchange_part_elems

(

)

Definition at line 923 of file MeshPartitioner.cpp.

References _col, _colDim, _debugFile, _elem, _nelems, _row, debug_file_close(), and debug_file_open().

Referenced by exchange_part_elems().

{
     debug_file_open("exchange_part_elems");
     //_row
     for ( int n = 0; n < _nelems.at(0)+1; n++){
         _debugFile << " _row[" << n << "] = " << _row.at(0)[n] << endl;
     }
     _debugFile << endl;
     //_col
     for ( int n = 0; n < _colDim.at(0); n++){
        _debugFile << " _col[" << n << "] = " << _col.at(0)[n] << endl;
     }
     _debugFile << endl;
     //elem
     for ( int n = 0; n < _nelems.at(0); n++){
         _debugFile << " _elem[" << n << "] = " << _elem.at(0)[n] << endl;
     }
     _debugFile << endl;
     debug_file_close();

}

void MeshPartitioner::DEBUG_faceCells_faceNodes

(

)

Definition at line 1367 of file MeshPartitioner.cpp.

References _cellCells, _cellNodes, _debugFile, _faceCells, _faceNodes, _nelems, _partFaces, _procID, debug_file_close(), debug_file_open(), and Array< T >::getLength().

Referenced by faceCells_faceNodes().

{
   //open file
   debug_file_open("faceCells_faceNodes");
   _debugFile << "faceCells_faceNodes : " << endl;
   _debugFile << endl;

   const Array<int>&   globalToLocalMap = _faceCells.at(0)->getGlobalToLocalMap();
   const Array<int>&   localToGlobalMap = _faceCells.at(0)->getLocalToGlobalMap();
   _debugFile << " globalToLocalMap.length() = " << globalToLocalMap.getLength() << endl;
   for ( int n = 0; n < globalToLocalMap.getLength(); n++)
       _debugFile << " globalToLocalMap[" << n << "] = " << globalToLocalMap[n] << endl;
   _debugFile << endl;
   _debugFile << " localToGlobalMap.length() = " << localToGlobalMap.getLength() << endl;
   for ( int n = 0; n < _nelems.at(0); n++)
       _debugFile << " localToGlobalMap[" << n << "] = " << localToGlobalMap[n] << endl;
   _debugFile << endl;

   //faceCells
   _debugFile << " _faceCells :  " << endl;
   _debugFile << " _faceCells->getRowDim() = " << _faceCells.at(0)->getRowDim() << endl;
   _debugFile << " _faceCells->getColDim() = " << _faceCells.at(0)->getColDim() << endl;
   const Array<int>&   rowFaceCells = _faceCells.at(0)->getRow();
   const Array<int>&   colFaceCells = _faceCells.at(0)->getCol();
   for ( int face = 0; face < _faceCells.at(0)->getRowDim(); face++){
      _debugFile << " row[" << face <<"] = " << (*_partFaces.at(0))(_procID,face) << "    ";
      int ncells = _faceCells.at(0)->getCount(face);
      for ( int cell = 0; cell < ncells; cell++){
         _debugFile << colFaceCells[ rowFaceCells[face] + cell ] << "    ";
      }
      _debugFile << endl;
   }
   _debugFile << endl;
   //faceNodes
   _debugFile << " _faceNodes :  " << endl;
   _debugFile << " _faceNodes->getRowDim() = " << _faceNodes.at(0)->getRowDim() << endl;
   _debugFile << " _faceNodes->getColDim() = " << _faceNodes.at(0)->getColDim() << endl;
   const Array<int>&   rowFaceNodes = _faceNodes.at(0)->getRow();
   const Array<int>&   colFaceNodes = _faceNodes.at(0)->getCol();

   for ( int face = 0; face < _faceNodes.at(0)->getRowDim(); face++){
       _debugFile << " row[" << face <<"] = " << (*_partFaces.at(0))(_procID,face) << "    ";
       int nnodes = _faceNodes.at(0)->getCount(face);
       for ( int node = 0; node < nnodes; node++){
           _debugFile << colFaceNodes[ rowFaceNodes[face] + node ] << "    ";
       }
       _debugFile << endl;
   }
   _debugFile << endl;
   //faceNodes
   _debugFile << " _cellNodes(Local Numbering) :  " << endl;
   _debugFile << " _cellNodes->getRowDim() = " << _cellNodes.at(0)->getRowDim() << endl;
   _debugFile << " _cellNodes->getColDim() = " << _cellNodes.at(0)->getColDim() << endl;
   const Array<int>&   rowCellNodes = _cellNodes.at(0)->getRow();
   const Array<int>&   colCellNodes = _cellNodes.at(0)->getCol();

   for ( int cell = 0; cell < _cellNodes.at(0)->getRowDim(); cell++){
       _debugFile << " row[" << cell  << "]  = " ;
       int nnodes = _cellNodes.at(0)->getCount(cell);
       for ( int node = 0; node < nnodes; node++){
          _debugFile << colCellNodes[ rowCellNodes[cell] + node ] << "    ";
       }
       _debugFile << endl;
   }
   _debugFile << endl;
   //cellCells
   _debugFile << " _cellCells :  " << endl;
   _debugFile << " _cellCells->getRowDim() = " << _cellCells.at(0)->getRowDim() << endl;
   _debugFile << " _cellCells->getColDim() = " << _cellCells.at(0)->getColDim() << endl;
   const Array<int>&   rowCellCells = _cellCells.at(0)->getRow();
   const Array<int>&   colCellCells = _cellCells.at(0)->getCol();

   for ( int cell = 0; cell < _cellCells.at(0)->getRowDim(); cell++){
       _debugFile << " row[" << cell <<"] = "  << "    ";
       int nnodes = _cellCells.at(0)->getCount(cell);
       for ( int node = 0; node < nnodes; node++){
          _debugFile << colCellCells[ rowCellCells[cell] + node ] << "    ";
       }
       _debugFile << endl;
   }
   _debugFile << endl;
   //close file
   debug_file_close();

}

void MeshPartitioner::DEBUG_fiedler_partition

(

)

Definition at line 658 of file MeshPartitioner.cpp.

References _debugFile, _elemDist, _fiedlerMap, _globalIndx, _meshList, _part, _procID, _totElems, CRConnectivityPrintFile(), debug_file_close(), and debug_file_open().

Referenced by fiedler_partition().

{
   debug_file_open("fiedler_partition");
   //_fieldermap
   _debugFile << "Fiedler Map :" << endl;
   _debugFile << endl;
    int totElms = _totElems[0];
    for ( int n = 0; n < totElms; n++ )
       _debugFile << "_fiedlerMap[" << n << "] = " <<  (*_fiedlerMap)[n] << endl;
    _debugFile << endl;
    //_part
   _debugFile << "_part :" << endl;
   _debugFile << endl;
   int elem_start   = (*_globalIndx.at(0))[_procID];
   int elem_finish  = elem_start + (*_elemDist[0])[_procID];
   int indx = 0;
   for ( int i = elem_start; i < elem_finish; i++ ){
      _debugFile << "_part[" << indx << "] = " << _part.at(0)[indx] << endl;
      indx++;
   }
   _debugFile << endl;
   //faceCells after Fiedler
   CRConnectivity&  faceCells = _meshList[0]->getAllFaceCells();
   CRConnectivityPrintFile( faceCells, "faceCells" );
   debug_file_close();

}

void MeshPartitioner::debug_file_close ( )

private

Definition at line 3422 of file MeshPartitioner.cpp.

References _debugFile.

Referenced by DEBUG_cellcells_global(), DEBUG_compute_elem_dist(), DEBUG_coordinates(), DEBUG_count_elems_part(), DEBUG_CRConnectivity_cellCells2(), DEBUG_CRConnectivity_cellParts(), DEBUG_CRConnectivity_faceParts(), DEBUG_elem_connectivity(), DEBUG_exchange_interface_meshes(), DEBUG_exchange_part_elems(), DEBUG_faceCells_faceNodes(), DEBUG_fiedler_partition(), DEBUG_gatherCellsLevel1_partID_map(), DEBUG_globalCellID_procID_map(), DEBUG_interfaces(), DEBUG_level1_scatter_gather_cells(), DEBUG_local_global(), DEBUG_map_part_elms(), DEBUG_mapBounIDAndCell(), DEBUG_non_interior_cells(), DEBUG_order_faceCells_faceNodes(), DEBUG_parmetis_mesh(), DEBUG_preserve_cell_order(), and DEBUG_resize_elem().

{
    _debugFile.close();
}

void MeshPartitioner::debug_file_open ( const string &  fname )

private

Definition at line 3411 of file MeshPartitioner.cpp.

References _debugFile, and _procID.

Referenced by DEBUG_cellcells_global(), DEBUG_compute_elem_dist(), DEBUG_coordinates(), DEBUG_count_elems_part(), DEBUG_CRConnectivity_cellCells2(), DEBUG_CRConnectivity_cellParts(), DEBUG_CRConnectivity_faceParts(), DEBUG_elem_connectivity(), DEBUG_exchange_interface_meshes(), DEBUG_exchange_part_elems(), DEBUG_faceCells_faceNodes(), DEBUG_fiedler_partition(), DEBUG_gatherCellsLevel1_partID_map(), DEBUG_globalCellID_procID_map(), DEBUG_interfaces(), DEBUG_level1_scatter_gather_cells(), DEBUG_local_global(), DEBUG_map_part_elms(), DEBUG_mapBounIDAndCell(), DEBUG_non_interior_cells(), DEBUG_order_faceCells_faceNodes(), DEBUG_parmetis_mesh(), DEBUG_preserve_cell_order(), and DEBUG_resize_elem().

{
    stringstream ss(stringstream::in | stringstream::out);
    ss <<  _procID;

     string  fname = "MeshPartitioner_PROC" + ss.str() + "_" +  fname_ + ".dat";
    _debugFile.open( fname.c_str() );
    ss.str("");
}

void MeshPartitioner::DEBUG_gatherCellsLevel1_partID_map

(

)

Definition at line 2601 of file MeshPartitioner.cpp.

References _debugFile, _gatherCellsLevel1PartIDMap, debug_file_close(), and debug_file_open().

Referenced by gatherCellsLevel1_partID_map().

{
   //open file
   debug_file_open("gatherCellsLevel1_partID_map");
   foreach ( const IntMap::value_type& mpos, _gatherCellsLevel1PartIDMap){
       const int globalID = mpos.first;
       const int partID   = mpos.second;
       _debugFile << " global CellID = " << globalID << "   partition ID = " << partID << endl;
   }
   //close file
   debug_file_close();
}

void MeshPartitioner::DEBUG_globalCellID_procID_map

(

)

Definition at line 2541 of file MeshPartitioner.cpp.

References _cellsLevel1PartID, _debugFile, debug_file_close(), and debug_file_open().

Referenced by globalCellID_procID_map().

{
   //open file
   debug_file_open("globalCellID_procID_map");
   foreach ( const IntMap::value_type& mpos, _cellsLevel1PartID){
       const int globalID = mpos.first;
       const int partID   = mpos.second;
       _debugFile << " global CellID = " << globalID << "   partition ID = " << partID << endl;
   }
   //close file
   debug_file_close();
}

void MeshPartitioner::DEBUG_interfaces

(

)

Definition at line 1490 of file MeshPartitioner.cpp.

References _debugFile, _interfaceMap, _nPart, _partFaces, _procID, debug_file_close(), and debug_file_open().

Referenced by interfaces().

{
    //open file
    debug_file_open("interfaces");
    //interfaceMap
    pair<multimap<int,int>::iterator,multimap<int,int>::iterator> ret;
    _debugFile << "_InterfaceMap : " << endl;
    _debugFile << endl;
    _debugFile << "_interfaceMap.size() = " <<  _interfaceMap.at(0).size() << endl;
    _debugFile << endl;
    multimap<int,int>::iterator it_multimap;
    for ( int part = 0; part < _nPart.at(0); part++ ){
         ret = _interfaceMap.at(0).equal_range(part);
         _debugFile  << " interface ID =  "  << part << "  =>  ";
         for (it_multimap=ret.first; it_multimap!=ret.second; ++it_multimap)
             _debugFile  <<  (*_partFaces.at(0))(_procID,  (*it_multimap).second) << "  ";
         _debugFile << endl;
    }
    _debugFile << endl;
    //close file
    debug_file_close();

}

void MeshPartitioner::DEBUG_level1_scatter_gather_cells

(

)

Definition at line 2983 of file MeshPartitioner.cpp.

References _debugFile, _meshListLocal, _nmesh, debug_file_close(), debug_file_open(), Mesh::getCells(), StorageSite::getGatherMapLevel1(), Mesh::getGhostCellSiteGatherMapLevel1(), Mesh::getGhostCellSiteScatterMapLevel1(), Array< T >::getLength(), and StorageSite::getScatterMapLevel1().

Referenced by level1_scatter_gather_cells().

{
    //open file
    debug_file_open("level1_scatter_gather_cells");
    //scatter cells
    for ( int id = 0; id < _nmesh; id++ ){
          const Mesh& mesh = *_meshListLocal.at(id);
          const StorageSite& cellSite = mesh.getCells();
          const StorageSite::ScatterMap& cellSiteScatterMapLevel1 = cellSite.getScatterMapLevel1();
          //get scatter map  key ={neight part id, mesh id}, value = scatter storage site
          const Mesh::GhostCellSiteMap& ghostSiteScatterMapLevel1 = mesh.getGhostCellSiteScatterMapLevel1();
          _debugFile << "This Mesh ID (Scatter Cells) = " << id << endl;
          //loop over scatter mappers
          foreach ( const Mesh::GhostCellSiteMap::value_type& mpos, ghostSiteScatterMapLevel1 ){
              const Mesh::PartIDMeshIDPair& pairID = mpos.first;
              const StorageSite& siteScatter  =  *(mpos.second);
              const Array<int>&  scatterArray =  *(cellSiteScatterMapLevel1.find( &siteScatter )->second);
              const int neighProcID     = pairID.first;
              const int neighMeshID = pairID.second;
             _debugFile << "    neighProcID = " << neighProcID << "  neighMeshID = " << neighMeshID << endl;
              for ( int i = 0; i < scatterArray.getLength(); i++ ){
                   _debugFile << "     " << scatterArray[i] << endl;
              }
          }
    }

   //gather cells
    for ( int id = 0; id < _nmesh; id++ ){
          const Mesh& mesh = *_meshListLocal.at(id);
          const StorageSite& cellSite = mesh.getCells();
          const StorageSite::GatherMap& cellSiteGatherMapLevel1 = cellSite.getGatherMapLevel1();
          //get scatter map  key ={neight part id, mesh id}, value = scatter storage site
          const Mesh::GhostCellSiteMap& ghostSiteGatherMapLevel1 = mesh.getGhostCellSiteGatherMapLevel1();
          _debugFile << "This Mesh ID (Gather Cells) = " << id << endl;
          //loop over scatter mappers
          foreach ( const Mesh::GhostCellSiteMap::value_type& mpos, ghostSiteGatherMapLevel1 ){
              const Mesh::PartIDMeshIDPair& pairID = mpos.first;
              const StorageSite& siteGather  =  *(mpos.second);
              const Array<int>&  gatherArray =  *(cellSiteGatherMapLevel1.find( &siteGather )->second);
              const int neighProcID     = pairID.first;
              const int neighMeshID = pairID.second;
             _debugFile << "    neighProcID = " << neighProcID << "  neighMeshID = " << neighMeshID << endl;
              for ( int i = 0; i < gatherArray.getLength(); i++ ){
                   _debugFile << "     " << gatherArray[i] << endl;
              }
          }
    }

    //close file
    debug_file_close();

}

void MeshPartitioner::DEBUG_local_global

(

)

Definition at line 2221 of file MeshPartitioner.cpp.

References _debugFile, _meshListLocal, debug_file_close(), debug_file_open(), Mesh::getGlobalToLocal(), Array< T >::getLength(), Mesh::getLocalToGlobal(), and global_offset().

Referenced by set_local_global().

{
   //open file
   debug_file_open("local_to_global");
   //print offsets
   _debugFile << " offset = " << global_offset() << endl;
   //print Mesh::localToGlobal array
   const int nmesh = int( _meshListLocal.size() );
   //loop over meshes
    for ( int id = 0; id < nmesh; id++ ){
       const Mesh& mesh = *_meshListLocal.at(id);
       const Array<int>& localToGlobal = mesh.getLocalToGlobal();
       _debugFile << "Mesh ID = " << id << endl;
       for ( int i = 0; i < localToGlobal.getLength(); i++ ){
           _debugFile << "   localToGlobal[" << i << "] = " << localToGlobal[i] << endl;
       }
    }
    for ( int id = 0; id < nmesh; id++ ){
       const Mesh& mesh = *_meshListLocal.at(id);
       const map<int,int>& globalToLocal = mesh.getGlobalToLocal();
       _debugFile << "Mesh ID = " << id << endl;
       foreach ( const IntMap::value_type& mpos, globalToLocal ){
           _debugFile << "   globalToLocal[" << mpos.first << "] = " << mpos.second << endl;
       }
    }

    debug_file_close();
}

void MeshPartitioner::DEBUG_map_part_elms

(

)

Definition at line 704 of file MeshPartitioner.cpp.

References _debugFile, _mapPartAndElms, _nPart, debug_file_close(), and debug_file_open().

Referenced by map_part_elms().

{
   //open file
   debug_file_open("map_part_elms");
   //header
   _debugFile << " _mapPartAndElms : " << endl;
   _debugFile << endl;
   for ( int p = 0; p < _nPart[0]; p++){
       multimap<int,int>::iterator it, itlow, itup;
       itlow = _mapPartAndElms.at(0).lower_bound(p);
       itup  = _mapPartAndElms.at(0).upper_bound(p);
       for( it = itlow; it != itup; it++)
          _debugFile << " partID = " << it->first << " elemID = " << it->second << endl;
   }
   _debugFile  << endl;
   //close file
   debug_file_close();

}

void MeshPartitioner::DEBUG_mapBounIDAndCell

(

)

Definition at line 1086 of file MeshPartitioner.cpp.

References _boundarySet, _debugFile, _elemSet, _mapBounIDAndBounType, _mapBounIDAndCell, debug_file_close(), and debug_file_open().

Referenced by mapBounIDAndCell().

{
    //open file
    debug_file_open("mapBounIDAndCell");
     //_elemset
     _debugFile << "_boundarySet : " << endl;
     _debugFile << endl;
     foreach(  const set<int>::value_type id ,_boundarySet.at(0) ){
         _debugFile <<  id << endl;
     }
     _debugFile << endl;
     //dump boundary names
     _debugFile << "_mapBounIDAndBounType : " << endl;
     _debugFile << endl;
     multimap<int,string>::iterator it_multimapS;
     for ( it_multimapS  = _mapBounIDAndBounType.at(0).begin();
           it_multimapS != _mapBounIDAndBounType.at(0).end(); it_multimapS++)
          _debugFile << "Boundary multimap = " << it_multimapS->first << "    " << it_multimapS->second << endl;
     _debugFile << endl;
     //_elemset
     _debugFile << "_elemSet : " << endl;
     _debugFile << endl;
     foreach(  const set<int>::value_type cellID ,_elemSet.at(0) ){
         _debugFile <<  cellID << endl;
     }
     _debugFile << endl;
    //boundaryID to Cell
    multimap<int,int>::iterator it_multimap;
    for ( it_multimap  = _mapBounIDAndCell.at(0).begin();
          it_multimap != _mapBounIDAndCell.at(0).end(); it_multimap++)
    _debugFile << "Boundary multimap = " << it_multimap->first << "    " << it_multimap->second << endl;
    _debugFile << endl;

    debug_file_close();
}

void MeshPartitioner::DEBUG_mesh

(

)

Definition at line 3115 of file MeshPartitioner.cpp.

References mesh_file(), and mesh_tecplot().

Referenced by mappers().

{
    mesh_file();
    mesh_tecplot();


}

void MeshPartitioner::DEBUG_non_interior_cells

(

)

Definition at line 1585 of file MeshPartitioner.cpp.

References _debugFile, _nonInteriorCells, debug_file_close(), and debug_file_open().

Referenced by non_interior_cells().

{
     //open
     debug_file_open("non_interior_cells");
     set<int>::const_iterator it_set;
     //non-interior cells (only for last mesh)
     _debugFile << "_nonInteriorCells : " << endl;
     _debugFile << endl;
     _debugFile << "total non-interior cells  = " << _nonInteriorCells.at(0).size() << endl;
     _debugFile << endl;
     for ( it_set = _nonInteriorCells.at(0).begin(); it_set != _nonInteriorCells.at(0).end(); it_set++ )
         _debugFile <<  "      " <<  *it_set  << endl;

     _debugFile << endl;
    //close
    debug_file_close();

}

void MeshPartitioner::DEBUG_order_faceCells_faceNodes

(

)

Definition at line 1839 of file MeshPartitioner.cpp.

References _debugFile, _faceCellsOrdered, _faceNodesOrdered, debug_file_close(), and debug_file_open().

Referenced by order_faceCells_faceNodes().

{
    //openfile
    debug_file_open("order_faceCells_faceNodes");
    //faceCellsOrdered
    _debugFile << " _faceCellsOrdered :  " << endl;
    _debugFile << " _faceCellsOrdered->getRowDim() = " << _faceCellsOrdered.at(0)->getRowDim() << endl;
    _debugFile << " _faceCellsOrdered->getColDim() = " << _faceCellsOrdered.at(0)->getColDim() << endl;
    const Array<int>& rowFaceCellsOrdered = _faceCellsOrdered.at(0)->getRow();
    const Array<int>& colFaceCellsOrdered = _faceCellsOrdered.at(0)->getCol();
    for ( int face = 0; face < _faceCellsOrdered.at(0)->getRowDim(); face++){
        _debugFile << " row[" << face <<"] = " ;
        int ncells = _faceCellsOrdered.at(0)->getCount(face);
        for ( int cell = 0; cell < ncells; cell++){
           _debugFile << colFaceCellsOrdered[ rowFaceCellsOrdered[face] + cell ]  << "    ";
        }
        _debugFile << endl;
     }
     _debugFile << endl;

    //faceNodes
    _debugFile << " _faceNodesOrdered :  " << endl;
    _debugFile << " _faceNodesOrdered->getRowDim() = " << _faceNodesOrdered.at(0)->getRowDim() << endl;
    _debugFile << " _faceNodesOrdered->getColDim() = " << _faceNodesOrdered.at(0)->getColDim() << endl;
    const Array<int>& rowFaceNodesOrdered = _faceNodesOrdered.at(0)->getRow();
    const Array<int>& colFaceNodesOrdered = _faceNodesOrdered.at(0)->getCol();

    for ( int face = 0; face < _faceNodesOrdered.at(0)->getRowDim(); face++){
       _debugFile << " row[" << face<<"] = " ;
       int nnodes = _faceNodesOrdered.at(0)->getCount(face);
       for ( int node = 0; node < nnodes; node++){
           _debugFile << colFaceNodesOrdered[ rowFaceNodesOrdered[face] + node ]+1 << "    ";
       }
       _debugFile << endl;
    }
    _debugFile << endl;

   //close
   debug_file_close();
}

void MeshPartitioner::DEBUG_parmetis_mesh

(

)

Definition at line 590 of file MeshPartitioner.cpp.

References _debugFile, _elemDist, _globalIndx, _part, _procID, debug_file_close(), and debug_file_open().

Referenced by parmetis_mesh().

{

   debug_file_open("parmetis_mesh");
    //_part
   _debugFile << "_part :" << endl;
   _debugFile << endl;
   int elem_start   = (*_globalIndx.at(0))[_procID];
   int elem_finish  = elem_start + (*_elemDist[0])[_procID];
   int indx = 0;
   for ( int i = elem_start; i < elem_finish; i++ ){
      _debugFile << "_part[" << indx << "] = " << _part.at(0)[indx] << endl;
      indx++;
   }
   _debugFile << endl;
   debug_file_close();

}

void MeshPartitioner::DEBUG_preserve_cell_order

(

)

Definition at line 1638 of file MeshPartitioner.cpp.

References _cellToPreservedOrderCell, _debugFile, _globalToLocal, debug_file_close(), and debug_file_open().

Referenced by preserve_cell_order().

{
   //file open
   debug_file_open("preserve_cell_order");
   _debugFile << "_cellToPreservedOrderCell : " << endl;
   _debugFile << endl;
   foreach ( const IntMap::value_type& pos, _cellToPreservedOrderCell )
      _debugFile << pos.first << "       "  <<  pos.second << endl;

   _debugFile << endl;
   _debugFile << " _globalToLocal : " << endl;
   _debugFile << endl;

   foreach ( const IntMap::value_type& pos, _globalToLocal ){
      _debugFile << "glblID = " << pos.first << ",    localID  =  " <<  pos.second << endl;
   }

   //close
   debug_file_close();

}

void MeshPartitioner::debug_print

(

)

void MeshPartitioner::DEBUG_resize_elem

(

)

Definition at line 1147 of file MeshPartitioner.cpp.

References _debugFile, _elemWithGhosts, _nelemsWithGhosts, debug_file_close(), and debug_file_open().

Referenced by resize_elem().

{
   //open file
   debug_file_open("resize_elem");
   //_nelemsWithGhosts
   _debugFile << "_nelemsWithGhosts : " << _nelemsWithGhosts.at(0) << endl;
   _debugFile << endl;
    //_elemWithGhosts
   _debugFile << "_elemWithGhosts : " << endl;
   _debugFile << endl;
    for ( int n = 0; n < _nelemsWithGhosts.at(0); n++ )
       _debugFile << _elemWithGhosts.at(0)[n] << endl;
   //close file
   debug_file_close();

}

void MeshPartitioner::elem_connectivity ( )

private

Definition at line 461 of file MeshPartitioner.cpp.

References _debugMode, _eElm, _eInd, _elemDist, _elmWght, _ePtr, _globalIndx, _meshList, _ncon, _nmesh, _procID, _wghtFlag, DEBUG_elem_connectivity(), get_local_nodes(), NOWEIGHTS, set_eptr_eind(), and WEIGTHS_ONLY_VERTICES.

Referenced by partition().

{

   for (int id = 0; id < _nmesh; id++){
       //allocate local ePtr for parMetis
       int mesh_nlocal = (*_elemDist.at(id))[_procID];
      _ePtr.push_back( new int[mesh_nlocal+1] );
      _eElm.push_back( new int[mesh_nlocal+1] );
       //element weights
      _elmWght.push_back( new int[_ncon.at(id)*mesh_nlocal] );
       if (  !_meshList.at(id)->isMergedMesh() ){
          _wghtFlag.at(id) = int( NOWEIGHTS ); //No Weights : default value
          for ( int n = 0; n < _ncon.at(id)*mesh_nlocal; n++)
             _elmWght.at(id)[n] = 1;
       } else {
          _wghtFlag.at(id) = int( WEIGTHS_ONLY_VERTICES );
           const Array<int>& cellColors = _meshList.at(id)->getCellColors();
           int indx = 0 ;
           for ( int n =0; n < mesh_nlocal; n++ ){
              for ( int i = 0; i < _meshList.at(id)->getNumOfAssembleMesh(); i++ ){
                 _elmWght.at(id)[indx] = 0;
                  if ( cellColors[ (*_globalIndx[id])[_procID] + n ] == i )
                      _elmWght.at(id)[indx] = 1;
                  indx++;
              }
           }
       }
       //allocate local eInd for ParMETIS
      _eInd.push_back( new int[get_local_nodes(id)] );

//       //setting ePtr and eInd for ParMETIS
      set_eptr_eind(id);
   }

   if ( _debugMode )
      DEBUG_elem_connectivity();

}

void MeshPartitioner::exchange_interface_meshes ( )

private

Definition at line 1906 of file MeshPartitioner.cpp.

References _debugMode, _faceCellsOrdered, _ghostCellsGlobal, _ghostCellsLocal, _interfaceMap, _interfaceMeshCounts, _interfaceMeshIDs, _interfaceOffsets, _interfaceSet, _localToGlobalMappers, _nmesh, _nPart, _offsetInterfaceCells, _procTotalInterfaces, _windowSize, and DEBUG_exchange_interface_meshes().

Referenced by mesh().

{

    vector<int>  offset;
    vector<int>  interfaceMeshIDs;
    int *recv_counts = NULL;
    int *displ       = NULL;
    for ( int id = 0; id < _nmesh; id++){
        recv_counts = new int[ _nPart.at(id) ];
        displ       = new int[ _nPart.at(id) ];

        int total_interface_mesh = int( _interfaceSet.at(id).size() );
        int total_faces = int( _interfaceMap.at(id).size() );

        MPI::COMM_WORLD.Allgather(&total_interface_mesh, 1, MPI::INT, _interfaceMeshCounts.at(id)->getData(), 1, MPI::INT);
        MPI::COMM_WORLD.Allgather(&total_faces, 1, MPI::INT, _procTotalInterfaces.at(id)->getData(), 1, MPI::INT);

        //now find offsets for ghostCells
        int total_interface_local = _interfaceSet.at(id).size();
        int total_interface_global = -1;

        MPI::COMM_WORLD.Allreduce( &total_interface_local, &total_interface_global, 1, MPI::INT, MPI::SUM );
        MPI::COMM_WORLD.Allgather( &total_interface_local, 1, MPI::INT, recv_counts, 1, MPI::INT );
        MPI::COMM_WORLD.Allreduce( &total_faces, &_windowSize.at(id), 1, MPI::INT, MPI::MAX);

      //enough space for gathering
       _offsetInterfaceCells.push_back(  ArrayIntPtr( new Array<int>(total_interface_global) )  );
       _interfaceMeshIDs.push_back    (  ArrayIntPtr( new Array<int>(total_interface_global) )  );

       _ghostCellsGlobal.push_back    (  ArrayIntPtr( new Array<int>(total_faces ) )  );
       _ghostCellsLocal.push_back     (  ArrayIntPtr( new Array<int>(total_faces ) )  );

        //local offset and interfaceMeshID are stored in contigous memory
        int index = 0;
        set<int>::const_iterator it_set;
        for ( it_set = _interfaceSet.at(id).begin(); it_set != _interfaceSet.at(id).end(); it_set++ ){
            int neighMeshID = *it_set;
            interfaceMeshIDs.push_back( neighMeshID );
            //loop over interface
             int  nstart = _interfaceOffsets.at(id)[neighMeshID];
             offset.push_back( nstart );

             int  nend  = nstart + _interfaceMap.at(id).count( neighMeshID );
            for ( int n = nstart;  n < nend; n++){
                  int elem_local_id  = (*_faceCellsOrdered.at(id))(n,0);
                  int elem_global_id = _localToGlobalMappers.at(id)[ elem_local_id ];

                 (*_ghostCellsLocal.at(id))[index]  = elem_local_id;
                 (*_ghostCellsGlobal.at(id))[index] = elem_global_id;
                 index++;
            }

        }

        displ[0] = 0;
        for ( int i = 1; i < _nPart.at(id); i++)
            displ[i] = recv_counts[i-1] + displ[i-1];


         //now gather for _interface...
         MPI::COMM_WORLD.Allgatherv( &offset[0], total_interface_local, MPI::INT,
                  _offsetInterfaceCells.at(id)->getData(), recv_counts, displ, MPI::INT);

         MPI::COMM_WORLD.Allgatherv( &interfaceMeshIDs[0], total_interface_local, MPI::INT,
                  _interfaceMeshIDs.at(id)->getData(), recv_counts, displ, MPI::INT);

       offset.clear();
       interfaceMeshIDs.clear();

       delete [] recv_counts;
       delete [] displ;

    }

   if ( _debugMode )
      DEBUG_exchange_interface_meshes();

}

void MeshPartitioner::exchange_part_elems ( )

private

Definition at line 784 of file MeshPartitioner.cpp.

References _cleanup, _col, _debugMode, _eElm, _eInd, _elem, _ePtr, _mapPartAndElms, _nmesh, _nPart, _procID, _row, cleanup_follow_exchange_part_elems(), DEBUG_exchange_part_elems(), and shift_sum_row().

Referenced by partition().

{

   for ( int id = 0; id < _nmesh; id++){

       int *countsRow  =  new int[_nPart.at(id)];
       int *countsCol  =  new int[_nPart.at(id)];
       int *offsetsRow =  new int[_nPart.at(id)];
       int *offsetsCol =  new int[_nPart.at(id)];


       for ( int partID = 0; partID < _nPart.at(id); partID++){
          int nelems_local = _mapPartAndElms.at(id).count(partID);
          int *row_local  = new int[nelems_local];
          int *elem_local = new int[nelems_local];

           multimap<int,int>::const_iterator it = _mapPartAndElms.at(id).find(partID);
           multimap<int,int>::const_iterator itlow = _mapPartAndElms.at(id).lower_bound(partID);
           multimap<int,int>::const_iterator itup = _mapPartAndElms.at(id).upper_bound(partID);

           //fill row array
           int indx = 0;
           int ncol_local = 0;
           for ( it = itlow; it != itup; it++){
              int pos         = it->second;  // element number
              ncol_local     += _ePtr.at(id)[pos+1] - _ePtr.at(id)[pos];
              row_local[indx]  = _ePtr.at(id)[pos+1]-_ePtr.at(id)[pos]; //aggregation before shipping
              elem_local[indx] = _eElm.at(id)[pos];  //globalID stored in _eElm
              indx++;
           }

           //fill col array
           int *col_local = new int[ncol_local];
           indx = 0;
           for ( it = itlow; it != itup; it++ ){
              int elID = it->second;
              int node_start = _ePtr.at(id)[elID];
              int node_end   = _ePtr.at(id)[elID+1];
              for ( int node = node_start; node < node_end; node++){
                 col_local[indx++] = _eInd.at(id)[node];
              }
           }

         //forming counts
         int nrow_local = nelems_local;
         MPI::COMM_WORLD.Allgather(&nrow_local, 1, MPI::INT, countsRow, 1, MPI::INT);
         MPI::COMM_WORLD.Allgather(&ncol_local, 1, MPI::INT, countsCol, 1, MPI::INT);


        //form offsets
        offsetsRow[0]  = 0;
        offsetsCol[0]  = 0;
        for ( int p = 1; p < int(_nPart.at(id)); p++ ){
           offsetsRow[p]  = countsRow[p-1]  + offsetsRow[p-1];
           offsetsCol[p]  = countsCol[p-1]  + offsetsCol[p-1];
        }

        //gathering partial partions for _row and _col
        MPI::COMM_WORLD.Gatherv(row_local, countsRow[_procID], MPI::INT, _row.at(id),
                                countsRow, offsetsRow, MPI::INT, partID);

        MPI::COMM_WORLD.Gatherv(col_local, countsCol[_procID], MPI::INT, _col.at(id),
                                countsCol, offsetsCol, MPI::INT, partID);

        MPI::COMM_WORLD.Gatherv(elem_local, countsRow[_procID], MPI::INT, _elem.at(id),
                                countsRow, offsetsRow, MPI::INT, partID);


        delete [] row_local;
        delete [] col_local;
        delete [] elem_local;

       }  // for::partID

       delete [] countsRow ;
       delete [] countsCol ;
       delete [] offsetsRow;
       delete [] offsetsCol;

    }  // for::meshID


   shift_sum_row();

   //clean up
   if ( _cleanup )
      cleanup_follow_exchange_part_elems();

   if ( _debugMode )
      DEBUG_exchange_part_elems();

}

void MeshPartitioner::extractBoundaryMesh

(

)

Definition at line 2852 of file MeshPartitioner.cpp.

References _bMesh, _meshList, _meshListLocal, Mesh::createBoundaryFaceGroup(), Mesh::getBoundaryFaceGroups(), StorageSite::getCommonMap(), Mesh::getConnectivityMap(), StorageSite::getCount(), CRConnectivity::getCount(), Mesh::getDimension(), Mesh::getFaceNodes(), Mesh::getFaces(), Mesh::getNodeCoordinates(), Mesh::getNodes(), StorageSite::getScatterIndex(), Mesh::setCoordinates(), StorageSite::setCount(), and FaceGroup::site.

{
  const Mesh& mesh = *_meshList.at(0);
  Mesh& meshLocal = *_meshListLocal.at(0);
  const StorageSite& nodes = mesh.getNodes();
  StorageSite& nodesLocal = meshLocal.getNodes();
  const Array<Mesh::VecD3>& coords = mesh.getNodeCoordinates();
//   map<int,int>& globalToLocalNodesFromLocalMesh= meshLocal.getGlobalToLocalNodes();
//   map<int,int>& g

  const int nodeCount = nodes.getCount();
  Array<int> globalToLocalNodes(nodeCount);

  globalToLocalNodes = -1;
  int bMeshNodeCount=0;
  int bMeshFaceCount=0;
  foreach(const FaceGroupPtr fgPtr, mesh.getBoundaryFaceGroups()){
      const FaceGroup& fg = *fgPtr;
      const StorageSite& faces = fg.site;
      const int nFaces = faces.getCount();
      const CRConnectivity& faceNodes = mesh.getFaceNodes(faces);
      for(int f=0; f<nFaces; f++){
          const int nFaceNodes = faceNodes.getCount(f);
          for(int nn=0; nn<nFaceNodes; nn++){
              const int n=faceNodes(f,nn);
              if (globalToLocalNodes[n] == -1){
                 globalToLocalNodes[n] = bMeshNodeCount++;
              }
          }
      }
      bMeshFaceCount += nFaces;
  }

  _bMesh = new Mesh(mesh.getDimension());

  StorageSite& bMeshFaces = _bMesh->getFaces();
  StorageSite& bMeshNodes = _bMesh->getNodes();
  bMeshFaces.setCount( bMeshFaceCount );
  bMeshNodes.setCount( bMeshNodeCount );

  _bMesh->createBoundaryFaceGroup(bMeshFaceCount,0,0,"wall");

  //setting coordinates
  shared_ptr< Array<Mesh::VecD3> > bMeshCoordPtr( new Array< Mesh::VecD3 > ( bMeshNodeCount ) );

  shared_ptr<Mesh::IntArray> myCommonNodes(new Mesh::IntArray(bMeshNodeCount));
  shared_ptr<Mesh::IntArray> otherCommonNodes(new Mesh::IntArray(bMeshNodeCount));
  for(int n=0; n<nodeCount; n++)
  {
      const int nLocal = globalToLocalNodes[n];
      if (nLocal >=0)
      {
          (*bMeshCoordPtr)[nLocal] = coords[n];
          (*myCommonNodes)[nLocal] = nLocal;
          (*otherCommonNodes)[nLocal] = n;
      }
  }
  nodesLocal.getCommonMap()[&bMeshNodes] = myCommonNodes;
  bMeshNodes.getCommonMap()[&nodesLocal] = otherCommonNodes;
  //filling scatter index (global to local)
  map<int,int>& scatterIndex = nodesLocal.getScatterIndex()[&bMeshNodes];
  for ( int n = 0; n < bMeshNodeCount; n++ ){
     const int nodeID = (*otherCommonNodes)[n];
     scatterIndex[nodeID] = n;
  }



  _bMesh->setCoordinates( bMeshCoordPtr );

  //faceNodes constructor
  shared_ptr<CRConnectivity> bFaceNodes( new CRConnectivity(bMeshFaces,
                                                            bMeshNodes) );

  bFaceNodes->initCount();

  bMeshFaceCount=0;

  foreach(FaceGroupPtr fgPtr, mesh.getBoundaryFaceGroups()){
      FaceGroup& fg = *fgPtr;
      StorageSite& faces = const_cast<StorageSite&>(fg.site);
      const int nFaces = faces.getCount();
      const CRConnectivity& faceNodes = mesh.getFaceNodes(faces);

      shared_ptr<Mesh::IntArray> myCommonFaces(new Mesh::IntArray(nFaces));
      shared_ptr<Mesh::IntArray> otherCommonFaces(new Mesh::IntArray(nFaces));

      for(int f=0; f<nFaces; f++){
         const int nFaceNodes = faceNodes.getCount(f);
         bFaceNodes->addCount(bMeshFaceCount,nFaceNodes);
         (*myCommonFaces)[f] = bMeshFaceCount;
         (*otherCommonFaces)[f] = f;
         bMeshFaceCount++;
      }

      faces.getCommonMap()[&bMeshFaces] = myCommonFaces;
      bMeshFaces.getCommonMap()[&faces] = otherCommonFaces;
  }

  bFaceNodes->finishCount();
  bMeshFaceCount=0;

  foreach(const FaceGroupPtr fgPtr, mesh.getBoundaryFaceGroups()){
     const FaceGroup& fg = *fgPtr;
     const StorageSite& faces = fg.site;
     const int nFaces = faces.getCount();
     const CRConnectivity& faceNodes = mesh.getFaceNodes(faces);
     for(int f=0; f<nFaces; f++){
        const int nFaceNodes = faceNodes.getCount(f);
        for(int nn=0; nn<nFaceNodes; nn++){
           const int n=faceNodes(f,nn);
           const int nLocal = globalToLocalNodes[n];
           bFaceNodes->add(bMeshFaceCount,nLocal);
        }
        bMeshFaceCount++;
     }
  }

  bFaceNodes->finishAdd();
  //setting faceNodes
  Mesh::SSPair key(&bMeshFaces,&bMeshNodes);
  Mesh::ConnectivityMap& connectivityMap = _bMesh->getConnectivityMap();
  connectivityMap[key] = bFaceNodes;
  //_bMesh->_connectivityMap[key] = bFaceNodes;

}

void MeshPartitioner::faceCells_faceNodes ( )

private

Definition at line 1324 of file MeshPartitioner.cpp.

References _cellCells, _cellNodes, _cellParts, _cellSite, _cleanup, _debugMode, _faceCells, _faceCellsGlobal, _faceNodes, _faceNodesGlobal, _faceSite, _interfaceMap, _nelems, _nelemsWithGhosts, _nmesh, _nodeSite, _partFaces, _partNodes, _procID, cleanup_follow_faceCells_faceNodes(), and DEBUG_faceCells_faceNodes().

Referenced by mesh().

{
    vector< ArrayIntPtr  >   indices;

    for ( int id = 0; id < _nmesh; id++){
        //form site
        int face_count = _partFaces.at(id)->getCount( _procID );
        int node_count = _partNodes.at(id)->getCount( _procID );

        _faceSite.push_back( StorageSitePtr(new  StorageSite(face_count)) );
        _nodeSite.push_back( StorageSitePtr(new  StorageSite(node_count)) );

        const Array<int>&  row = _partFaces.at(id)->getRow();
        const Array<int>&  col = _partFaces.at(id)->getCol();
        //forming indices
        indices.push_back( ArrayIntPtr(new Array<int>( face_count )) );
        int n_start = row[_procID];
        int indx = 0;
        for ( int n = n_start; n < n_start + face_count; n++){
            (*indices.at(id))[indx] = col[n];
            indx++;
        }
        //getting subset from global _faceCellsGlobal and _faceNodesGlobal
        int cell_count  = _nelems.at(id);
        int ghost_count = _nelemsWithGhosts.at(id) - _nelems.at(id) + _interfaceMap.at(id).size();
       _cellSite.push_back( StorageSitePtr(new StorageSite( cell_count, ghost_count)) );

       _faceCells.push_back( _faceCellsGlobal.at(id)->getLocalizedSubsetOfFaceCells( *_faceSite.at(id), *_cellSite.at(id), *indices.at(id), *_cellParts.at(id), _procID )  );
       _faceNodes.push_back( _faceNodesGlobal.at(id)->getLocalizedSubset( *_faceSite.at(id), *_nodeSite.at(id), *indices.at(id) )  );
       _cellCells.push_back( (_faceCells.at(id)->getTranspose())->multiply(*_faceCells.at(id), true) );
       _cellNodes.push_back( (_faceCells.at(id)->getTranspose())->multiply(*_faceNodes.at(id), false) );

    }

    if ( _cleanup )
       cleanup_follow_faceCells_faceNodes();

    if ( _debugMode )
        DEBUG_faceCells_faceNodes();
}

void MeshPartitioner::fence_window ( )

private

Definition at line 3102 of file MeshPartitioner.cpp.

References _winGlobal, and _winLocal.

Referenced by mappers().

{

//     _winLocal.Fence ( 0 );
//     _winGlobal.Fence( 0 );

      _winLocal.Fence(MPI::MODE_NOPUT);
      _winGlobal.Fence(MPI::MODE_NOPUT);

}

void MeshPartitioner::fiedler_order

(

const string &

fname

)

Definition at line 611 of file MeshPartitioner.cpp.

References _fiedlerMap, _partTYPE, _totElems, _totElemsAndGhosts, and FIEDLER.

{
   _partTYPE = FIEDLER;
  //read permutation file
   int totElms          = _totElems[0];
   int totElmsAndGhost = _totElemsAndGhosts[0];
   _fiedlerMap = ArrayIntPtr( new Array<int>(totElmsAndGhost) );
   ifstream  permutation_file( fname.c_str() );
   int cellID  = -1;
   for ( int i = 0; i < totElms; i++ ){
        permutation_file >> cellID;
        (*_fiedlerMap)[i] = cellID - 1; //permutation
   }
   for ( int i = totElms; i < totElmsAndGhost; i++ ){
        (*_fiedlerMap)[i] = i; //permutation
   }

   permutation_file.close();
}

void MeshPartitioner::fiedler_partition ( )

private

Definition at line 632 of file MeshPartitioner.cpp.

References _debugMode, _elemDist, _fiedlerMap, _globalIndx, _meshList, _part, _procID, DEBUG_fiedler_partition(), and CRConnectivity::reorder().

Referenced by partition().

{
   MPI::COMM_WORLD.Barrier();

   //copy to part
   int elem_start   = (*_globalIndx.at(0))[_procID];
   int elem_finish  = elem_start + (*_elemDist[0])[_procID];

   int indx = 0;
   for ( int i = elem_start; i < elem_finish; i++ ){
      _part.at(0)[indx] = _procID;
      indx++;
   }

   CRConnectivity&  faceCells = _meshList[0]->getAllFaceCells();
   faceCells.reorder( *_fiedlerMap );

   MPI::COMM_WORLD.Barrier();

   if ( _debugMode )
      DEBUG_fiedler_partition();

}

void MeshPartitioner::free_window ( )

private

Definition at line 3095 of file MeshPartitioner.cpp.

References _winGlobal, and _winLocal.

Referenced by mappers().

{
     _winLocal.Free();
     _winGlobal.Free();
}

void MeshPartitioner::gatherCellsLevel1_partID_map ( )

private

Definition at line 2556 of file MeshPartitioner.cpp.

References _cellsLevel1PartID, _debugMode, _gatherCellsLevel1PartIDMap, _meshListLocal, _nmesh, DEBUG_gatherCellsLevel1_partID_map(), Mesh::getAllFaceCells(), Mesh::getCellCellsGlobal(), Mesh::getInterfaceGroupCount(), Mesh::getInterfaceGroups(), and Mesh::getLocalToGlobal().

Referenced by mesh().

{
    for ( int id = 0; id < _nmesh; id++ ){
        const Mesh& mesh = *_meshListLocal.at(id);
        const CRConnectivity&  faceCells     = mesh.getAllFaceCells();
        const Mesh::multiMap&  cellCellsMap = mesh.getCellCellsGlobal();
        const FaceGroupList&   faceGroupList = mesh.getInterfaceGroups();
        const Array<int>&      localToGlobal = mesh.getLocalToGlobal();
        //loop over interface, and get ghost cells(globalid), then go to scatterCells,
        //loop over interfaces  for gather
        for ( int i = 0; i < mesh.getInterfaceGroupCount(); i++ ){
            const int ibeg = faceGroupList[i]->site.getOffset();
            const int iend = ibeg + faceGroupList[i]->site.getCount();
            for ( int i = ibeg; i < iend; i++ ){
                const int localCellID  = faceCells(i,1);  //gather cellID(local)
                multimap<int,int>::const_iterator it;
                for ( it = cellCellsMap.equal_range(localCellID).first; it != cellCellsMap.equal_range(localCellID).second; it++){
                    _gatherCellsLevel1PartIDMap[it->second] = _cellsLevel1PartID[it->second];
                }
            }

        }

        for ( int i = 0; i < mesh.getInterfaceGroupCount(); i++ ){
            const int ibeg = faceGroupList[i]->site.getOffset();
            const int iend = ibeg + faceGroupList[i]->site.getCount();
            for ( int i = ibeg; i < iend; i++ ){
                //delete zero level gather cells
                _gatherCellsLevel1PartIDMap.erase( localToGlobal[ faceCells(i,1) ] );
                //delete scatter cells
                _gatherCellsLevel1PartIDMap.erase( localToGlobal[ faceCells(i,0) ] );
            }

        }

    }


   if( _debugMode )
      DEBUG_gatherCellsLevel1_partID_map();

}

int MeshPartitioner::get_local_nodes ( int  id )

private

Definition at line 501 of file MeshPartitioner.cpp.

References _elemDist, _globalIndx, _meshList, _procID, Mesh::getCellNodes(), and CRConnectivity::getCount().

Referenced by elem_connectivity().

{
      const Mesh* mesh = _meshList[id];
      const CRConnectivity& cellNodes = mesh->getCellNodes();

      //get local nodes
      int local_nodes = 0;
      int nstart = (*_globalIndx.at(id))[_procID];
      int npart  = nstart + (*_elemDist[id])[_procID];
      for ( int n = nstart; n < npart; n++)
           local_nodes += cellNodes.getCount(n);

       return local_nodes;
}

int MeshPartitioner::get_window_displ ( int  id, int  neigh_mesh_id  )

private

Definition at line 3063 of file MeshPartitioner.cpp.

References _interfaceMeshCounts, _interfaceMeshIDs, _offsetInterfaceCells, and _procID.

Referenced by mappers().

{
      int loc = 0;
      int window_displ = 0;
      for ( int i = 0; i < neigh_mesh_id; i++)
          loc += (*_interfaceMeshCounts.at(id))[i];

      while ( (*_interfaceMeshIDs.at(id))[loc] != _procID){
          window_displ += (*_offsetInterfaceCells.at(id))[loc+1] - (*_offsetInterfaceCells.at(id))[loc];
         loc++;
      }


    return window_displ;
}

const Mesh& MeshPartitioner::getBoundaryMesh ( ) const

inline

Definition at line 51 of file MeshPartitioner.h.

{ return *_bMesh; }

int MeshPartitioner::global_offset ( )

private

Definition at line 2106 of file MeshPartitioner.cpp.

References _meshListLocal, _nPart, _procID, Mesh::getBoundaryFaceGroups(), Mesh::getBoundaryGroupCount(), Mesh::getCells(), and StorageSite::getSelfCount().

Referenced by DEBUG_local_global(), and set_local_global().

{
   const int nmesh = int( _meshListLocal.size() );
   int count = 0;
   //get offsets for
   for ( int id = 0; id < nmesh; id++ ){
      const Mesh&    mesh = *_meshListLocal.at(id);
      const StorageSite& cellSite = mesh.getCells();
      const FaceGroupList&  bounGroupList = mesh.getBoundaryFaceGroups();
      int bounCount = 0;
      for ( int i = 0; i < mesh.getBoundaryGroupCount(); i++ )
         bounCount += bounGroupList[i]->site.getCount();
      const int selfCount = cellSite.getSelfCount();
      count += selfCount + bounCount;
   }

    //allocation holding each partiton offset
    int *counts = new int[ _nPart[0] ];
   //MPI calls allgather to know offsets
   MPI::COMM_WORLD.Allgather( &count, 1, MPI::INT, counts, 1, MPI::INT);

   //compute offsets for each partition
   int offset = 0;
   for ( int i = 0; i < _procID; i++ )
      offset += counts[i];

   //delete allocation counts
   delete [] counts;
   return offset;

}

void MeshPartitioner::globalCellID_procID_map ( )

private

Definition at line 2451 of file MeshPartitioner.cpp.

References _cellsLevel1PartID, _debugMode, _meshListLocal, _nmesh, _nPart, DEBUG_globalCellID_procID_map(), Mesh::getBoundaryFaceGroups(), Mesh::getBoundaryGroupCount(), Mesh::getCellCells(), Mesh::getCells(), StorageSite::getCount(), CRConnectivity::getCount(), Mesh::getGhostCellSiteScatterMap(), Mesh::getLocalToGlobal(), StorageSite::getScatterMap(), and StorageSite::getSelfCount().

Referenced by mesh().

{
      for ( int id = 0; id < _nmesh; id++ ){
          set<int> cellsLevel1;
          const Mesh& mesh = *_meshListLocal.at(id);
          const Array<int>&      localToGlobal = mesh.getLocalToGlobal();
          const CRConnectivity&  cellCells = mesh.getCellCells();
          const StorageSite& cellSite = mesh.getCells();
          const int selfCount = cellSite.getSelfCount();
          const StorageSite::ScatterMap& cellScatterMap       = cellSite.getScatterMap();
          //count boundary cells
          const FaceGroupList&  bounGroupList = mesh.getBoundaryFaceGroups();
          int nboun = 0;
          for ( int n = 0; n < mesh.getBoundaryGroupCount(); n++ ){
             nboun += bounGroupList[n]->site.getCount();
          }
          //compute innercells + boundary cells
          const int countNonGhostCells = selfCount +  nboun;
          //get scatter map  key ={neight part id, mesh id}, value = scatter storage site
          const Mesh::GhostCellSiteMap& ghostCellSiteScatterMap = mesh.getGhostCellSiteScatterMap();
          //loop over scatter mappers
          foreach ( const Mesh::GhostCellSiteMap::value_type& mpos, ghostCellSiteScatterMap ){
              const StorageSite& siteScatter =  *(mpos.second);
              const Array<int>&  scatterArray =  *(cellScatterMap.find( &siteScatter )->second);
              //loop over scatter cells
              for ( int i = 0; i < siteScatter.getCount(); i++){
                  const int cellID0 = scatterArray[i];
                  cellsLevel1.insert( localToGlobal[cellID0] );
                  const int jj = cellCells.getCount(cellID0);
                  //around cells
                  for ( int j = 0; j < jj; j++ ){
                     //now this cell arounds
                     //check if this is not ghost cell since we are only including inner+boundary cells
                     const int cellID1 = cellCells(cellID0,j);
                     if ( cellID1 < countNonGhostCells ){  //since we order first local then boundary
                         cellsLevel1.insert(localToGlobal[cellID1]);
                     }
                  }
              }
         }
         //allocate send buffer and copy local values in it
         shared_ptr< Array<int> > cellsLevel1Array = ArrayIntPtr( new Array<int>(cellsLevel1.size()) );
         set <int>::const_iterator it = cellsLevel1.begin();
         for ( int i = 0; i < cellsLevel1Array->getLength(); i++){
             (*cellsLevel1Array)[i] = *it;
             it++;
         }

         int cellsLevel1GlobalSize = 0;
         int sendbuffer = int( cellsLevel1.size() );
         MPI::COMM_WORLD.Allreduce( &sendbuffer, &cellsLevel1GlobalSize, 1, MPI::INT, MPI::SUM );

         //create array for cellsLevel1Global
         shared_ptr< Array<int> > cellsLevel1Global = ArrayIntPtr( new Array<int>(cellsLevel1GlobalSize  ) );
         int *recv_counts = new int[ _nPart.at(id) ];
         int sendcount = int( cellsLevel1.size() );
         MPI::COMM_WORLD.Allgather( &sendcount, 1, MPI::INT, recv_counts, 1, MPI::INT );

         int *displ = new int[ _nPart.at(id) ];
         displ[0] = 0;
         for ( int i = 1; i < _nPart.at(id); i++)
            displ[i] = recv_counts[i-1] + displ[i-1];
         //now gather for cellsLevel1Global
         MPI::COMM_WORLD.Allgatherv( cellsLevel1Array->getData(), sendcount , MPI::INT,
                  cellsLevel1Global->getData(), recv_counts, displ, MPI::INT);

        //now fill following arrays
        int procid = 0;
        int indx = recv_counts[0];
        for ( int i = 0; i < cellsLevel1Global->getLength(); i++ ){
            _cellsLevel1PartID[ (*cellsLevel1Global)[i] ] = procid;
            if ( (i == indx-1) && (procid <_nPart.at(id)-1) ){
               //procid++;
               indx += recv_counts[++procid];
            }
        }

         delete [] recv_counts;
         delete [] displ;

      }

//write this debug function

   if ( _debugMode  )
      DEBUG_globalCellID_procID_map();
 }

void MeshPartitioner::init ( )

private

Definition at line 299 of file MeshPartitioner.cpp.

References _bndryOffsets, _boundarySet, _cellToOrderedCell, _cleanup, _colDim, _debugMode, _edgecut, _elemSet, _eType, _fromIndices, _globalToLocalMappers, _interfaceMeshCounts, _interfaceOffsets, _interfaceSet, _localToGlobalMappers, _mapBounIDAndBounType, _mapBounIDAndCell, _mapPartAndElms, _meshList, _ncommonNodes, _ncon, _nelems, _nelemsWithGhosts, _nmesh, _nonInteriorCells, _nPart, _numFlag, _partTYPE, _procID, _procTotalInterfaces, _toIndices, _totElems, _totElemsAndGhosts, _tpwgts, _ubvec, _wghtFlag, _windowSize, C_STYLE, StorageSite::getCount(), StorageSite::getSelfCount(), HEXA, NOWEIGHTS, PARMETIS, QUAD, TETRA, and TRI.

Referenced by MeshPartitioner().

{
    _partTYPE  = PARMETIS;
    _procID    = MPI::COMM_WORLD.Get_rank();
    _nmesh     = _meshList.size();

   _totElems.resize  ( _nmesh );
   _totElemsAndGhosts.resize( _nmesh );
   _wghtFlag.resize( _nmesh );
   _numFlag.resize ( _nmesh );
   _ncon.resize    ( _nmesh );
   _ncommonNodes.resize( _nmesh );
   _mapPartAndElms.resize( _nmesh );
   _boundarySet.resize( _nmesh );
   _interfaceSet.resize( _nmesh );
   _mapBounIDAndCell.resize( _nmesh );
   _mapBounIDAndBounType.resize( _nmesh );
   _nelems.resize( _nmesh );
   _nelemsWithGhosts.resize( _nmesh );
   _colDim.resize( _nmesh );
   _edgecut.resize( _nmesh );
   _elemSet.resize(_nmesh);
   _nonInteriorCells.resize(_nmesh ); //local numbering
   _bndryOffsets.resize( _nmesh );
   _interfaceOffsets.resize( _nmesh );
   _cellToOrderedCell.resize( _nmesh );
   _globalToLocalMappers.resize( _nmesh );
   _localToGlobalMappers.resize( _nmesh );
   _windowSize.resize( _nmesh );
   _fromIndices.resize( _nmesh );
   _toIndices.resize( _nmesh );
   _cleanup = false;
   _debugMode = false;
    for ( int id = 0; id < _nmesh; id++){
        StorageSite& site = _meshList[id]->getCells();
       _totElems.at(id)   = site.getSelfCount();
       _totElemsAndGhosts.at(id) = site.getCount();
       _wghtFlag.at(id) = int( NOWEIGHTS ); //No Weights : default value
       _numFlag.at(id)  = int( C_STYLE );   //C Style numbering :: default_value
       _ncon.at(id)     = 2;               //number of specified weights : default value for contigous domain ncon > 1
       //if it is assemble mesh ncon will be equal to num of assembled mesh
       if (  _meshList.at(id)->isMergedMesh() )
           _ncon.at(id)     = _meshList.at(id)->getNumOfAssembleMesh();

       //assign ubvec
       _ubvec.push_back( new float[_ncon.at(id) ] );
       for ( int n = 0; n < _ncon.at(id); n++)
         _ubvec.at(id)[n] = 1.05f; //1.05 suggested value from parMetis manual


        //assign elementy type
        switch (_eType.at(id) ){
            case   TRI :
                   _ncommonNodes.at(id) = 2;
                   break;
            case   TETRA :
                   _ncommonNodes.at(id) = 3;
                   break;
            case   HEXA :
                   _ncommonNodes.at(id) = 4;
                   break;
            case   QUAD :
                   _ncommonNodes.at(id) = 2;
                    break;
            default :
                    cout << " ONLY TRIANGLE, TETRAHEDRAL, HEXAHEDRAL and QUADRILATERAL elements must be chose " <<
                    endl;     abort();
        }

        //get tpwgts
        int ncon_by_nparts = _ncon.at(id) * _nPart.at(id);
        _tpwgts.push_back( new float[ ncon_by_nparts ] );
        for (int n = 0; n < ncon_by_nparts; n++){
            _tpwgts.at(id)[n] = 1.0f / float( ncon_by_nparts );
        }

       //edgecut
        _edgecut.at(id) = -1;

      _interfaceMeshCounts.push_back (  ArrayIntPtr( new Array<int>(_nPart.at(id)) )  );
      _procTotalInterfaces.push_back (  ArrayIntPtr( new Array<int>(_nPart.at(id)) )  );

    }


}

void MeshPartitioner::interfaces ( )

private

Definition at line 1469 of file MeshPartitioner.cpp.

References _debugMode, _faceParts, _interfaceMap, _interfaceSet, _nmesh, _partFaces, _procID, and DEBUG_interfaces().

Referenced by mesh().

{
    _interfaceMap.resize( _nmesh );
    for ( int id = 0; id < _nmesh; id++){
       int nface =   _partFaces.at(id)->getCount( _procID );
        for ( int face = 0; face < nface; face++ ){
             int face_globalID = (*_partFaces.at(id))(_procID,face);
            if (_faceParts.at(id)->getCount(face_globalID) == 2 ){  // ==2 means sharing interface
                int neighPart = (*_faceParts.at(id))(face_globalID,0) +
                                (*_faceParts.at(id))(face_globalID,1) - _procID;
                _interfaceSet.at(id).insert( neighPart );
                _interfaceMap.at(id).insert(  pair<int,int>(neighPart,face) );
            }
        }
    }

    if ( _debugMode )
       DEBUG_interfaces();
}

void MeshPartitioner::isCleanup ( bool  clean_up )

inline

Definition at line 66 of file MeshPartitioner.h.

{ _cleanup = clean_up;  }

void MeshPartitioner::isDebug ( bool  debug )

inline

Definition at line 67 of file MeshPartitioner.h.

                                  { _cleanup = false;
                                    _debugMode = debug;     }

void MeshPartitioner::level1_scatter_gather_cells ( )

private

Definition at line 2617 of file MeshPartitioner.cpp.

References _debugMode, _gatherCellsLevel1PartIDMap, _meshList, _meshListLocal, _nmesh, _nPart, _partNodes, _procID, DEBUG_level1_scatter_gather_cells(), StorageSite::getCount(), CRConnectivity::getCount(), Array< T >::getData(), max(), min(), StorageSite::setCountLevel1(), and FaceGroup::site.

Referenced by mesh().

{

      for ( int id = 0; id < _nmesh; id++ ){

         //we prepare gatherArrays to other processor
         map<int, vector<int> > gatherArrays; //key=sending procs, value = scatter cells on other cells to this processor
         foreach( const IntMap::value_type& mpos, _gatherCellsLevel1PartIDMap ){
            const int globalID = mpos.first;
            const int partID   = mpos.second; //this is where is going to be sent
            gatherArrays[partID].push_back( globalID );
         }

         vector<int> gatherProcs;
         //create a vector holding receiver processor
         foreach( const VectorMap::value_type& pos, gatherArrays){
            gatherProcs.push_back( pos.first);
         }

         //globalSendProcess is holding number of sending processro for each processor
         Array<int> globalGatherProcsCount( _nPart.at(id) );
         int gatherProcsCount = gatherArrays.size();
         MPI::COMM_WORLD.Allgather(&gatherProcsCount, 1, MPI::INT, globalGatherProcsCount.getData(), 1, MPI::INT);

         Array<int> offsets( _nPart.at(id) );
        //form offsets
        offsets[0]  = 0;
        for ( int p = 1; p < int(_nPart.at(id)); p++ ){
           offsets[p]  = globalGatherProcsCount[p-1]  + offsets[p-1];
        }
        //get global buffer size
        int globalBufferSize = 0;
        for ( int i = 0; i < globalGatherProcsCount.getLength(); i++ ){
           globalBufferSize += globalGatherProcsCount[i];
        }
        Array<int> globalGatherProcs( globalBufferSize );
        //gathering partial partions for _row and _col
        MPI::COMM_WORLD.Allgatherv(&gatherProcs[0], gatherProcs.size(), MPI::INT, globalGatherProcs.getData(),
                                 (const int *) globalGatherProcsCount.getData(), (const int *)offsets.getData(), MPI::INT);

         //now preparing scatterProcs
         list<int> scatterProcs;
         for ( int i = 0; i < _nPart.at(id); i++ ){
            for ( int j = 0; j < globalGatherProcsCount[i]; j++ ){
                 const int gatherProcID = globalGatherProcs[ offsets[i]+j];
                 if ( _procID == gatherProcID ) //if it is sending me then this is included in recvProcs
                      scatterProcs.push_back( i );
             }
         }


         //MPI SENDING
         MPI::Request   request_send[ gatherArrays.size() ];
         int indxSend = 0;
         int indxRecv = 0;
         foreach(const VectorMap::value_type pos, gatherArrays){
            int to_where = pos.first;
            int count = int( gatherArrays[to_where].size() );
            int send_tag = 112233;
            request_send[indxSend++] =
                     MPI::COMM_WORLD.Isend( &gatherArrays[to_where][0], count, MPI::INT, to_where, send_tag );
         }


         map<int, vector<int> > scatterArrays;   //key=recv procs, value = gather cells
         list<int>::iterator it;
         while ( !scatterProcs.empty() ){
            for( it = scatterProcs.begin(); it != scatterProcs.end(); ++it ){
               int from_where = *it; //whereever it sends data has to get another data from there
               int recv_tag = 112233;
               MPI::Status recv_status;
               if( MPI::COMM_WORLD.Iprobe(from_where, recv_tag, recv_status) ){
                  //find receive buffer size
                  int scatter_count = recv_status.Get_count( MPI::INT );
                  //recv arrays allocation
                  scatterArrays[from_where].resize( scatter_count);
                  scatterProcs.remove(from_where);
                  break;
               }
            }
         }


         //RECIEVING
         //getting values from other meshes to fill g
         MPI::Request   request_recv[ scatterArrays.size() ];
         foreach( const VectorMap::value_type& pos, scatterArrays){
            int from_where = pos.first; //whereever it sends data has to get another data from there
            int recv_count = int(scatterArrays[from_where].size());
            int recv_tag = 112233;
            request_recv[indxRecv++] =
                     MPI::COMM_WORLD.Irecv( &scatterArrays[from_where][0], recv_count, MPI::INT, from_where, recv_tag );
         }

         int countScatter  = scatterArrays.size();
         int countGather   = gatherArrays.size();
         MPI::Request::Waitall( countScatter, request_recv );
         MPI::Request::Waitall( countGather, request_send );


        StorageSite::ScatterMap & cellScatterMapLevel1 = _meshListLocal.at(id)->getCells().getScatterMapLevel1();
        StorageSite::GatherMap  & cellGatherMapLevel1  = _meshListLocal.at(id)->getCells().getGatherMapLevel1();
        map<int,int>&  globalToLocal = _meshListLocal.at(id)->getGlobalToLocal();
        StorageSite& cellSite = _meshListLocal.at(id)->getCells();
        //create scatter ghost sites level1
        foreach ( const VectorMap::value_type& pos, scatterArrays ){
           const int toProcID = pos.first;
           const vector<int>& scatter_array = pos.second;
           const int scatterSize  = int( scatter_array.size() );
           //scatter Arrays
           ArrayIntPtr from_indices = ArrayIntPtr( new Array<int>( scatterSize ) );
           //copy scatter_array to from_indices
           for ( int i = 0; i < scatterSize; i++ ){
               (*from_indices)[i] = globalToLocal[ scatter_array[i] ];
           }

           //create scatter  sites
           shared_ptr<StorageSite> siteScatter( new StorageSite(scatterSize) );

           siteScatter->setScatterProcID( _procID );
           siteScatter->setGatherProcID ( toProcID );


           int packed_info = (std::max(_procID,toProcID) << 16 ) | ( std::min(_procID,toProcID) );
           siteScatter->setTag( packed_info );
           Mesh::PartIDMeshIDPair  pairID = make_pair<int,int>(toProcID, id);
           _meshListLocal.at(id)->createGhostCellSiteScatterLevel1( pairID, siteScatter );
            cellScatterMapLevel1[ siteScatter.get() ] = from_indices;
        }

        int gatherIndx = cellSite.getCount();
       //create  gather ghost sites level1
        foreach ( const VectorMap::value_type& pos, gatherArrays ){
           const int fromProcID = pos.first;
           const vector<int>& gather_array = pos.second;
           const int gatherSize  = int( gather_array.size() );
           //gather Arrays
           ArrayIntPtr to_indices = ArrayIntPtr( new Array<int>( gatherSize ) );
          //copy gather_array to to_indices
           for ( int i = 0; i < gatherSize; i++ ){
               (*to_indices)[i]  = gatherIndx;
               globalToLocal[gather_array[i]] = gatherIndx;
               gatherIndx++;
           }

           //create gather and ghost sites
           shared_ptr<StorageSite> siteGather ( new StorageSite(gatherSize ) );

           siteGather->setScatterProcID( _procID );
           siteGather->setGatherProcID ( fromProcID );

           int packed_info = (std::max(fromProcID, _procID) << 16 ) | ( std::min(fromProcID, _procID) );
           siteGather->setTag( packed_info );
           Mesh::PartIDMeshIDPair  pairID = make_pair<int,int>(fromProcID, id);
           _meshListLocal.at(id)->createGhostCellSiteGatherLevel1 ( pairID, siteGather );
            cellGatherMapLevel1 [ siteGather.get() ] = to_indices;
        }

        //create storage sites
        cellSite.setCountLevel1(gatherIndx);

        const StorageSite& faceSite = _meshListLocal.at(id)->getFaces();
        _meshListLocal.at(id)->eraseConnectivity(cellSite, cellSite);
        _meshListLocal.at(id)->eraseConnectivity(cellSite, faceSite);

        //uniquie
        if ( !_meshList.at(0)->isMergedMesh() )
           _meshListLocal.at(id)->uniqueFaceCells();

        _meshListLocal.at(id)->createScatterGatherCountsBuffer();
        _meshListLocal.at(id)->syncCounts();
        _meshListLocal.at(id)->recvScatterGatherCountsBufferLocal();

        _meshListLocal.at(id)->createScatterGatherIndicesBuffer();
        _meshListLocal.at(id)->syncIndices();
        _meshListLocal.at(id)->recvScatterGatherIndicesBufferLocal();

        _meshListLocal.at(id)->createCellCellsGhostExt();

        //adding Mesh classes new data structure to keep track of globalID nodes (consisten with fluent case file)
        _meshListLocal.at(id)->createLocalToGlobalNodesArray();
        const StorageSite& nodes = _meshListLocal.at(id)->getNodes();
        Array<int>&      localToGlobalNodes = *_meshListLocal.at(id)->getLocalToGlobalNodesPtr();
        //map<int,int>&    globalToLocalNodes = _meshListLocal.at(id)->getGlobalToLocalNodes();

        //updating localToGlobal
        for ( int i = 0; i < nodes.getCount(); i++ ){
             const int globalID = (*_partNodes.at(id))(_procID,i);
             localToGlobalNodes[i] = globalID;
             //globalToLocalNodes[globalID] = i;
        }
        //find boundary nodes
        set<int>& boundaryNodeSet = _meshListLocal.at(id)->getBoundaryNodesSet();
        foreach(const FaceGroupPtr fgPtr, _meshListLocal.at(id)->getBoundaryFaceGroups() ){
           const FaceGroup& fg = *fgPtr;
           const StorageSite& faces = fg.site;
           const int nFaces = faces.getCount();
           const CRConnectivity& faceNodes = _meshListLocal.at(id)->getFaceNodes(faces);
           for(int f=0; f<nFaces; f++){
              const int nFaceNodes = faceNodes.getCount(f);
              for(int nn=0; nn<nFaceNodes; nn++){
                 const int n=faceNodes(f,nn);
                 boundaryNodeSet.insert(n);
              }
           }
        }


//         const Array<Mesh::VecD3>& coordFluent = _meshList.at(0)->getNodeCoordinates();
//         const Array<Mesh::VecD3>& coordPart   = _meshListLocal.at(0)->getNodeCoordinates();
//         if ( _procID == 0 )
//            coordFluent.print(cout);
//         cout << endl;
//         cout << endl;
//         if ( _procID == 1 ){
//            coordPart.print(cout);
//            localToGlobalNodes.print(cout);
//            cout << endl;
//            CRConnectivityPrint(*_partNodes.at(0),_procID,"partNodes");
//         }

/*        const Array<int>& localToGlobalNodes = _faceNodesGlobal.at(0)->getLocalToGlobalMap();
        localToGlobalNodes.print(cout);*/

    }



   if ( _debugMode )
      DEBUG_level1_scatter_gather_cells();
 }

void MeshPartitioner::map_part_elms ( )

private

Definition at line 688 of file MeshPartitioner.cpp.

References _debugMode, _elemDist, _mapPartAndElms, _nmesh, _part, _procID, and DEBUG_map_part_elms().

Referenced by partition().

{
   for (int  id = 0; id < _nmesh; id++){
      int nlocal_elem = (*_elemDist.at(id))[_procID];
      for ( int elm = 0; elm < nlocal_elem; elm++){
         int partID = _part[id][elm];
         _mapPartAndElms.at(id).insert(pair<int,int>(partID,elm));
      }

   }

   if ( _debugMode )
      DEBUG_map_part_elms();
}

void MeshPartitioner::mapBounIDAndCell ( int  id )

private

Definition at line 1041 of file MeshPartitioner.cpp.

References _boundarySet, _debugMode, _elem, _elemSet, _mapBounIDAndBounType, _mapBounIDAndCell, _meshList, _nelems, _totElems, and DEBUG_mapBounIDAndCell().

Referenced by CRConnectivity_cellParts().

{

   //mapBounIDAndCell  store global information
   //_mapBounIDAndCell store  local (process) information
    multimap<int,int>  mapBounIDAndCell;

    //boundary information has been stored
    const FaceGroupList&  boundaryFaceGroups = _meshList.at(id)->getBoundaryFaceGroups();
    int indx = _totElems.at(id);

    for ( int bounID = 0; bounID < int(boundaryFaceGroups.size()); bounID++){
        int group_id = boundaryFaceGroups.at(bounID)->id;
        _boundarySet.at(id).insert( group_id );
        string boun_type( boundaryFaceGroups.at(bounID)->groupType );

        _mapBounIDAndBounType.at(id).insert( pair<int,string>(group_id, boun_type) );

        int nBounElm = boundaryFaceGroups.at(bounID)->site.getCount();

        for ( int n = 0; n < nBounElm; n++){
           mapBounIDAndCell.insert( pair<int,int>(group_id, indx) );
           indx++;
        }
     }

     //putting local elements  in set to check fast way
     for ( int n = 0; n < _nelems.at(id); n++ )
        _elemSet.at(id).insert( _elem.at(id)[n] );

     multimap<int,int>::const_iterator  it;
     const CRConnectivity& cellCells = _meshList.at(id)->getCellCells();
     for ( it = mapBounIDAndCell.begin(); it != mapBounIDAndCell.end(); it++ ){
        int boun_cell_id = it->second;
        int neigh_id     = cellCells(boun_cell_id,0); //assuming just one neighbour for boundary
        if ( _elemSet.at(id).count( neigh_id ) > 0 )
            _mapBounIDAndCell.at(id).insert( pair<int,int>(it->first, it->second) );
     }

     if ( _debugMode )
        DEBUG_mapBounIDAndCell();

}

void MeshPartitioner::mappers ( )

private

Definition at line 2019 of file MeshPartitioner.cpp.

References _cleanup, _debugMode, _fromIndices, _globalToLocalMappers, _interfaceMap, _interfaceSet, _meshListLocal, _nmesh, _toIndices, _winGlobal, _winLocal, cleanup_follow_mappers(), create_window(), DEBUG_mesh(), fence_window(), free_window(), and get_window_displ().

Referenced by mesh().

{

    for ( int id = 0; id < _nmesh; id++){
        create_window( id );
        fence_window();

        StorageSite::ScatterMap & cellScatterMap = _meshListLocal.at(id)->getCells().getScatterMap();
        StorageSite::GatherMap  & cellGatherMap  = _meshListLocal.at(id)->getCells().getGatherMap();

       //getting data
        set<int>::const_iterator it_set;
        int interfaceIndx = 0;
        for ( it_set = _interfaceSet.at(id).begin(); it_set != _interfaceSet.at(id).end(); it_set++){

            int neighMeshID = *it_set;
            int size = int(_interfaceMap.at(id).count(neighMeshID) );
            _fromIndices.at(id).push_back( ArrayIntPtr( new Array<int>(size) ) );
              _toIndices.at(id).push_back( ArrayIntPtr( new Array<int>(size) ) );
           *_fromIndices.at(id).at(interfaceIndx)  = -1;
              *_toIndices.at(id).at(interfaceIndx) = -1;

             int window_displ = -1;
             window_displ = get_window_displ( id, neighMeshID );
            _winLocal.Get ( _fromIndices.at(id).at(interfaceIndx)->getData(), size, MPI::INT, neighMeshID, window_displ, size, MPI::INT );
            _winGlobal.Get( _toIndices.at(id).at(interfaceIndx)->getData()  , size, MPI::INT, neighMeshID, window_displ, size, MPI::INT );
             interfaceIndx++;

        }

       fence_window();
       free_window();


       interfaceIndx = 0;
       for ( it_set = _interfaceSet.at(id).begin(); it_set != _interfaceSet.at(id).end(); it_set++ ){

           int neighMeshID = *it_set;
           int size = int(_interfaceMap.at(id).count(neighMeshID) );
           map<int, int>  mapKeyCount;        //map between key and count of that key
           for ( int n = 0; n < size; n++){

               int  key     = (*_toIndices.at(id).at(interfaceIndx))[n];
//               int  count   = _globalToLocalMappers.at(id).count( key );

               if ( mapKeyCount.count( key ) > 0 ) { //it has elements
                  mapKeyCount[key] = mapKeyCount[key] + 1; //increase one
               } else {  //if it is empty
                  mapKeyCount.insert(pair<int,int>(key,0));
               }

               multimap<int,int>::const_iterator it;
               it = _globalToLocalMappers.at(id).lower_bound( key );
               for ( int n_iter = 0; n_iter < mapKeyCount[key]; n_iter++)
                   it++;

               int elem_id =  it->second;
               (*_toIndices.at(id).at(interfaceIndx))[n] =  elem_id;


           }
          //from indices seems useless for now but we need to find scatterCells = cellCells(toIndices) and
          //use fromindices as storage Array
          for ( int i = 0; i < _fromIndices.at(id).at(interfaceIndx)->getLength(); i++){
               int elem_id = (*_toIndices.at(id).at(interfaceIndx))[i];
                (*_fromIndices.at(id).at(interfaceIndx))[i] = _meshListLocal.at(id)->getCellCells()(elem_id,0);
          }
          Mesh::PartIDMeshIDPair pairID = make_pair<int,int>(neighMeshID,0); //no multiple meshees so second index zero
          cellScatterMap[ _meshListLocal.at(id)->getGhostCellSiteScatter( pairID ) ] = _fromIndices.at(id).at(interfaceIndx);
          cellGatherMap [ _meshListLocal.at(id)->getGhostCellSiteGather ( pairID ) ] = _toIndices.at(id).at(interfaceIndx);

          interfaceIndx++;

        }

    }

    if ( _cleanup )
       cleanup_follow_mappers();

   if ( _debugMode )
      DEBUG_mesh();

}

void MeshPartitioner::mesh

(

)

Definition at line 116 of file MeshPartitioner.cpp.

References _meshList, coordinates(), CRConnectivity_cellParts(), CRConnectivity_faceParts(), exchange_interface_meshes(), faceCells_faceNodes(), gatherCellsLevel1_partID_map(), globalCellID_procID_map(), interfaces(), level1_scatter_gather_cells(), mappers(), mesh_setup(), non_interior_cells(), order_faceCells_faceNodes(), set_cellcells_global(), set_local_global(), and setMeshColors().

{
    CRConnectivity_cellParts();
    CRConnectivity_faceParts();
    interfaces();
    faceCells_faceNodes();
    non_interior_cells();
    order_faceCells_faceNodes();
    coordinates();
    exchange_interface_meshes();
    mesh_setup();
    mappers();
    set_local_global();
    set_cellcells_global();
    globalCellID_procID_map();
    gatherCellsLevel1_partID_map();
    level1_scatter_gather_cells();
    set_local_global();
    if (  _meshList.at(0)->isMergedMesh() ){
       setMeshColors();
    }

}

void MeshPartitioner::mesh_file ( )

private

Definition at line 3124 of file MeshPartitioner.cpp.

References _meshListLocal, _nmesh, _procID, and StorageSite::getCount().

Referenced by DEBUG_mesh(), mesh_tecplot(), mesh_xdmf_header(), and mesh_xdmfplot().

{
     stringstream ss;
     ss << "mesh_proc" << _procID << "_info.dat";
     ofstream  mesh_file( (ss.str()).c_str() );
     for ( int id = 0; id < _nmesh; id++ ){

          const StorageSite::ScatterMap& cellScatterMap  = _meshListLocal.at(id)->getCells().getScatterMap();
          const StorageSite::GatherMap& cellGatherMap   = _meshListLocal.at(id)->getCells().getGatherMap();
          const Mesh::GhostCellSiteMap& ghostCellSiteScatterMap = _meshListLocal.at(id)->getGhostCellSiteScatterMap();
          const Mesh::GhostCellSiteMap& ghostCellSiteGatherMap  = _meshListLocal.at(id)->getGhostCellSiteGatherMap();

           Mesh::GhostCellSiteMap::const_iterator it_ghostScatter;
            //loop over interfaces
           for ( it_ghostScatter = ghostCellSiteScatterMap.begin(); it_ghostScatter != ghostCellSiteScatterMap.end(); it_ghostScatter++ ){
               const Mesh::PartIDMeshIDPair pairID = it_ghostScatter->first;
               int neighID = pairID.first;

               const StorageSite& siteScatter =  *( ghostCellSiteScatterMap.find( pairID )->second );
               const StorageSite& siteGather  =  *( ghostCellSiteGatherMap.find ( pairID )->second );


               const Array<int>&  scatterArray =  *(cellScatterMap.find( &siteScatter )->second);
               const Array<int>&  gatherArray  =  *(cellGatherMap.find ( &siteGather )->second);
               for ( int i = 0; i < siteScatter.getCount(); i++){
                     mesh_file <<   "  neightMeshID = " <<  neighID  << "        "
                               << gatherArray[i]  + 1  << "    ===>    "
                               << scatterArray[i] + 1  << endl;
               }
          }

      }

      mesh_file.close();

}

void MeshPartitioner::mesh_setup ( )

private

Definition at line 948 of file MeshPartitioner.cpp.

References _bndryOffsets, _boundarySet, _coord, _faceCellsOrdered, _faceNodesOrdered, _interfaceMap, _interfaceOffsets, _interfaceSet, _mapBounIDAndBounType, _mapBounIDAndCell, _meshListLocal, _nmesh, _procID, count_interior_faces(), max(), and min().

Referenced by mesh().

{
    for ( int id = 0; id < _nmesh; id++){
        //interior faces
        _meshListLocal.at(id)->createInteriorFaceGroup( count_interior_faces(id) );

        //boundary faces
        set<int>::const_iterator it_set;
        for ( it_set = _boundarySet.at(id).begin(); it_set != _boundarySet.at(id).end(); it_set++){
           int bndryID = *it_set;
           int size   =  _mapBounIDAndCell.at(id).count(bndryID);
           if ( size > 0 ){
              int offset =  _bndryOffsets.at(id)[ bndryID ] ;
              string boundaryType = _mapBounIDAndBounType.at(id)[bndryID];
              _meshListLocal.at(id)->createBoundaryFaceGroup(size, offset, bndryID, boundaryType);
           }
         }

        //then interface faces
        for ( it_set = _interfaceSet.at(id).begin(); it_set != _interfaceSet.at(id).end(); it_set++){
           int interfaceID = *it_set;
           int size = int(_interfaceMap.at(id).count( interfaceID ) );
           int offset = _interfaceOffsets.at(id)[ interfaceID ];
//            _meshListLocal.at(id)->createInterfaceGroup( size, offset, interfaceID );
//        structural solver complained and thought that it is boundayr so we assign as -
//         but this interface id might be used in meshassembly and meshdismantler
           _meshListLocal.at(id)->createInterfaceGroup( size, offset, -interfaceID );
            shared_ptr<StorageSite> siteGather ( new StorageSite(size) );
            shared_ptr<StorageSite> siteScatter( new StorageSite(size) );
            siteGather->setScatterProcID( _procID );
            siteGather->setGatherProcID ( interfaceID );
            siteScatter->setScatterProcID( _procID );
            siteScatter->setGatherProcID ( interfaceID );
            int packed_info = (std::max(_procID,interfaceID) << 16 ) | ( std::min(_procID,interfaceID) );
            siteScatter->setTag( packed_info );


            Mesh::PartIDMeshIDPair  pairID = make_pair<int,int>(interfaceID, id);
           _meshListLocal.at(id)->createGhostCellSiteScatter( pairID, siteScatter );
           _meshListLocal.at(id)->createGhostCellSiteGather ( pairID, siteScatter );

         }

       _meshListLocal.at(id)->setCoordinates( _coord.at(id)            );
       _meshListLocal.at(id)->setFaceNodes  ( _faceNodesOrdered.at(id) );
       _meshListLocal.at(id)->setFaceCells  ( _faceCellsOrdered.at(id) );
    }

}

void MeshPartitioner::mesh_tecplot ( )

private

Definition at line 3164 of file MeshPartitioner.cpp.

References _cellToOrderedCell, _eType, _meshListLocal, _nelems, _nonInteriorCells, _procID, CRConnectivity::getCount(), Array< T >::getLength(), CRConnectivity::getRowDim(), HEXA, mesh_file(), QUAD, TETRA, and TRI.

Referenced by DEBUG_mesh().

{
     stringstream ss;
     ss << "mesh_proc" << _procID << ".dat";
     ofstream  mesh_file( (ss.str()).c_str() );

      const Mesh& mesh = *(_meshListLocal.at(0));
      const CRConnectivity&  cellNodes = mesh.getCellNodes();
      const Array<Mesh::VecD3>&  coord = mesh.getNodeCoordinates();
      int tot_elems = cellNodes.getRowDim();
      int tot_nodes =  coord.getLength();

     mesh_file << "title = \" tecplot file for process Mesh \" "  << endl;
     mesh_file << "variables = \"x\",  \"y\", \"z\", \"cell_type\" " << endl;
#if 0
     mesh_file << "variables = \"x\",  \"y\", \"z\", \"cell_type\", \"color\"  " << endl;
#endif

     stringstream zone_info;

     if ( _eType.at(0) == TRI )
        zone_info <<  " DATAPACKING = BLOCK,  VARLOCATION = ([4]=CELLCENTERED), ZONETYPE=FETRIANGLE ";

     if ( _eType.at(0) == QUAD )
        zone_info <<  " DATAPACKING = BLOCK,  VARLOCATION = ([4]=CELLCENTERED), ZONETYPE=FEQUADRILATERAL ";

     if ( _eType.at(0) == HEXA )
        zone_info <<  " DATAPACKING = BLOCK,  VARLOCATION = ([4]=CELLCENTERED), ZONETYPE=FEBRICK ";

     if ( _eType.at(0) == TETRA )
        zone_info <<  " DATAPACKING = BLOCK,  VARLOCATION = ([4]=CELLCENTERED), ZONETYPE=FETETRAHEDRON ";


     mesh_file << "zone N = " << tot_nodes << " E = " << tot_elems << zone_info.str()  << endl;

     //x
     for ( int n = 0; n < tot_nodes; n++){
         mesh_file << scientific  << coord[n][0] << "     " ;
         if ( n % 5 == 0 ) mesh_file << endl;
     }
     mesh_file << endl;

     //y
     for ( int n= 0; n < tot_nodes; n++){
         mesh_file << scientific << coord[n][1] << "     ";
         if ( n % 5 == 0 ) mesh_file << endl;
     }
     mesh_file << endl;

     //z
     for ( int n = 0; n < tot_nodes; n++){
          mesh_file << scientific << coord[n][2] << "     ";
          if ( n % 5 == 0) mesh_file << endl;
     }

     mesh_file << endl;
     mesh_file << endl;
     //cell type
      int cell_type = -1;
      for ( int n = 0; n < tot_elems;  n++){
          int elem_id = _cellToOrderedCell[0][n];
          cell_type = 1;
          if ( _nonInteriorCells.at(0).count(elem_id) == 0 ){
             cell_type = 0;
          } else {
             cell_type = 1;
          }

          mesh_file << cell_type  << "      ";
          if (  n % 10 == 0 ) mesh_file << endl;

       }
    mesh_file << endl;
#if  0
      mesh_file << endl;
      //mesh color is only
      const Array<int>& color = mesh.getCellColors();
      for ( int n = 0; n < tot_elems; n++ ){
          mesh_file <<  color[n] <<  "      ";
          if ( n % 10 == 0 ) mesh_file << endl;
      }
#endif


      mesh_file << endl;
     //connectivity
    for (int n = 0; n < tot_elems; n++){
         int nnodes =  cellNodes.getCount(n);
         if (  n < _nelems.at(0) ){
            for ( int node = 0; node < nnodes; node++)
                mesh_file << cellNodes(n,node)+1 << "      ";
         } else {

              if ( _eType.at(0) == TRI )
                  mesh_file << cellNodes(n,0)+1 << "      " << cellNodes(n,1)+1 <<
                   "       " << cellNodes(n,0)+1 << "      ";

              if ( _eType.at(0) == QUAD )
                  mesh_file << cellNodes(n,0)+1 << "      "  << cellNodes(n,0)+1 <<
                   "       " << cellNodes(n,1)+1 << "      " << cellNodes(n,1)+1 << "      ";

              if ( _eType.at(0) == HEXA )
                  mesh_file << cellNodes(n,0)+1 << "      "  << cellNodes(n,1)+1 << "      "
                            << cellNodes(n,2)+1 << "      "  << cellNodes(n,3)+1 << "      "
                            << cellNodes(n,0)+1 << "      "  << cellNodes(n,1)+1 << "      "
                            << cellNodes(n,2)+1 << "      "  << cellNodes(n,3)+1 << "      ";

             if ( _eType.at(0) == TETRA )
                  mesh_file << cellNodes(n,0)+1 << "      "  << cellNodes(n,1)+1 <<
                   "       " << cellNodes(n,2)+1 << "      " << cellNodes(n,0)+1 << "      ";


         }
        mesh_file << endl;
     }


    mesh_file.close();

}

void MeshPartitioner::mesh_xdmf_header ( )

private

Definition at line 3286 of file MeshPartitioner.cpp.

References mesh_file().

Referenced by mesh_xdmfplot().

{
  int nprocs = MPI::COMM_WORLD.Get_size();
  ofstream  mesh_file("mesh.xmf");
  mesh_file << "<?xml version='1.0' ?>" << endl;
  mesh_file << "<!DOCTYPE Xdmf SYSTEM 'Xdmf.dtd' []>" << endl;
  mesh_file << "<Xdmf xmlns:xi='http://www.w3.org/2001/XInclude' Version='2.0'>" << endl;
  mesh_file << "  <Domain>" << endl;
  for (int i=0; i < nprocs; i++)
    mesh_file << "    <xi:include href='mesh_proc" << i << ".xmf' />" << endl;
  mesh_file << "  </Domain>" << endl;
  mesh_file << "</Xdmf>" << endl;
  mesh_file.close();
}

void MeshPartitioner::mesh_xdmfplot

(

)

Definition at line 3306 of file MeshPartitioner.cpp.

References _eType, _meshListLocal, _nelems, _procID, CRConnectivity::getCount(), Array< T >::getLength(), HEXA, mesh_file(), mesh_xdmf_header(), QUAD, TETRA, and TRI.

{
  if (_procID == 0)
    mesh_xdmf_header();

  stringstream ss;
  ss << "mesh_proc" << _procID << ".xmf";
  ofstream  mesh_file( (ss.str()).c_str() );

  const Mesh& mesh = *(_meshListLocal.at(0));
  const CRConnectivity&  cellNodes = mesh.getCellNodes();
  const Array<Mesh::VecD3>&  coord = mesh.getNodeCoordinates();
  int tot_elems = _nelems.at(0);
  int tot_nodes =  coord.getLength();
  int epn;

  mesh_file << "<Grid Name='Mesh-" << _procID << "' GridType='Uniform'>" << endl << "  ";

  switch (_eType.at(0)) {
  case TRI:
    mesh_file << "<Topology TopologyType='Triangle'";
    epn = 3;
    break;
  case QUAD:
    mesh_file << "<Topology TopologyType='Quadrilateral'";
    epn = 4;
    break;
  case HEXA:
    mesh_file << "<Topology TopologyType='Hexahedron'";
    epn = 8;
    break;
  case TETRA:
    mesh_file << "<Topology TopologyType='Tetrahedron'";
    epn = 4;
    break;
  default:
    cout << "Unknown mesh type " << _eType.at(0) << endl;
    return;
  }
  mesh_file << " Dimensions='" << tot_elems << "'>" << endl;
  mesh_file << "    <DataItem Dimensions='" << tot_elems << " " << epn << "'>" << endl;

  //connectivity (Topology)
  for (int n = 0; n < tot_elems; n++) {
    mesh_file << "      ";
    for (int node = 0; node < cellNodes.getCount(n); node++)
        mesh_file << cellNodes(n,node) << " ";
    mesh_file << endl;
  }
  mesh_file << "    </DataItem>" << endl;
  mesh_file << "  </Topology>" << endl;

  // Geometry
  mesh_file << "  <Geometry Type='XYZ'>" << endl;
  mesh_file << "    <DataItem Dimensions='" << tot_nodes << " 3' NumberType='Float'>" << endl;
  for (int n = 0; n < tot_nodes; n++) {
    mesh_file << "      ";
    mesh_file << coord[n][0] << " " ;
    mesh_file << coord[n][1] << " " ;
    mesh_file << coord[n][2] << endl;
  }
  mesh_file << "    </DataItem>" << endl;
  mesh_file << "  </Geometry>" << endl;
  mesh_file << "</Grid>" << endl;
  mesh_file.close();
}

const MeshList& MeshPartitioner::meshList ( ) const

inline

Definition at line 49 of file MeshPartitioner.h.

{ return _meshListLocal; }

void MeshPartitioner::non_interior_cells ( )

private

Definition at line 1565 of file MeshPartitioner.cpp.

References _debugMode, _faceCells, _nelems, _nmesh, _nonInteriorCells, _partFaces, _procID, and DEBUG_non_interior_cells().

Referenced by mesh().

{
     for ( int id = 0; id < _nmesh; id++ ){
         int nface_local = _partFaces.at(id)->getCount( _procID );
         for ( int face = 0; face < nface_local; face++){
             int cell_0 = (*_faceCells.at(id))(face,0);
             int cell_1 = (*_faceCells.at(id))(face,1);
             if ( cell_0 >= _nelems.at(id) )
               _nonInteriorCells.at(id).insert(cell_0);
             if ( cell_1 >= _nelems.at(id) )
               _nonInteriorCells.at(id).insert(cell_1);

        }
    }

    if ( _debugMode )
        DEBUG_non_interior_cells();
}

void MeshPartitioner::order_faceCells_faceNodes ( )

private

Definition at line 1666 of file MeshPartitioner.cpp.

References _bndryOffsets, _boundarySet, _cellCells, _cellNodes, _cellToOrderedCell, _cellToPreservedOrderCell, _debugMode, _faceCells, _faceCellsOrdered, _faceNodes, _faceNodesOrdered, _globalToLocal, _globalToLocalMappers, _interfaceMap, _interfaceOffsets, _interfaceSet, _localToGlobalMappers, _mapBounIDAndCell, _meshListLocal, _nelemsWithGhosts, _nmesh, _nonInteriorCells, _partFaces, _procID, construct_mesh(), DEBUG_order_faceCells_faceNodes(), and preserve_cell_order().

Referenced by mesh().

{

     for ( int id = 0; id < _nmesh; id++ ){
        int tot_cells = _nelemsWithGhosts.at(id) + _interfaceMap.at(id).size();
        construct_mesh( id );

        _faceCellsOrdered.push_back( CRConnectivityPtr( new  CRConnectivity(_meshListLocal.at(id)->getFaces(), _meshListLocal.at(id)->getCells() ) ) );
        _faceNodesOrdered.push_back( CRConnectivityPtr( new  CRConnectivity(_meshListLocal.at(id)->getFaces(), _meshListLocal.at(id)->getNodes() ) ) );
        _cellToOrderedCell[id].assign(tot_cells, -1);
        //first preserve order cells (stick with global numbering)
         preserve_cell_order();
          //faceCells
         _faceCellsOrdered.at(id)->initCount();
         _faceNodesOrdered.at(id)->initCount();

         int nface = _partFaces.at(id)->getCount(_procID);
         int count_node = _faceNodes.at(id)->getRow()[1] - _faceNodes.at(id)->getRow()[0];
         int count_cell = _faceCells.at(id)->getRow()[1] - _faceCells.at(id)->getRow()[0];
         for ( int face = 0; face < nface; face++){
            _faceCellsOrdered.at(id)->addCount(face,count_cell);  //two cells (always)
            _faceNodesOrdered.at(id)->addCount(face,count_node);  //two, three or four nodes
         }

         _faceCellsOrdered.at(id)->finishCount();
         _faceNodesOrdered.at(id)->finishCount();

         //start with interior faces
         int array_length = _faceCells.at(id)->getLocalToGlobalMap().getLength();
         assert( array_length == tot_cells );

         int face_track = 0;
         int nface_local = _partFaces.at(id)->getCount( _procID );
         for ( int face = 0; face < nface_local; face++){
             int cell_0 = (*_faceCells.at(id))(face,0);
             int cell_1 = (*_faceCells.at(id))(face,1);
             //find if this face is interior or not
             bool is_interior = _nonInteriorCells.at(id).count(cell_0) == 0 &&
                                _nonInteriorCells.at(id).count(cell_1) == 0;

              if ( is_interior ) {
                   int cellID0 = _cellToPreservedOrderCell[cell_0];
                   int cellID1 = _cellToPreservedOrderCell[cell_1];
                    //map to cell number to preserved ordering mapping
                   _cellToOrderedCell[id][cell_0] = cellID0;
                   _cellToOrderedCell[id][cell_1] = cellID1;
                    //add operation to faceCells
                   _faceCellsOrdered.at(id)->add(face_track,cellID0);
                   _faceCellsOrdered.at(id)->add(face_track,cellID1);
                   //storing things as mappers
                   int globalID0 = _faceCells.at(id)->getLocalToGlobalMap()[cell_0];
                   int globalID1 = _faceCells.at(id)->getLocalToGlobalMap()[cell_1];
                   _globalToLocalMappers.at(id).insert( pair<int,int>(globalID0,cellID0 ) );
                   _globalToLocalMappers.at(id).insert( pair<int,int>(globalID1,cellID1 ) );
                   _localToGlobalMappers.at(id).insert( pair<int,int>(cellID0, globalID0) );
                   _localToGlobalMappers.at(id).insert( pair<int,int>(cellID1, globalID1) );
                   //faceNodesOrdered
                   for  ( int node = 0; node < count_node; node++ )
                      _faceNodesOrdered.at(id)->add( face_track, (*_faceNodes.at(id))( face, node ) );
                   face_track++;
              }
         }

         //check if any inner cells are not visited from above search (it might be inner cell
         //surrounded by interface/boundary faces,so,the above loop fail to catch inner cells)
        foreach(const IntMap::value_type& mpos, _cellToPreservedOrderCell){
             int cellID     = mpos.first;
             int global_id = _faceCells.at(id)->getLocalToGlobalMap()[cellID];
             if ( _cellToOrderedCell[0][cellID] == -1 ){ //means not visited
                 int orderedCellID = mpos.second;
                 _cellToOrderedCell[0][cellID] = orderedCellID;
                 _globalToLocalMappers.at(id).insert( pair<int,int>(global_id,orderedCellID)  );
                 _localToGlobalMappers.at(id).insert( pair<int,int>(orderedCellID, global_id) );
             }
        }

       int cellID = _cellToPreservedOrderCell.size();
        //then boundary faces
       multimap<int,int>::const_iterator it_cell;
       pair<multimap<int,int>::const_iterator,multimap<int,int>::const_iterator> it;
       set<int> ::const_iterator it_set;
       int offset = face_track;
       //loop over boundaries
       for ( it_set = _boundarySet.at(id).begin(); it_set != _boundarySet.at(id).end(); it_set++){
          int bndryID = *it_set;
          it = _mapBounIDAndCell.at(id).equal_range(bndryID);
          //if it is not empty
          if ( _mapBounIDAndCell.at(id).count( bndryID ) > 0 )
             _bndryOffsets.at(id).insert( pair<int,int>(bndryID, offset) );

          for ( it_cell = it.first; it_cell != it.second; it_cell++ ){
               int elem_0 = _globalToLocal[it_cell->second];
               int elem_1 =  (*_cellCells.at(id))(elem_0, 0);
               assert( elem_0 != elem_1 );
               int inner_elem = _cellToOrderedCell[id][elem_1];
               int outer_elem = cellID;

               //update globalToLocal and localToGlobalMaps
               _globalToLocalMappers.at(id).insert( pair<int,int>(it_cell->second,cellID ) );
               _localToGlobalMappers.at(id).insert( pair<int,int>(cellID, it_cell->second) );
               _cellToOrderedCell[id][elem_0] = cellID;

               _faceCellsOrdered.at(id)->add(face_track, inner_elem);
               _faceCellsOrdered.at(id)->add(face_track, outer_elem);

               int count_node = _faceNodes.at(id)->getRow()[1] - _faceNodes.at(id)->getRow()[0];
               for  ( int node = 0; node < count_node; node++)
                    _faceNodesOrdered.at(id)->add( face_track, (*_cellNodes.at(id))(elem_0,node) );

              face_track++;
              offset++;
              cellID++;
          }
       }


       //then interface faces
       multimap<int,int>::const_iterator it_face;
       for ( it_set = _interfaceSet.at(id).begin(); it_set != _interfaceSet.at(id).end(); it_set++){
          int interfaceID = *it_set;
          it = _interfaceMap.at(id).equal_range( interfaceID );
          _interfaceOffsets.at(id).insert( pair<int,int>(interfaceID,offset) ) ;
          for ( it_face = it.first; it_face != it.second; it_face++ ){
              int face_id = it_face->second;
              int elem_0 =  (*_faceCells.at(id))(face_id,0);
              int elem_1 =  (*_faceCells.at(id))(face_id,1);
              int outer_elem_id = -1;

             if ( _nonInteriorCells.at(id).count( elem_1 ) > 0 ){ //if elem_1 is non-interior cell
                _faceCellsOrdered.at(id)->add(face_track,_cellToOrderedCell[id][elem_0]);
                 outer_elem_id = elem_1;
             } else {
                _faceCellsOrdered.at(id)->add(face_track,_cellToOrderedCell[id][elem_1]);
                outer_elem_id = elem_0;
             }
            _faceCellsOrdered.at(id)->add(face_track,cellID);

             //update maps
             int global_id = _faceCells.at(id)->getLocalToGlobalMap()[outer_elem_id];
             assert( cellID >=0 && cellID < array_length );
             _globalToLocalMappers.at(id).insert( pair<int,int>(global_id, cellID) );
             _localToGlobalMappers.at(id).insert( pair<int,int>(cellID, global_id) );
             _cellToOrderedCell[id][outer_elem_id] = cellID;

             int count_node = _faceNodes.at(id)->getRow()[1] - _faceNodes.at(id)->getRow()[0];

             if ( outer_elem_id == elem_1 ) {
                 for  ( int  node = 0; node < count_node; node++)
                    _faceNodesOrdered.at(id)->add( face_track, (*_faceNodes.at(id))( face_id, node ) );
             } else {
                 for  ( int  node = count_node-1; node >= 0; node--)
                    _faceNodesOrdered.at(id)->add( face_track, (*_faceNodes.at(id))( face_id, node ) );
             }

              face_track++;
              offset++;
              cellID++;
          }

       }

        _faceCellsOrdered.at(id)->finishAdd();
        _faceNodesOrdered.at(id)->finishAdd();
        assert(  cellID == tot_cells );
     }


     if ( _debugMode )
         DEBUG_order_faceCells_faceNodes();

}

void MeshPartitioner::parmetis_mesh ( )

private

Definition at line 573 of file MeshPartitioner.cpp.

References _debugMode, _edgecut, _eInd, _elmWght, _ePtr, _globalIndx, _ncommonNodes, _ncon, _nmesh, _nPart, _numFlag, _options, _part, _tpwgts, _ubvec, _wghtFlag, and DEBUG_parmetis_mesh().

Referenced by partition().

{
   MPI_Comm comm_world = MPI::COMM_WORLD;
   for ( int id = 0; id < _nmesh; id++){
       ParMETIS_V3_PartMeshKway( &(*_globalIndx.at(id))[0], _ePtr.at(id), _eInd.at(id),
        _elmWght.at(id), &_wghtFlag.at(id), &_numFlag.at(id), &_ncon.at(id),  &_ncommonNodes.at(id),
        &_nPart.at(id), _tpwgts.at(id), _ubvec.at(id), &_options, &_edgecut.at(id), _part.at(id), &comm_world );

   }

   if ( _debugMode )
      DEBUG_parmetis_mesh();

}

void MeshPartitioner::partition

(

)

Definition at line 97 of file MeshPartitioner.cpp.

References _partTYPE, compute_elem_dist(), count_elems_part(), elem_connectivity(), exchange_part_elems(), FIEDLER, fiedler_partition(), map_part_elms(), PARMETIS, and parmetis_mesh().

{

     compute_elem_dist();
     if ( _partTYPE == FIEDLER  )
        fiedler_partition();
     elem_connectivity();
     if ( _partTYPE == PARMETIS )
        parmetis_mesh();
     map_part_elms();
     count_elems_part();
     exchange_part_elems();
    //dumpTecplot();

}

void MeshPartitioner::preserve_cell_order ( )

private

Definition at line 1607 of file MeshPartitioner.cpp.

References _cellToPreservedOrderCell, _debugMode, _faceCells, _globalToLocal, DEBUG_preserve_cell_order(), CRConnectivity::getGlobalToLocalMap(), Array< T >::getLength(), and CRConnectivity::getLocalToGlobalMap().

Referenced by order_faceCells_faceNodes().

{

   const CRConnectivity& faceCells    = *_faceCells.at(0);
   const Array<int>& globalToLocalList = faceCells.getGlobalToLocalMap();
   const Array<int>& localToGlobalList = faceCells.getLocalToGlobalMap();
   set<int> globalCellList;
   //first copy _faceCells.GlobalTocell to some set which will be ordered from smallest integer to largest one
   for ( int i = 0; i < globalToLocalList.getLength(); i++){
       if ( globalToLocalList[i] != -1 ){
            globalCellList.insert( i );
       }
   }
  //now use ordered set
  int indx = 0;
  foreach(  const set<int>::value_type globalID, globalCellList ){
       int localID = globalToLocalList[globalID];
       _cellToPreservedOrderCell[localID] = indx++;
  }
  //use global to Local
  for ( int i = 0; i < localToGlobalList.getLength(); i++ ){
      const int glblID = localToGlobalList[i];
      _globalToLocal[glblID] = i;
  }

  if ( _debugMode )
     DEBUG_preserve_cell_order();

}

void MeshPartitioner::resize_elem ( int  id )

private

Definition at line 1124 of file MeshPartitioner.cpp.

References _debugMode, _elem, _elemWithGhosts, _mapBounIDAndCell, _nelems, _nelemsWithGhosts, and DEBUG_resize_elem().

Referenced by CRConnectivity_cellParts().

{
   int  tot_cells = _mapBounIDAndCell.at(id).size() + _nelems.at(id);
   _nelemsWithGhosts.at(id) = tot_cells;
   _elemWithGhosts.push_back(  new int[ tot_cells] );

   //assign old values
   for ( int n = 0;  n < _nelems.at(id); n++)
       _elemWithGhosts.at(id)[n] = _elem.at(id)[n];
   //ghost part assigned
   multimap<int,int>::const_iterator it;
   int indx = _nelems.at(id);
   for ( it = _mapBounIDAndCell.at(id).begin(); it != _mapBounIDAndCell.at(id).end(); it++){
      _elemWithGhosts.at(id)[indx] = it->second;
      indx++;
   }

   if ( _debugMode )
      DEBUG_resize_elem();

}

void MeshPartitioner::scatterCellsLevel1 ( )

private

void MeshPartitioner::set_cellcells_global ( )

private

Definition at line 2252 of file MeshPartitioner.cpp.

References _debugMode, _meshListLocal, cellcells_global_extension(), DEBUG_cellcells_global(), Mesh::getCellCells(), Mesh::getCellCellsGlobal(), Mesh::getCells(), StorageSite::getCount(), CRConnectivity::getCount(), and Mesh::getLocalToGlobal().

Referenced by mesh().

{
   const int nmesh = int( _meshListLocal.size() );
   //get offsets for
   for ( int id = 0; id < nmesh; id++ ){
      Mesh&    mesh = *_meshListLocal.at(id);
      Mesh::multiMap&  cellCellsGlobal = mesh.getCellCellsGlobal();
      const Array<int>& localToGlobal = mesh.getLocalToGlobal();
      const StorageSite&     cellSite  = mesh.getCells();
      const CRConnectivity& cellCells = mesh.getCellCells();
      //loop over
      const int ncells = cellSite.getCount();
      for ( int n = 0; n < ncells; n++ ){
         const int iend = cellCells.getCount(n);
         //cellCellsGlobal.insert( pair<int,int>(n, localToGlobal[n]) );
         for ( int i = 0; i < iend; i++ ){
            const int localCellID = cellCells(n,i);
            cellCellsGlobal.insert( pair<int,int>(n, localToGlobal[localCellID] ) );
         }
      }
   }

   cellcells_global_extension();

   if ( _debugMode )
      DEBUG_cellcells_global();

}

void MeshPartitioner::set_eptr_eind ( int  id )

private

Definition at line 517 of file MeshPartitioner.cpp.

References _eElm, _eInd, _elemDist, _ePtr, _eType, _globalIndx, _meshList, _procID, Mesh::getCellNodes(), CRConnectivity::getCount(), HEXA, QUAD, TETRA, and TRI.

Referenced by elem_connectivity().

{
      const Mesh* mesh = _meshList[id];
      const CRConnectivity& cellNodes = mesh->getCellNodes();

      int elem_start   = (*_globalIndx.at(id))[_procID];
      int elem_finish  = elem_start + (*_elemDist[id])[_procID];
      int indxInd   = 0;
      int indxPtr   = 0;
      _ePtr.at(id)[indxPtr] = 0;
      for ( int elem = elem_start; elem < elem_finish; elem++ ){
          _eElm.at(id)[indxPtr] = elem;  //mapping local to global Index
           indxPtr++;
          _ePtr.at(id)[indxPtr] = _ePtr.at(id)[indxPtr-1] +  cellNodes.getCount(elem);
          if ( _eType.at(id) == TRI || _eType.at(id) == TETRA || _eType.at(id) == HEXA ){ // connectivity orientation is not important
              for (  int node = 0; node < cellNodes.getCount(elem); node++ )
                 _eInd.at(id)[indxInd++] = cellNodes(elem,node);
          }

         if ( _eType.at(id) == QUAD ) {  //connectivity orientation is reversed for QUADs since Parmetis require clockwise orientation
              for (  int node = cellNodes.getCount(elem)-1; node >=0; node-- )
                 _eInd.at(id)[indxInd++] = cellNodes(elem,node);
         }

      }

}

void MeshPartitioner::set_local_global ( )

private

Definition at line 2141 of file MeshPartitioner.cpp.

References _debugMode, _localToGlobalMappers, _meshListLocal, Mesh::createLocalGlobalArray(), DEBUG_local_global(), Mesh::getAllFaceCells(), Mesh::getBoundaryFaceGroups(), Mesh::getBoundaryGroupCount(), CRConnectivity::getCount(), StorageSite::getCountLevel1(), Mesh::getGlobalToLocal(), Mesh::getLocalToGlobal(), StorageSite::getSelfCount(), and global_offset().

Referenced by mesh().

{
    const int nmesh = int( _meshListLocal.size() );
    //creating cellID MultiField to use sync() operation
    shared_ptr<MultiField>  cellMultiField = shared_ptr<MultiField>( new MultiField()    );
    shared_ptr<Field>       cellField      = shared_ptr<Field>     ( new Field("globalcellID") );

    for ( int id = 0; id < nmesh; id++ ){
       const StorageSite* site = &_meshListLocal[id]->getCells();
       MultiField::ArrayIndex ai( cellField.get(), site );
       shared_ptr<Array<int> > cIndex(new Array<int>(site->getCountLevel1()));
       *cIndex = -1;
       cellMultiField->addArray(ai,cIndex);
    }

    //global numbering
    const int globalOffset = global_offset();
    int offset = globalOffset;
    for ( int id = 0; id < nmesh; id++ ){
       const Mesh&    mesh = *_meshListLocal.at(id);
       const StorageSite* site = &_meshListLocal[id]->getCells();
       MultiField::ArrayIndex ai( cellField.get(), site );
       Array<int>&  localCell = dynamic_cast< Array<int>& >( (*cellMultiField)[ai] );
       //global numbering inner cells
       const int selfCount = site->getSelfCount();
       const  map<int,int>&  localToGlobalMappers = _localToGlobalMappers.at(0);
       for ( int i = 0; i < selfCount; i++ ){
          localCell[i] = offset + i;
          localCell[i] = localToGlobalMappers.find(i)->second;
       }
       //update offset
       offset += selfCount;
       //loop over boundaries and global number boundary cells
       const FaceGroupList&  bounGroupList = mesh.getBoundaryFaceGroups();
       const CRConnectivity& faceCells  = mesh.getAllFaceCells();
       for ( int i = 0; i < mesh.getBoundaryGroupCount(); i++ ){
          const int ibeg = bounGroupList[i]->site.getOffset();
          const int iend = ibeg + bounGroupList[i]->site.getCount();
          int indx=0;
          for ( int ii = ibeg; ii < iend; ii++ ){
             const int cellID = faceCells(ii,1);
             localCell[ cellID] =localToGlobalMappers.find(cellID)->second ;
             indx++;
          }
          //update offset
          offset += iend-ibeg;
       }
    }

    //sync opeartion
    cellMultiField->sync();

    //create localToGlobal array and assign it in Mesh
    for ( int id = 0; id < nmesh; id++ ){
       Mesh& mesh = *_meshListLocal.at(id);
       mesh.createLocalGlobalArray();
       const StorageSite* site = &_meshListLocal[id]->getCells();
       MultiField::ArrayIndex ai( cellField.get(), site );
       const Array<int>&  localCell = dynamic_cast< const Array<int>& >( (*cellMultiField)[ai] );
       Array<int>& localToGlobal = mesh.getLocalToGlobal();
       for ( int i = 0; i < localCell.getLength(); i++ ){
          localToGlobal[i] = localCell[i];
          assert( localCell[i] != -1 );
       }

       //copying GlobalToLocal
       map<int,int>& globalToLocal = mesh.getGlobalToLocal();
       for ( int i = 0; i < localCell.getLength(); i++ ){
          globalToLocal[ localToGlobal[i] ] = i;
       }
    }

   if ( _debugMode )
      DEBUG_local_global();

}

void MeshPartitioner::setMeshColors ( )

private

Definition at line 1000 of file MeshPartitioner.cpp.

References _localToGlobalMappers, _meshList, _meshListLocal, StorageSite::getCount(), StorageSite::getCountLevel1(), StorageSite::getSelfCount(), and Array< T >::resize().

Referenced by mesh().

{
    //get number of meshes assembled from meshList
    int nmesh = _meshList.at(0)->getNumOfAssembleMesh();
    //assing nmesh and make Mesh::_isAssembledMesh == true
    _meshListLocal.at(0)->setNumOfAssembleMesh( nmesh );
    _meshListLocal.at(0)->createCellColor();
    //get cellsite storagesite
    const StorageSite& cellSite = _meshListLocal.at(0)->getCells();
    Array<int>&   colorGlbl     = _meshList.at(0)->getCellColors();
    Array<int>&   colorLocal      = _meshListLocal.at(0)->getCellColors();
    Array<int>&   colorOtherLocal = _meshListLocal.at(0)->getCellColorsOther();
    const  map<int,int>&  localToGlobalMappers = _localToGlobalMappers.at(0);
    //loop first over inner cells to color them
    for ( int i = 0; i <  cellSite.getSelfCount(); i++ ){
        int glblID = localToGlobalMappers.find(i)->second;
        colorLocal[i] = colorGlbl[ glblID ];
    }
    //coloring other cells (boundary+ghostcells)
    //we check across cell's color, they should have the same color.
    const CRConnectivity& cellCells = _meshListLocal.at(0)->getCellCells();
    for ( int i = cellSite.getSelfCount(); i < cellSite.getCount(); i++ ){
       int acrossCellID = cellCells(i,0); //ghost or boundary has only one cell connected
       colorLocal[i] = colorLocal[ acrossCellID ];
    }

    //colorOtherLocal loop first over inner cells to color them, this color ghost cell according to their real location
    colorOtherLocal.resize( cellSite.getCountLevel1() );
    const Array<int>& localToGlobal = _meshListLocal.at(0)->getLocalToGlobal();
    for ( int i = 0; i <  cellSite.getCountLevel1(); i++ ){
        int glblID = localToGlobal[i];
        colorOtherLocal[i] = colorGlbl[ glblID ];
    }


}

void MeshPartitioner::setNumFlag

(

int

num_flag

)

Definition at line 289 of file MeshPartitioner.cpp.

References _nmesh, and _numFlag.

{
  for ( int id = 0; id < _nmesh; id++)
      _numFlag.at(id) = num_flag;

}

void MeshPartitioner::setWeightType

(

int

weight_type

)

Definition at line 281 of file MeshPartitioner.cpp.

References _nmesh, and _wghtFlag.

{
   for ( int id = 0; id < _nmesh; id++)
      _wghtFlag.at(id) =  weight_type;

}

void MeshPartitioner::shift_sum_row ( )

private

Definition at line 878 of file MeshPartitioner.cpp.

References _nelems, _nmesh, and _row.

Referenced by exchange_part_elems().

{
   for ( int id = 0; id < _nmesh; id++){
       //shift [0,n] to [1,n+1]
       for ( int n = _nelems.at(id); n > 0; n--)
           _row.at(id)[n] = _row.at(id)[n-1];
      _row.at(id)[0] = 0;
      //summing row ex: row = {0,3,6,9,...} for triangle (three nodes)
       for ( int n = 1; n < _nelems.at(id)+1; n++ )
          _row.at(id)[n] += _row.at(id)[n-1];

   }


}

Member Data Documentation

Mesh* MeshPartitioner::_bMesh

private

Definition at line 264 of file MeshPartitioner.h.

Referenced by extractBoundaryMesh(), and ~MeshPartitioner().

vector< map<int,int> > MeshPartitioner::_bndryOffsets

private

Definition at line 233 of file MeshPartitioner.h.

Referenced by init(), mesh_setup(), and order_faceCells_faceNodes().

vector< set<int> > MeshPartitioner::_boundarySet

private

Definition at line 223 of file MeshPartitioner.h.

Referenced by DEBUG_mapBounIDAndCell(), init(), mapBounIDAndCell(), mesh_setup(), and order_faceCells_faceNodes().

vector< CRConnectivityPtr > MeshPartitioner::_cellCells

private

Definition at line 211 of file MeshPartitioner.h.

Referenced by DEBUG_faceCells_faceNodes(), faceCells_faceNodes(), and order_faceCells_faceNodes().

vector< CRConnectivityPtr > MeshPartitioner::_cellNodes

private

Definition at line 212 of file MeshPartitioner.h.

Referenced by DEBUG_faceCells_faceNodes(), faceCells_faceNodes(), and order_faceCells_faceNodes().

vector< CRConnectivityPtr > MeshPartitioner::_cellParts

private

Definition at line 216 of file MeshPartitioner.h.

Referenced by CRConnectivity_cellParts(), CRConnectivity_faceParts(), DEBUG_CRConnectivity_cellParts(), and faceCells_faceNodes().

vector< StorageSitePtr > MeshPartitioner::_cellSite

private

Definition at line 200 of file MeshPartitioner.h.

Referenced by faceCells_faceNodes().

vector< StorageSitePtr > MeshPartitioner::_cellSiteGlobal

private

Definition at line 199 of file MeshPartitioner.h.

Referenced by CRConnectivity_cellParts().

map<int,int> MeshPartitioner::_cellsLevel1PartID

private

Definition at line 240 of file MeshPartitioner.h.

Referenced by DEBUG_globalCellID_procID_map(), gatherCellsLevel1_partID_map(), and globalCellID_procID_map().

vector< vector<int> > MeshPartitioner::_cellToOrderedCell

private

Definition at line 235 of file MeshPartitioner.h.

Referenced by init(), mesh_tecplot(), and order_faceCells_faceNodes().

map<int,int> MeshPartitioner::_cellToPreservedOrderCell

private

Definition at line 239 of file MeshPartitioner.h.

Referenced by DEBUG_preserve_cell_order(), order_faceCells_faceNodes(), and preserve_cell_order().

bool MeshPartitioner::_cleanup

private

Definition at line 260 of file MeshPartitioner.h.

Referenced by exchange_part_elems(), faceCells_faceNodes(), init(), mappers(), and ~MeshPartitioner().

vector< int* > MeshPartitioner::_col

private

Definition at line 188 of file MeshPartitioner.h.

Referenced by cleanup_follow_exchange_part_elems(), count_elems_part(), DEBUG_exchange_part_elems(), exchange_part_elems(), and ~MeshPartitioner().

vector<int> MeshPartitioner::_colDim

private

Definition at line 196 of file MeshPartitioner.h.

Referenced by count_elems_part(), DEBUG_count_elems_part(), DEBUG_exchange_part_elems(), and init().

vector< ArrayVecD3Ptr > MeshPartitioner::_coord

private

Definition at line 227 of file MeshPartitioner.h.

Referenced by coordinates(), DEBUG_coordinates(), and mesh_setup().

ofstream MeshPartitioner::_debugFile

private

Definition at line 262 of file MeshPartitioner.h.

Referenced by CRConnectivityPrintFile(), DEBUG_cellcells_global(), DEBUG_compute_elem_dist(), DEBUG_coordinates(), DEBUG_count_elems_part(), DEBUG_CRConnectivity_cellParts(), DEBUG_CRConnectivity_faceParts(), DEBUG_elem_connectivity(), DEBUG_exchange_interface_meshes(), DEBUG_exchange_part_elems(), DEBUG_faceCells_faceNodes(), DEBUG_fiedler_partition(), debug_file_close(), debug_file_open(), DEBUG_gatherCellsLevel1_partID_map(), DEBUG_globalCellID_procID_map(), DEBUG_interfaces(), DEBUG_level1_scatter_gather_cells(), DEBUG_local_global(), DEBUG_map_part_elms(), DEBUG_mapBounIDAndCell(), DEBUG_non_interior_cells(), DEBUG_order_faceCells_faceNodes(), DEBUG_parmetis_mesh(), DEBUG_preserve_cell_order(), and DEBUG_resize_elem().

bool MeshPartitioner::_debugMode

private

Definition at line 261 of file MeshPartitioner.h.

Referenced by compute_elem_dist(), coordinates(), count_elems_part(), CRConnectivity_cellParts(), CRConnectivity_faceParts(), elem_connectivity(), exchange_interface_meshes(), exchange_part_elems(), faceCells_faceNodes(), fiedler_partition(), gatherCellsLevel1_partID_map(), globalCellID_procID_map(), init(), interfaces(), level1_scatter_gather_cells(), map_part_elms(), mapBounIDAndCell(), mappers(), non_interior_cells(), order_faceCells_faceNodes(), parmetis_mesh(), preserve_cell_order(), resize_elem(), set_cellcells_global(), and set_local_global().

vector< int > MeshPartitioner::_edgecut

private

Definition at line 182 of file MeshPartitioner.h.

Referenced by init(), and parmetis_mesh().

vector< int* > MeshPartitioner::_eElm

private

Definition at line 170 of file MeshPartitioner.h.

Referenced by cleanup_follow_exchange_part_elems(), DEBUG_elem_connectivity(), elem_connectivity(), exchange_part_elems(), set_eptr_eind(), and ~MeshPartitioner().

vector< int* > MeshPartitioner::_eInd

private

Definition at line 169 of file MeshPartitioner.h.

Referenced by cleanup_follow_exchange_part_elems(), DEBUG_elem_connectivity(), elem_connectivity(), exchange_part_elems(), parmetis_mesh(), set_eptr_eind(), and ~MeshPartitioner().

vector< int* > MeshPartitioner::_elem

private

Definition at line 189 of file MeshPartitioner.h.

Referenced by cleanup_follow_faceCells_faceNodes(), count_elems_part(), DEBUG_exchange_part_elems(), exchange_part_elems(), mapBounIDAndCell(), resize_elem(), and ~MeshPartitioner().

vector< Array<int>* > MeshPartitioner::_elemDist

private

Definition at line 166 of file MeshPartitioner.h.

Referenced by compute_elem_dist(), DEBUG_compute_elem_dist(), DEBUG_elem_connectivity(), DEBUG_fiedler_partition(), DEBUG_parmetis_mesh(), elem_connectivity(), fiedler_partition(), get_local_nodes(), map_part_elms(), set_eptr_eind(), and ~MeshPartitioner().

vector< set<int> > MeshPartitioner::_elemSet

private

Definition at line 190 of file MeshPartitioner.h.

Referenced by DEBUG_mapBounIDAndCell(), init(), and mapBounIDAndCell().

vector< int* > MeshPartitioner::_elemWithGhosts

private

Definition at line 191 of file MeshPartitioner.h.

Referenced by CRConnectivity_cellParts(), DEBUG_resize_elem(), resize_elem(), and ~MeshPartitioner().

vector< int* > MeshPartitioner::_elmWght

private

Definition at line 171 of file MeshPartitioner.h.

Referenced by cleanup_follow_exchange_part_elems(), elem_connectivity(), parmetis_mesh(), and ~MeshPartitioner().

vector< int* > MeshPartitioner::_ePtr

private

Definition at line 168 of file MeshPartitioner.h.

Referenced by cleanup_follow_exchange_part_elems(), count_elems_part(), DEBUG_elem_connectivity(), elem_connectivity(), exchange_part_elems(), parmetis_mesh(), set_eptr_eind(), and ~MeshPartitioner().

vector< int > MeshPartitioner::_eType

private

Definition at line 176 of file MeshPartitioner.h.

Referenced by init(), mesh_tecplot(), mesh_xdmfplot(), and set_eptr_eind().

vector< CRConnectivityPtr > MeshPartitioner::_faceCells

private

Definition at line 209 of file MeshPartitioner.h.

Referenced by DEBUG_faceCells_faceNodes(), faceCells_faceNodes(), non_interior_cells(), order_faceCells_faceNodes(), and preserve_cell_order().

vector< const CRConnectivity* > MeshPartitioner::_faceCellsGlobal

private

Definition at line 206 of file MeshPartitioner.h.

Referenced by cleanup_follow_faceCells_faceNodes(), CRConnectivity_faceParts(), and faceCells_faceNodes().

vector< CRConnectivityPtr > MeshPartitioner::_faceCellsOrdered

private

Definition at line 213 of file MeshPartitioner.h.

Referenced by DEBUG_order_faceCells_faceNodes(), exchange_interface_meshes(), mesh_setup(), and order_faceCells_faceNodes().

vector< CRConnectivityPtr > MeshPartitioner::_faceNodes

private

Definition at line 210 of file MeshPartitioner.h.

Referenced by DEBUG_faceCells_faceNodes(), faceCells_faceNodes(), and order_faceCells_faceNodes().

vector< const CRConnectivity* > MeshPartitioner::_faceNodesGlobal

private

Definition at line 207 of file MeshPartitioner.h.

Referenced by cleanup_follow_faceCells_faceNodes(), CRConnectivity_faceParts(), and faceCells_faceNodes().

vector< CRConnectivityPtr > MeshPartitioner::_faceNodesOrdered

private

Definition at line 214 of file MeshPartitioner.h.

Referenced by DEBUG_order_faceCells_faceNodes(), mesh_setup(), and order_faceCells_faceNodes().

vector< CRConnectivityPtr > MeshPartitioner::_faceParts

private

Definition at line 218 of file MeshPartitioner.h.

Referenced by CRConnectivity_faceParts(), DEBUG_CRConnectivity_faceParts(), and interfaces().

vector< StorageSitePtr > MeshPartitioner::_faceSite

private

Definition at line 202 of file MeshPartitioner.h.

Referenced by faceCells_faceNodes().

ArrayIntPtr MeshPartitioner::_fiedlerMap

private

Definition at line 255 of file MeshPartitioner.h.

Referenced by DEBUG_fiedler_partition(), fiedler_order(), and fiedler_partition().

vector< vector< ArrayIntPtr > > MeshPartitioner::_fromIndices

private

Definition at line 253 of file MeshPartitioner.h.

Referenced by init(), and mappers().

map<int,int> MeshPartitioner::_gatherCellsLevel1PartIDMap

private

Definition at line 241 of file MeshPartitioner.h.

Referenced by DEBUG_gatherCellsLevel1_partID_map(), gatherCellsLevel1_partID_map(), and level1_scatter_gather_cells().

vector< ArrayIntPtr > MeshPartitioner::_ghostCellsGlobal

private

Definition at line 248 of file MeshPartitioner.h.

Referenced by create_window(), DEBUG_exchange_interface_meshes(), and exchange_interface_meshes().

vector< ArrayIntPtr > MeshPartitioner::_ghostCellsLocal

private

Definition at line 249 of file MeshPartitioner.h.

Referenced by create_window(), DEBUG_exchange_interface_meshes(), and exchange_interface_meshes().

vector< Array<int>* > MeshPartitioner::_globalIndx

private

Definition at line 167 of file MeshPartitioner.h.

Referenced by compute_elem_dist(), DEBUG_compute_elem_dist(), DEBUG_fiedler_partition(), DEBUG_parmetis_mesh(), elem_connectivity(), fiedler_partition(), get_local_nodes(), parmetis_mesh(), set_eptr_eind(), and ~MeshPartitioner().

map<int,int> MeshPartitioner::_globalToLocal

private

Definition at line 238 of file MeshPartitioner.h.

Referenced by DEBUG_preserve_cell_order(), order_faceCells_faceNodes(), and preserve_cell_order().

vector< multimap<int,int> > MeshPartitioner::_globalToLocalMappers

private

Definition at line 236 of file MeshPartitioner.h.

Referenced by cleanup_follow_mappers(), init(), mappers(), and order_faceCells_faceNodes().

vector< multimap<int,int> > MeshPartitioner::_interfaceMap

private

Definition at line 229 of file MeshPartitioner.h.

Referenced by construct_mesh(), count_interior_faces(), DEBUG_interfaces(), exchange_interface_meshes(), faceCells_faceNodes(), interfaces(), mappers(), mesh_setup(), and order_faceCells_faceNodes().

vector< ArrayIntPtr > MeshPartitioner::_interfaceMeshCounts

private

Definition at line 244 of file MeshPartitioner.h.

Referenced by DEBUG_exchange_interface_meshes(), exchange_interface_meshes(), get_window_displ(), and init().

vector< ArrayIntPtr > MeshPartitioner::_interfaceMeshIDs

private

Definition at line 247 of file MeshPartitioner.h.

Referenced by DEBUG_exchange_interface_meshes(), exchange_interface_meshes(), and get_window_displ().

vector< map<int,int> > MeshPartitioner::_interfaceOffsets

private

Definition at line 234 of file MeshPartitioner.h.

Referenced by exchange_interface_meshes(), init(), mesh_setup(), and order_faceCells_faceNodes().

vector< set<int> > MeshPartitioner::_interfaceSet

private

Definition at line 228 of file MeshPartitioner.h.

Referenced by exchange_interface_meshes(), init(), interfaces(), mappers(), mesh_setup(), and order_faceCells_faceNodes().

vector< map<int,int> > MeshPartitioner::_localToGlobalMappers

private

Definition at line 237 of file MeshPartitioner.h.

Referenced by cleanup_follow_mappers(), exchange_interface_meshes(), init(), order_faceCells_faceNodes(), set_local_global(), and setMeshColors().

vector< map<int,string> > MeshPartitioner::_mapBounIDAndBounType

private

Definition at line 225 of file MeshPartitioner.h.

Referenced by DEBUG_mapBounIDAndCell(), init(), mapBounIDAndCell(), and mesh_setup().

vector< multimap<int,int> > MeshPartitioner::_mapBounIDAndCell

private

Definition at line 224 of file MeshPartitioner.h.

Referenced by DEBUG_mapBounIDAndCell(), init(), mapBounIDAndCell(), mesh_setup(), order_faceCells_faceNodes(), and resize_elem().

vector< multimap<int,int> > MeshPartitioner::_mapPartAndElms

private

Definition at line 186 of file MeshPartitioner.h.

Referenced by count_elems_part(), DEBUG_map_part_elms(), exchange_part_elems(), init(), and map_part_elms().

const MeshList MeshPartitioner::_meshList

private

Definition at line 162 of file MeshPartitioner.h.

Referenced by construct_mesh(), coordinates(), CRConnectivity_faceParts(), DEBUG_fiedler_partition(), elem_connectivity(), extractBoundaryMesh(), fiedler_partition(), get_local_nodes(), init(), level1_scatter_gather_cells(), mapBounIDAndCell(), mesh(), MeshPartitioner(), set_eptr_eind(), and setMeshColors().

vector< Mesh* > MeshPartitioner::_meshListLocal

private

Definition at line 263 of file MeshPartitioner.h.

Referenced by cellcells_global_extension(), construct_mesh(), DEBUG_cellcells_global(), DEBUG_CRConnectivity_cellCells2(), DEBUG_level1_scatter_gather_cells(), DEBUG_local_global(), extractBoundaryMesh(), gatherCellsLevel1_partID_map(), global_offset(), globalCellID_procID_map(), level1_scatter_gather_cells(), mappers(), mesh_file(), mesh_setup(), mesh_tecplot(), mesh_xdmfplot(), order_faceCells_faceNodes(), set_cellcells_global(), set_local_global(), setMeshColors(), and ~MeshPartitioner().

vector< int > MeshPartitioner::_ncommonNodes

private

Definition at line 175 of file MeshPartitioner.h.

Referenced by init(), and parmetis_mesh().

vector< int > MeshPartitioner::_ncon

private

Definition at line 174 of file MeshPartitioner.h.

Referenced by elem_connectivity(), init(), and parmetis_mesh().

vector<int> MeshPartitioner::_nelems

private

Definition at line 194 of file MeshPartitioner.h.

Referenced by construct_mesh(), count_elems_part(), count_interior_faces(), DEBUG_count_elems_part(), DEBUG_exchange_part_elems(), DEBUG_faceCells_faceNodes(), faceCells_faceNodes(), init(), mapBounIDAndCell(), mesh_tecplot(), mesh_xdmfplot(), non_interior_cells(), resize_elem(), and shift_sum_row().

vector<int> MeshPartitioner::_nelemsWithGhosts

private

Definition at line 195 of file MeshPartitioner.h.

Referenced by construct_mesh(), count_interior_faces(), CRConnectivity_cellParts(), DEBUG_resize_elem(), faceCells_faceNodes(), init(), order_faceCells_faceNodes(), and resize_elem().

int MeshPartitioner::_nmesh

private

Definition at line 197 of file MeshPartitioner.h.

Referenced by cellcells_global_extension(), compute_elem_dist(), coordinates(), count_elems_part(), CRConnectivity_cellParts(), CRConnectivity_faceParts(), DEBUG_cellcells_global(), DEBUG_level1_scatter_gather_cells(), elem_connectivity(), exchange_interface_meshes(), exchange_part_elems(), faceCells_faceNodes(), gatherCellsLevel1_partID_map(), globalCellID_procID_map(), init(), interfaces(), level1_scatter_gather_cells(), map_part_elms(), mappers(), mesh_file(), mesh_setup(), non_interior_cells(), order_faceCells_faceNodes(), parmetis_mesh(), setNumFlag(), setWeightType(), and shift_sum_row().

vector< StorageSitePtr > MeshPartitioner::_nodeSite

private

Definition at line 201 of file MeshPartitioner.h.

Referenced by faceCells_faceNodes().

vector< set<int> > MeshPartitioner::_nonInteriorCells

private

Definition at line 231 of file MeshPartitioner.h.

Referenced by DEBUG_non_interior_cells(), init(), mesh_tecplot(), non_interior_cells(), and order_faceCells_faceNodes().

vector<int> MeshPartitioner::_nPart

private

Definition at line 163 of file MeshPartitioner.h.

Referenced by cellcells_global_extension(), compute_elem_dist(), count_elems_part(), CRConnectivity_cellParts(), DEBUG_compute_elem_dist(), DEBUG_exchange_interface_meshes(), DEBUG_interfaces(), DEBUG_map_part_elms(), exchange_interface_meshes(), exchange_part_elems(), global_offset(), globalCellID_procID_map(), init(), level1_scatter_gather_cells(), and parmetis_mesh().

vector< int > MeshPartitioner::_numFlag

private

Definition at line 173 of file MeshPartitioner.h.

Referenced by init(), parmetis_mesh(), and setNumFlag().

vector< ArrayIntPtr > MeshPartitioner::_offsetInterfaceCells

private

Definition at line 245 of file MeshPartitioner.h.

Referenced by DEBUG_exchange_interface_meshes(), exchange_interface_meshes(), and get_window_displ().

int MeshPartitioner::_options

private

Definition at line 179 of file MeshPartitioner.h.

Referenced by parmetis_mesh().

vector< int* > MeshPartitioner::_part

private

Definition at line 183 of file MeshPartitioner.h.

Referenced by compute_elem_dist(), DEBUG_fiedler_partition(), DEBUG_parmetis_mesh(), fiedler_partition(), map_part_elms(), parmetis_mesh(), and ~MeshPartitioner().

vector< CRConnectivityPtr > MeshPartitioner::_partCells

private

Definition at line 217 of file MeshPartitioner.h.

Referenced by CRConnectivity_cellParts().

vector< CRConnectivityPtr > MeshPartitioner::_partFaces

private

Definition at line 219 of file MeshPartitioner.h.

Referenced by construct_mesh(), count_interior_faces(), CRConnectivity_faceParts(), DEBUG_faceCells_faceNodes(), DEBUG_interfaces(), faceCells_faceNodes(), interfaces(), non_interior_cells(), and order_faceCells_faceNodes().

vector< CRConnectivityPtr > MeshPartitioner::_partNodes

private

Definition at line 220 of file MeshPartitioner.h.

Referenced by construct_mesh(), coordinates(), CRConnectivity_faceParts(), DEBUG_coordinates(), faceCells_faceNodes(), and level1_scatter_gather_cells().

vector< StorageSitePtr > MeshPartitioner::_partSite

private

Definition at line 203 of file MeshPartitioner.h.

Referenced by CRConnectivity_cellParts().

PARTTYPE MeshPartitioner::_partTYPE

private

Definition at line 256 of file MeshPartitioner.h.

Referenced by fiedler_order(), init(), and partition().

int MeshPartitioner::_procID

private

Definition at line 180 of file MeshPartitioner.h.

Referenced by compute_elem_dist(), construct_mesh(), coordinates(), count_interior_faces(), DEBUG_coordinates(), DEBUG_elem_connectivity(), DEBUG_faceCells_faceNodes(), DEBUG_fiedler_partition(), debug_file_open(), DEBUG_interfaces(), DEBUG_parmetis_mesh(), elem_connectivity(), exchange_part_elems(), faceCells_faceNodes(), fiedler_partition(), get_local_nodes(), get_window_displ(), global_offset(), init(), interfaces(), level1_scatter_gather_cells(), map_part_elms(), mesh_file(), mesh_setup(), mesh_tecplot(), mesh_xdmfplot(), non_interior_cells(), order_faceCells_faceNodes(), and set_eptr_eind().

vector< ArrayIntPtr > MeshPartitioner::_procTotalInterfaces

private

Definition at line 246 of file MeshPartitioner.h.

Referenced by exchange_interface_meshes(), and init().

vector< int* > MeshPartitioner::_row

private

Definition at line 187 of file MeshPartitioner.h.

Referenced by cleanup_follow_exchange_part_elems(), count_elems_part(), DEBUG_exchange_part_elems(), exchange_part_elems(), shift_sum_row(), and ~MeshPartitioner().

vector< vector< ArrayIntPtr > > MeshPartitioner::_toIndices

private

Definition at line 254 of file MeshPartitioner.h.

Referenced by init(), and mappers().

vector<int> MeshPartitioner::_totElems

private

Definition at line 164 of file MeshPartitioner.h.

Referenced by compute_elem_dist(), CRConnectivity_cellParts(), DEBUG_compute_elem_dist(), DEBUG_fiedler_partition(), fiedler_order(), init(), and mapBounIDAndCell().

vector<int> MeshPartitioner::_totElemsAndGhosts

private

Definition at line 165 of file MeshPartitioner.h.

Referenced by CRConnectivity_cellParts(), fiedler_order(), and init().

vector< float* > MeshPartitioner::_tpwgts

private

Definition at line 177 of file MeshPartitioner.h.

Referenced by init(), parmetis_mesh(), and ~MeshPartitioner().

vector< float* > MeshPartitioner::_ubvec

private

Definition at line 178 of file MeshPartitioner.h.

Referenced by init(), parmetis_mesh(), and ~MeshPartitioner().

vector< int > MeshPartitioner::_wghtFlag

private

Definition at line 172 of file MeshPartitioner.h.

Referenced by elem_connectivity(), init(), parmetis_mesh(), and setWeightType().

vector< int > MeshPartitioner::_windowSize

private

Definition at line 250 of file MeshPartitioner.h.

Referenced by create_window(), exchange_interface_meshes(), and init().

MPI::Win MeshPartitioner::_winGlobal

private

Definition at line 258 of file MeshPartitioner.h.

Referenced by create_window(), fence_window(), free_window(), and mappers().

MPI::Win MeshPartitioner::_winLocal

private

Definition at line 259 of file MeshPartitioner.h.

Referenced by create_window(), fence_window(), free_window(), and mappers().

---

The documentation for this class was generated from the following files:

• MeshPartitioner.h
• MeshPartitioner.cpp
